355

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  [email protected]

Fax:  (308) 284-8324

web:  www.ascapacitor.com

200VDC/135VAC

200VDC/135VAC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.200"

(5.1mm)

0.610"

(15.5mm)

24

1.3

0.068

0.340"

(8.6mm)

0.860"

(21.8mm)

24

30.3

0.0015

0.200"

(5.1mm)

0.610"

(15.5mm)

24

2.0

0.082

0.360"

(9.1mm)

0.860"

(21.8mm)

24

36.5

0.0022

0.200"

(5.1mm)

0.610"

(15.5mm)

24

2.9

0.10

0.390"

(9.9mm)

0.860"

(21.8mm)

24

44.5

0.0033

0.200"

(5.1mm)

0.610"

(15.5mm)

24

4.3

0.15

0.410"

(10.4mm)

1.000"

(25.4mm)

22

57.0

0.0047

0.200"

(5.1mm)

0.610"

(15.5mm)

24

6.1

0.22

0.420"

(10.7mm)

1.260"

(32.0mm)

22

48.8

0.0068

0.210"

(5.3mm)

0.610"

(15.5mm)

24

8.8

0.33

0.490"

(12.4mm)

1.260"

(32.0mm)

22

73.3

0.0082

0.220"

(5.6mm)

0.610"

(15.5mm)

24

10.7

0.47

0.570"

(14.5mm)

1.260"

(32.0mm)

20

104.3

0.010

0.240"

(6.1mm)

0.610"

(15.5mm)

24

13.0

0.68

0.560"

(14.2mm)

1.770"

(45.0mm)

20

90.4

0.015

0.270"

(6.9mm)

0.610"

(15.5mm)

24

19.5

0.82

0.610"

(15.5mm)

1.770"

(45.0mm)

20

109.1

0.022

0.300"

(7.6mm)

0.610"

(15.5mm)

24

28.6

1.0

0.650"

(16.5mm)

1.770"

(45.0mm)

20

133.0

0.033

0.290"

(7.4mm)

0.740"

(18.8mm)

24

21.9

2.0

0.820"

(20.8mm)

2.010"

(51.1mm)

20

222.0

0.047

0.330"

(8.4mm)

0.740"

(18.8mm)

24

31.3

5.0

1.250"

(31.8mm)

2.010"

(51.1mm)

20

555.0

PAGE 1 OF 3

POLYPROPYLENE FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE

355

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  [email protected]

Fax:  (308) 284-8324

web:  www.ascapacitor.com

400VDC/270VAC

400VDC/270VAC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

I

PEAK

(A)

0.0010

0.260"

(6.6mm)

0.800"

(20.3mm)

24

1.0

0.068

0.430"

(10.9mm)

1.300"

(33.0mm)

24

30.3

0.0015

0.290"

(7.4mm)

0.800"

(20.3mm)

24

1.6

0.082

0.460"

(11.7mm)

1.300"

(33.0mm)

22

36.5

0.0022

0.290"

(7.4mm)

0.800"

(20.3mm)

24

2.3

0.1

0.500"

(12.7mm)

1.300"

(33.0mm)

22

44.5

0.0033

0.290"

(7.4mm)

0.800"

(20.3mm)

24

3.4

0.15

0.590"

(15.0mm)

1.300"

(33.0mm)

20

66.8

0.0047

0.290"

(7.4mm)

0.800"

(20.3mm)

24

4.9

0.22

0.700"

(17.8mm)

1.300"

(33.0mm)

20

97.9

0.0068

0.290"

(7.4mm)

0.800"

(20.3mm)

24

7.1

0.33

0.720"

(18.3mm)

1.550"

(39.4mm)

20

117.5

0.0082

0.310"

(7.9mm)

0.800"

(20.3mm)

24

8.6

0.47

0.700"

(17.8mm)

2.050"

(52.1mm)

20

104.3

0.010

0.330"

(8.4mm)

0.800"

(20.3mm)

