Space-saving automotive fuses
Features and benefits:
•
Fuses are color coded
by amp rating for easy
identification.
•
ATR fuses provide
single-circuit protection.
•
ATL fuses provide dual-
circuit protection in a
single product.
•
FMM fuses are the
smallest female Maxi
cartridge fuses in the
market.
•
Broad portfolio of micro
fuses provides solutions
fro most applications.
Bussmann series
superior micro fuses
provide protection
while consuming
minimal space.
Product description:
New vehicles are
incorporating more
electronic circuitry, which
requires more protection.
With space at a premium,
many new vehicles now use
micro fuses.
In addition to their small
footprint, micro fuses have
the capability to withstand
temperatures ranging from
-40oC to +125oC (-40oF to
257oF), making them ideal
for vehicles in extreme
environments.
Bussmann
®
series ATR
(2-blade) and ATL (3-blade)
fuses are rated to 32 volts
and constructed of nylon
with silver-plated zinc alloy
terminals. Bussmann series
FMM (micro female Maxi™)
fuses are also rated to 32
volts, but are constructed of
PA6T with tin-plated copper
terminals.
Micro blade fuses and cartridge
BUSSMANN
SERIES
Dimensions (actual size):
FMM
9.7 mm
15.0 mm
ATL
14.3 mm
15
.3
mm
ATR
9.1 mm
15
.3
m
m
