Chip Beads (2504021007Y0)
Part Number: 2504021007Y0
MULTI- LAYER CHIP BEAD
Fair- Rite offers a broad selection of cost effective multi- layer chip beads to suppress conducted EMI signals. Chip beads can be
used in an array of devices such as cellular phones, computers, laptops, pagers, etc. The small package sizes accommodate
automated placements and allow for a dense packaging of circuit boards.
Chip Beads are available in standard, high and GHz signal speeds.
Packaging Options:
- All multi- layer chip beads are supplied taped and reeled, if required bulk packed chip beads can be provided.
The suggested land patterns are in accordance to the latest revision of IPC-7351.
Weight: 0.002 (g)
Package Size: 0402 (1005)
Dim
mm
mm tol
nominal inch
inch misc.
A
0.5
±0.05
0.02
_
B
0.5
±0.05
0.02
_
C
1
±0.05
0.04
_
D
0.25
±0.15
0.01
_
Land Patterns
V
W
X
Y
Z
0.40
(0.016”)
1.30
(0.051”)
0.70
(0.028”)
0.90
(0.035”)
_
Reel Information
Tape Width
mm
Pitch
mm
Parts 7"
Reel
Parts 13"
Reel
Parts 14"
Reel
8
4
10000
_
_
