PCB Mount Solid State Relays - AC Output

DPA

1Amp

120/240 Vac
16-Pin DIP
SCR AC Switch Output
Zero Cross Turn-On

Crydom's DPA solid state relays are compact 16-pin DIP packages that are ideal
for high density automated assembled printed circuit boards.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

DPA4119

20-140

.025-1.0 3.5-10

1.0

UL, CSA, TUV

DPA6119

20-280

.025-1.0 3.5-10

1.0

UL, CSA, TUV

Line

Load

Control Must Must Surge

Voltage

Current

Operate

Release

Current

Range

Current

1-Cycle

Vrms

Arms

mAdc

Apk

DPA4111

20-140

.025-1.0 10-35

1.0

UL, CSA, TUV

DPA6111

20-280

.025-1.0 10-35

1.0

UL, CSA, TUV

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 3,750Vrms

SDV, SDI

1.5Amp

120/240 Vac
16-Pin DIP
SCR AC Switch Output
Zero Cross or Random Turn-On

The SDV/SDI solid state relays are compact 16-pin DIP packages that are ideal for
high density automated assembled printed circuit boards.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

SDV2415

12-280

.025-1.5 3.5-10

1.0

UL, CSA, TUV

SDV2415R*

12-280

.025-1.5 3.5-10

1.0

UL, CSA, TUV

Line

Load

Control Must

Must Surge

Voltage

Current

Operate

Release

Current

Range

Current

1-Cycle

Vrms

Arms

mAdc

Apk

SDI2415

12-280

.025-1.5 10-35

1.0

UL, CSA, TUV

SDI2415R*

12-280

.025-1.5 10-35

1.0

UL, CSA, TUV

* R sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 3,750Vrms

PCB Mount

Product Index

ASO

ASPF

CMX

CX/CXE

CX241

CTX

DO/DMO

DPA

D2W

MPF

SPF/PF

SDV/SDI

7
5

SPA
UPD

pg model 3 5 7 10 12 18 20 25 40 50 60 75 80 90 100 110 125 150

53TP

(3 Phase)

CSW

CMD/CMA

CWD/CWA

DxD

DC60

D06D

DUAL

H12

HD/HA

HD60/HA60

PRG

PSD

QUAD

Serie 1 A12/A24

Serie 1 D12/D24

SMR/SMR-6

SSC

CKR

CMR

HPF

MS11

110

CPV

DSD, DLD

LPCV

16,17

PCV

RPC

SST

- AC Output Relays
- DC Output Relays
- Ac and DC Outputs Available

Solid State Relays - PCB Mount

Rating Amps

Solid State Relays - Panel Mount

Rating Amps

Solid State Relays - DIN rail Mount

Rating Amps

Solid State Control Relays

pg model

DIP

pg model

1.0 1.5 2.0 3.0 3.5 4.0 5.0 6.0 8.0 10 12 15 20 25 40

DIP

1.5Amp

120/240 Vac
16-Pin DIP
SCR AC Switch Output
Zero Cross or Random Turn-On

Crydom's DIP solid state relays are compact 16-pin DIP packages that are ideal
for high density automated assembled printed circuit boards.

DIP1215

20-140

.025-1.5 10-35

1.0

CSA

DIP1215R*

20-140

.025-1.5 10-35

1.0

CSA

Line

Load

Control Must Must Surge

Voltage

Current

Operate

Release

Current

Range

Current

1-Cycle

Vrms

Arms

mAdc

Apk

DIP2415

20-280

.025-1.5 10-35

1.0

CSA

DIP2415R*

20-280

.025-1.5 10-35

1.0

CSA

* R Sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 3,750Vrms

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

PCB Mount Solid State Relays - AC Output

D2W

2-3.5Amp

120/240 Vac
AC SIP
Triac Output

The D2W Series features an epoxy-coated package that provides exceptional
environmental protection. Pinouts are compatible with Series 6 and OAC type I/O
modules.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