24

10.5

0.68

0.830"

(21.1mm)

2.050"

(52.1mm)

20

151.0

0.015

0.400"

(10.2mm)

0.800"

(20.3mm)

24

15.7

0.82

0.900"

(22.9mm)

2.050"

(52.1mm)

20

182.0

0.022

0.310"

(7.9mm)

1.050"

(26.7mm)

24

13.0

1.0

0.990"

(25.1mm)

2.050"

(52.1mm)

20

222.0

0.033

0.370"

(9.4mm)

1.050"

(26.7mm)

24

19.6

2.0

1.370"

(34.8mm)

2.050"

(52.1mm)

20

444.0

0.047

0.430"

(10.9mm)

1.050"

(26.7mm)

24

27.9

PAGE 2 OF 3

POLYPROPYLENE FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE

355

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  [email protected]

Fax:  (308) 284-8324

web:  www.ascapacitor.com

PAGE 3 OF 3

GENERAL SPECIFICATIONS

PHYSICAL CHARACTERISTICS

CONSTRUCTION:

 NON-INDUCTIVE WOUND POLYPROPYLENE AND FOIL.

CASE:

  FLAME RETARDANT TAPE WRAP CASE AND EPOXY FILL.

LEAD MATERIAL:

  AXIAL SOLDER COATED OR TINNED SOLID WIRE, AWG AS SPECIFIED IN TABLES.

DIMENSIONS:

 AS SPECIFIED IN TABLES.

ELECTRICAL CHARACTERISTICS

CAPACITANCE:

  AS SPECIFIED IN TABLES ± REQUESTED TOLERANCE WHEN MEASURED AT OR

REFERRED TO 1000 ± 20 HZ AND 25 ± 5 °C.

TOLERANCE:

 ±1%, ±2%, ±5%, ±10%, AND ±20% AVAILABLE.  OTHER TOLERANCES AVAILABLE UPON

REQUEST.

DISSIPATION FACTOR:

  SHALL NOT BE GREATER THAN 0.1% WHEN MEASURED AT OR REFERRED TO

1000 ± 20 HZ AND 25 ± 5 °C.

INSULATION RESISTANCE:

  SHALL BE GREATER THAN 200,000 M

Ω

 FOR CAPACITANCE VALUES 0.5 µF

AND LESS OR 100,000 M

Ω

 X µF FOR CAPACITANCE VALUES GREATER THAN 0.5µF WHEN MEASURED

AFTER 2 MINUTES ELECTRIFICATION AT 100VDC AND 25 ± 5 °C.

DIELECTRIC STRENGTH:

  200% RATED VOLTAGE FOR 1 MINUTE THROUGH A LIMITING RESISTANCE

OF 100 OHMS/VOLT AT 25 ± 5 °C.

RATED VOLTAGE:

  200VDC/135VAC AND 400VDC/270VAC AVAILABLE.

TEMPERATURE:

  -55 °C TO +105 °C AT FULL RATED VOLTAGE OPERATIONAL TEMPERATURE, +105 °C

MAX STORAGE TEMPERATURE.

ADDITIONAL INFORMATION

ORDERING INFORMATION:

  ALL ASC CAPACITORS ARE ORDERED BY "FAMILY CAP-TOL-VOLT"

DESIGNATION.  (I.E.  TO ORDER A 355 0.0082µF, ±5%, 400VDC CAPACITOR, REQUEST PART NUMBER
"355 .0082-5-400")

SEE ALSO:

  "GENERAL INFORMATION - POLYPROPYLENE CAPACITORS" DOCUMENT FOR ADDITIONAL

PHYSICAL, ELECTRICAL, AND PERFORMANCE CHARACTERISTICS NOT MENTIONED IN THIS FILE.

WARNING:

  INFORMATION ON THIS FILE IS SUBJECT TO CHANGE WITHOUT NOTICE AT ASC'S

DISCRETION.

LAST MODIFIED:  08/09/01

POLYPROPYLENE FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE
