5MP1
SERIES
Metallized
Polypropylene
Metallized Polypropylene
Metallized Polypropylene and Military Styles CFR13
and CFR14."Hi-Rel"
replacement for electrolytics for a broad range of commercial and military
switching power supplies.
FEATURES
STANDARD CONFIGURATION
-
Better electrical properties
with higher reliability and no
capacitance versus
electrolytic
-
Resonant frequency of
1065KHz
-
Ripple current to 30amps
-
Capacitance as high as 50µf
-
Voltage protection: 200%
-
Long term stability, retrace
and low dielectric absorption
-
5MP12/MIL Style CFR13 Wrap and
axial leads
-
5MP16/MIL Style CFR14 Wrap and
lug terminations
Rev. 3
Summary
Capacitance Range
1.0µF to 50.0µF. Capacitance is measured at 25°C at/or
referenced to a frequency of 1kHz.
Capacitance Tolerance
Standard tolerance is ±10%. Tolerances of ±20% and ±5% are
available.
Operating Temperature Range
-55°C to +105°C
Enclosure/ Construction
Mylar tape outer wrap.
Voltage Rating
DC working voltage ratings are from 100VDC to 400VDC
Quality Control
Capacitors are tested 100% for:
o Capacitance tolerance
o Dissipation Factor
o Dielectric withstanding voltage
o Insulation Resistance
o Equivalent Series Resistance (ESR)
Process and inspection data are maintained on
and available
on special request.
Environmental
Parameter
Method
Condition
Vibration
204
D
Immersion
104
B
Shock
213
I
Humidity
106
-
Thermal Shock
107
A
Life
108
F
Reference MIL-STD-202
Characteristics
Insulation Resistance
Temperature(°C)
25
85
105
Megaohmsx
Microfarads
300,000
30,000
3,000
Insulation Resistance
Dilectric Strength
Capacitors shall withstand a DC potential of twice rated
voltage for one (1) minute through a limiting resistance
of 100 ohms/volt without damage or breakdown.
Capacitance Change
Temperature(°C)
-55
25
105
PercentageChange
(typical)
2.0
0
-4.0
CapacitanceChange
Dissipation Factor
When measured at the frequency
for capacitance
measurement, the dissipation factor shall not exceed 0.1%.
INSULATION RESISTANCE VERSUS
TEMPERATURE
100
1,000
10,000
100,000
1,000,000
+25°
+45°
+65°
+85°
+105°
TEMPERATURE (°C)
IN
SU
LA
TI
O
N
R
ES
IS
TA
N
C
E
(M
EG
O
H
M
S
X
M
IC
R
O
FA
R
AD)
CAPACITANCE CHANGE VERSUS
TEMPERATURE
-5
-4
-3
-2
-1
0
1
2
-55°
-35°
-15°
+5°
+25°
+45°
+65°
+85° +105°
T E M PE R A T UR E (°C )
CA
PA
CI
TANCE CHANGE (%)
DISSIPATION FACTOR VERSUS TEMPERATURE
0
0.01
0.02
0.03
0.04
0.05
-55°
-35°
-15°
+5°
+25°
+45°
+65°
+85°
+105°
T E M PE R A T UR E (°C )
DISSI
PA
TION
FA
C
TOR (%)
Rev. 3
ELECTRICAL
DATA
EC PART
NUMBER
EQUIVALENT
MILITARY
DESIGNATION
CAP µF
D
L
ESR Ohms
20-100 kHz
Max
Fres
kHz
I PEAK
AMPS
dv/dt
(V/µs)
5MP12D105_
CFR13ALB105_
1
0.469 ±0.062
0.750
0.015
1065
407
407
5MP12D205_
CFR13ALB205_
2
0.534 ±0.062
0.938
0.012
703
528
264
5MP12D305_
CFR13ALB305_
3
0.624 ±0.093
0.938
0.011
574
790
263
5MP12D505_
CFR13ALB505_
5
0.640 ±0.093
1.250
0.100
385
828
166
5MP12D106_
CFR13ALB106_
10
0.805 ±0.093
1.500
0.009
248
1280
128
5MP12D206_
CFR13ALB206_
20
0.875 ±0.125
2.250
0.008
141
1517
76
5MP12D306_
CFR13ALB306_
30
1.075 ±0.125
2.250
0.006
115
2277
76
5MP12D506_
Not Available
50
1.375 ±0.125
2.250
0.004
89
3795
76
5MP12F105_
CFR13ALC105_
1
0.450 ±0.062
1.250
0.020
861
250
250
5MP12F205_
CFR13ALC205_
2
0.605 ±0.093
1.250
0.015
609
498
249
5MP12F305_
CFR13ALC305_
3
0.654 ±0.093
1.500
0.013
452
576
192
5MP12F505_
CFR13ALC505_
5
0.769 ±0.093
1.750
0.011
323
782
156
5MP12F106_
CFR13ALC106_
10
0.905 ±0.125
2.250
0.009
200
1139
114
5MP12F206_
CFR13ALC206_
20
1.315 ±0.125
2.250
0.006
141
2277
114
5MP12J105_
CFR13ALE105_
1
0.620 ±0.093
1.500
0.019
784
319
319
5MP12J205_
CFR13ALE205_
2
0.802 ±0.093
1.750
0.015
511
521
260
5MP12J305_
CFR13ALE305_
3
0.961 ±0.125
1.750
0.012
417
781
260
5MP12J505_
CFR13ALE505_
5
1.067 ±0.125
2.250
0.010
283
950
190
5MP12J106_
CFR13ALE106_
10
1.543 ±0.125
2.250
0.006
200
1898
190
Rev. 3
Lead
Dia.
0.032
0.032
0.040
0.040
0.040
0.040
0.040
0.040
0.032
0.032
0.040
0.040
0.040
0.040
0.040
0.040
0.040
0.040
0.040
Note:
The tenth character of the EC part number represents the capacitance tolerance: M=±20%, K=±10%, J=±5%.
EC PART
NUMBER
EQUIVALENT
MILITARY
DESIGNATION
CAP µF
D
L
ESR Ohms
20-100 kHz
Max
Fres
kHz
I PEAK
AMPS
dv/dt
(V/µs)
5MP16D105_
CFR14LLB105_
1
0.469 ±0.062
0.922
0.015
949
407
407
5MP16D205_
CFR14LLB205_
2
0.534 ±0.062
1.110
0.012
617
528
264
5MP16D305_
CFR14LLB305_
3
0.624 ±0.093
1.110
0.011
504
790
263
5MP16D505_
CFR14LLB505_
5
0.640 ±0.093
1.422
0.100
347
828
166
5MP16D106_
CFR14LLB106_
10
0.805 ±0.093
1.672
0.009
227
1280
128
5MP16D206_
CFR14LLB206_
20
0.875 ±0.125
2.422
0.008
133
1517
76
5MP16D306_
CFR14LLB306_
30
1.075 ±0.125
2.422
0.006
108
2277
76
5MP16D506_
Not Available
50
1.375 ±0.125
2.422
0.004
84
3795
76
5MP16F105_
CFR14LLC105_
1
0.450 ±0.062
1.422
0.020
776
250
250
5MP16F205_
CFR14LLC205_
2
0.605 ±0.093
1.422
0.015
548
498
249
5MP16F305_
CFR14LLC305_
3
0.654 ±0.093
1.672
0.013
414
576
192
5MP16F505_
CFR14LLC505_
5
0.769 ±0.093
1.922
0.011
299
782
156
5MP16F106_
CFR14LLC106_
10
0.905 ±0.125
2.422
0.009
188
1139
114
5MP16F206_
CFR14LLC206_
20
1.315 ±0.125
2.422
0.006
133
2277
114
5MP16J105_
CFR14LLE105_
1
0.620 ±0.093
1.672
0.019
716
319
319
5MP16J205_
CFR14LLE205_
2
0.802 ±0.093
1.922
0.015
472
521
260
5MP16J305_
CFR14LLE305_
3
0.961 ±0.125
1.922
0.012
386
781
260
5MP16J505_
CFR14LLE505_
5
1.067 ±0.125
2.422
0.010
265
950
190
5MP16J106_
CFR14LLE106_
10
1.543 ±0.125
2.422
0.006
188
1898
190
L1
1.640
1.828
1.828
2.140
2.390
3.140
3.140
3.140
2.140
2.140
2.390
2.640
3.140
3.140
2.390
2.640
2.640
3.140
3.140
Note:
The tenth character of the EC part number represents the capacitance tolerance: M=±20%, K=±10%, J=±5%.