D2W202F

24-280

.06-2.0

3-32

1.0

UL, CSA

D2W203F

24-280

.06-3.0

3-32

1.0

UL, CSA

D2W203F-11

24-280

.06-3.5

3-32

1.0

UL, CSA

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

ASO

1.5-2Amp

120/240 Vac
AC Mini-SIP
DC Control, SCR AC Switch Output

US Patent No. 5,134,094

Crydom’s ASO solid state relays are SPST-NO miniature SIP packages rated at
1.5A/2.0A. They are designed for switching highly inductive, low current loads
such as solenoids. Typical applications include: pumps, gaming, vending
machines, security systems, medical equipment and appliances.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

ASO241

12-280

.025-1.5 4-10

1.0

UL, CSA

ASO241R*

12-280

.025-1.5 4-10

1.0

UL, CSA

ASO242

12-280

.06-2.0

4-10

1.0

120

UL, CSA

ASO242R*

12-280

.06-2.0

4-10

1.0

120

UL, CSA

* R sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms

CX241

1.5Amp

120/240 Vac
AC SIP, SCR AC Switch Output
Zero Cross or Random Turn-On

US Patent No. 5,134,094

The CX241/R AC relays are SPST-NO solid state relays. Both models offer the ASO
circuit with the popular CX pinout.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CX241

12-280

.025-1.5 4-10

1.0

UL, CSA, VDE

CX241R*

12-280

.025-1.5 4-10

1.0

UL, CSA, VDE

*R Sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

3-4Amp

120/240 Vac
Triac AC Output SIP
5, 15 & 24 Volt Logic System Compatible

Available in 3Arms and 4Arms ratings, all are SPST-NO PC-mount relays that provide
greater packaging density and compatibility with pinout of Series 6 and OAC output
modules. For DC output see page 7 for the MPDCD3.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

MP120D3

12-140

.02-3.0

3-32

2.6

1.0

UL, CSA, VDE

MP120D4

12-140

.02-4.0

3-32

2.6

1.0

130

MP240D2

24-280

.02-2.0

3-32

2.6

1.0

MP240D3

24-280

.02-3.0

3-32

2.6

1.0

UL, CSA, VDE

MP240D4

24-280

.02-4.0

3-32

2.6

1.0

130

CSA, VDE

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 4000 Vrms

MCX241

The MCX241/MCX241R offer the same speciﬁcations
and performance as the the CX241, the only differ-
ence is the MP style package. Add a “M” preﬁx to
the above part numbers for this option. Pinouts are
compatible with Series 6 and OAC type I/O modules.
MCX241 models are UL, CSA and VDE approved.

LC241, LC242

1.5 - 2.0 A

120/240 Vac
AC Mini-SIP
DC Control

The LC241/ LC242 offer the popular ASO circuit in cost effective package.
Crydom’s propretary Triac circuitry makes snubbless operation possible in most
applications.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

LC241

12-280

.025-1.5 4-10

1.0

UL, CSA

LC241R*

12-280

.025-1.5 4-10

1.0

UL, CSA

LC242

12-280

.025-2.0 4-10

1.0

100

LC242R*

12-280

.025-2.0 4-10

1.0

100

*R Sufﬁx denotes random turn-on.

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 2500 Vrms

PCB Mount

UPD

15-25 Amp

120/240Vac

Metal Baseplate
High Surge Rating
Zero Cross or Random Turn-On

Vrms

Arms

V DC

Apk

Vrms

Arms

V DC

Apk

UPD2415

24-280 .15-15

3-15

1.0

120

UPD2415-10

24-280 .15-15

3-15

1.0

120

UPD2425

24-280 .15-25

3-15

1.0

250

UPD2425-10

24-280 .15-25

3-15

1.0

250

UPD2415D

24-280 .15-15

3-15

14/36

1.0

120

UPD2415D-10

24-280 .15-15

3-15

14/36

1.0

120

UPD2425D

24-280 .15-25

3-15

14/36

1.0

250

UPD2425D-10

24-280 .15-25

3-15

14/36

1.0

250

Vrms

Arms

V DC

Apk

UPD2415TP

24-280 .15-15

4.5-8

1.0

120

UPD2415TP-10

24-280 .15-15

4.5-8

1.0

120

* Contact factory for availability.
** Input circuit incorporates active current limiter.