EC PART
NUMBER
EQUIVALENT
MILITARY
DESIGNATION
MAXIMUM RIPPLE CURRENT
(AMPS RMS) 20-100 kHz
CASE TEMPERATURE
25°C
35°C
45°C
55°C
65°C
75°C
85°C
5MP12D105_
CFR13ALB105_
9.2
8.5
7.8
7.0
6.0
4.9
4.5
5MP12D205_
CFR13ALB205_
10.8
10.0
9.1
8.2
7.0
5.8
5.3
5MP12D305_
CFR13ALB305_
12.1
11.2
10.3
9.2
8.0
6.5
5.9
5MP12D505_
CFR13ALB505_
13.8
12.7
11.6
10.4
9.0
7.4
6.7
5MP12D106_
CFR13ALB106_
15.0
15.0
14.2
12.7
11.0
9.0
8.2
5MP12D206_
CFR13ALB206_
15.0
15.0
15.0
15.0
13.6
11.1
10.0
5MP12D306_
CFR13ALB306_
15.0
15.0
15.0
15.0
15.0
12.4
11.4
5MP12D506_
Not Available
15.0
15.0
15.0
15.0
15.0
13.6
12.4
5MP12F105_
CFR13ALC105_
7.3
7.3
7.3
7.3
7.2
5.9
5.4
5MP12F205_
CFR13ALC205_
12.0
12.0
11.3
10.1
8.7
7.1
6.5
5MP12F305_
CFR13ALC305_
15.0
13.8
12.6
11.3
9.8
8.0
7.3
5MP12F505_
CFR13ALC505_
15.0
15.0
14.7
13.1
11.4
9.3
8.5
5MP12F106_
CFR13ALC106_
15.0
15.0
15.0
15.0
13.8
11.3
10.3
5MP12F206_
CFR13ALC206_
15.0
15.0
15.0
15.0
15.0
14.1
12.8
5MP12J105_
CFR13ALE105_
9.5
9.5
9.5
9.5
9.5
7.8
7.1
5MP12J205_
CFR13ALE205_
15.0
15.0
15.0
13.4
11.6
9.5
8.7
5MP12J305_
CFR13ALE305_
15.0
15.0
15.0
15.0
13.1
10.7
9.8
5MP12J505_
CFR13ALE505_
15.0
15.0
15.0
15.0
15.0
12.5
11.4
5MP12J106_
CFR13ALE106_
15.0
15.0
15.0
15.0
15.0
15.0
14.1
5MP16D105_
CFR14LLB105_
10.3
9.5
8.7
7.8
6.7
5.5
5.0
5MP16D205_
CFR14LLB205_
12.0
11.0
10.0
8.9
7.8
6.3
5.8
5MP16D305_
CFR14LLB305_
13.3
12.3
11.2
10.0
8.7
7.1
6.5
5MP16D505_
CFR14LLB505_
14.8
13.7
12.5
11.2
9.7
7.9
7.2
5MP16D106_
CFR14LLB106_
17.8
16.5
15.0
13.5
11.7
9.5
8.7
5MP16D206_
CFR14LLB206_
21.6
20.0
18.3
16.4
14.2
11.6
10.6
5MP16D306_
CFR14LLB306_
24.3
22.5
20.5
18.4
15.9
13.0
11.9
5MP16D506_
Not Available
29.6
27.3
25.5
23.6
20.6
20.0
19.7
5MP16F105_
CFR14LLC105_
7.3
7.3
7.3
7.3
7.3
6.4
5.8
5MP16F205_
CFR14LLC205_
14.3
13.3
12.1
10.8
9.4
7.7
7.0
5MP16F305_
CFR14LLC305_
15.9
14.7
13.5
12.0
10.4
8.5
7.8
5MP16F505_
CFR14LLC505_
18.3
17.0
15.5
13.9
12.0
9.8
8.9
5MP16F106_
CFR14LLC106_
22.4
20.7
18.9
16.9
14.6
12.0
10.9
5MP16F206_
CFR14LLC206_
27.4
25.4
23.2
20.7
17.9
14.7
13.4
5MP16J105_
CFR14LLE105_
9.5
9.5
9.5
9.5
9.5
8.3
7.5
5MP16J205_
CFR14LLE205_
15.0
15.0
15.0
14.2
12.3
10.0
9.1
5MP16J305_
CFR14LLE305_
21.1
19.5
17.8
15.9
13.8
11.3
10.3
5MP16J505_
CFR14LLE505_
24.4
22.6
20.6
18.5
16.0
13.1
11.9
5MP16J106_
CFR14LLE106_
30.0
27.8
25.4
22.7
19.7
16.1
14.7
Note:
The tenth character of the EC part number represents the capacitance tolerance: M=±20%, K=±10%, J=±5%
Rev. 3
ADDITIONAL INFORMATION
These metallized polypropylene capacitors are manufactured by using special techniques in order to
achieve the optimum characteristics for high current, high capacitance, low ESR applications. For Filter
designs where capacitance of 50µF or less is suitable for the circuit, type 5MP
the opportunity to
utilize capacitors with ESR's orders of magnitude better than those of electrolytics, thus providing the
opportunity to improve general system design. These unique capacitors also exhibit none of the
of capacitance with frequency often associated with electrolytics.
In addition to the features which make type 5MP particularly suitable for switching applications,
they are also characterized by low losses. Other advantages of polypropylene are long term
stability, retrace, low dielectric absorption, and high insulation resistance.
HOW TO ORDER
TYPE
Metallized Polypropylene
5MP1
STYLE / VOLTAGE
AC high power / D=100VDC; F=200VDC; J=400VDC
2 D
CAPACITANCE
IN PICOFARADS
The
two digits are
the third represents the number of zeros
(e.g. 475=4700000pF)
105
TOLERANCE
Standard tolerance is ±10%. Tolerances of ±20% and ±5% are available.
K
Marking and Date Code
All capacitors are marked with company initials "EC", corporate logo or EC trademark—in addition to type 5MP1, capacitance,
tolerance, rated DC working voltage and date code. The
two digits of the date code represent the year, the second two digits the
week, i.e., 0952 is the 52nd week of 2009, 0902 is the second week of 2009.
Quality Assurance
Major emphasis is placed on quality assurance. EC is an ISO 9001-2000 and AS9100:2004
Company. Raw material
inspection and the use of SPC manufacturing procedures assure the highest quality standards. Procedures are fully described in the
EC Quality Control Manual. Electronic Concepts will continue to advance the state-of-the-art by utilizing leading edge technology,
compact capacitor designs and establishing reliability procedures.
Sales
United States
Europe
Eastern:
*Headquarters*
P.O. Box 1278
Eatontown,NJ 07724
Tel: 732-542-7880
Fax: 732-542-0524
Central:
Illinois 630-668-8747
email: sales@ecicaps.com
website:www.ecicaps.com
Ireland
Electronic ConceptsEurope LTD
IDA Estate, Oughterad
Co. Galway, Ireland
tel: +353-91-552385,552432
fax: +353-91-552387
email: sales@ecicaps.ie
website:www.electronicconcepts.ie
Rev. 3