Line

Load

Control Control

Must

Surge

Voltage Current

Voltage

Current** Release

Current

Range

@12Vdc Voltage

1-Cycle

Line

Load

Control Control

Must

Surge

Voltage Current

Voltage

Current

Release

Current

Range

@12Vdc Voltage

1-Cycle

Line

Load

Control Control

Must

Surge

Voltage Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Crydom's UPD series solid-state relays are an ideal solution for high-power
switching applications with limited panel space. Single phase, dual output, or
three phase versions are available with either PCB or quick-connect* terminals,
making the UPD series the perfect long-life alternative to many
electromechanical relays.

Dual

3Phase

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

CTX

4 x 2.5Amp

120/240 Vac
TRIAC Output
4 AC Relays in One
Compact Package

The CTX240D3Q offers four independently controlled solid state relays in one
compact PCB mount package. Based on the proven Series CX product line,
featuring ultra high surge rating, extra low leakage and 4-10 Vdc logic compatible
input. The CTX exhibits exceptional steady-state ratings utilizing highly efﬁcient
thermal management for increased cycle life.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CTX240D3Q

24-280

0.1-6.0** 4-10

1.0

120

CTX240D3QR*

24-280

0.1-6.0** 4-10

1.0

120

* R sufﬁx denotes random turn-on. Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms
**1 section ON; 2 sections ON 0.1-4.0; 3 sections ON 0.1-3.0; 4 sections ON 0.1-2.5

PCB Mount Solid State Relays - AC Output

8-12Amp

120/240 Vac
Metal Baseplate
High Surge Rating
Zero Cross or Random Turn-On

Metal baseplate design for direct attachment of external heat sink to achieve maximum
current ratings. Applications include; motor, heater, lamp and solenoid switching.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

LS240D8

24-280

.15-8

4-10

1.0

UL, cUL,TUV

LS240D8R*

24-280

.15-8

4-10

1.0

UL, cUL,TUV

LS240D12

24-280

.15-12

4-10

1.0

120

UL, cUL,CSA, TUV

LS240D12R*

24-280

.15-12

4-10

1.0

120

UL, cUL,CSA, TUV

* R sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms
24 Vdc input versions available (LSE series)

25-40Amp

120/240/480 Vac
Zero Cross or Random Turn-On
SCR AC Switch Output
Low Proﬁle

The LR products offer a low proﬁle package that is perfect for printed circuit board
mounting. Rated at up to 1200V transient capability. Mounting clip available, order
part no. LMC-1.

Line

Load

Control Control

Must

Surge

Voltage Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Zero Cross

Vrms

Arms

Vdc

Apk

LR600240D25

24-280 .15-25

4-32

1.0

250

LR600240D40

24-280 .15-40

4-32

1.0

400

LR1200480D25

48-530 .15-25

4-32

1.0

250

LR1200480D40

48-530 .15-40

4-32

1.0

400

Random Turn-On

LR600240D25R

24-280 .15-25

4-32

1.0

250

LR600240D40R

24-280 .15-40

4-32

1.0

400

LR1200480D25R

48-530 .15-25

4-32

1.0

250

LR1200480D40R

48-530 .15-40

4-32

1.0

400

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms
AC input versions available

PCB Mount

CX, CXE

5Amp

120/240/380/480 Vac
AC SIP, SCR AC Switch Output
Ultra High Surge Rating

US Patent No. 5,134,094

Crydom's family of SPST-NO relays provide a high power switching capability in
a PC-mounted air-cooled package. Advanced features include exceptional steady
state current, plus ultra-high surge ratings. Models are available to switch up to
660 Vrms with AC or DC control, and either zero-cross or random turn-on ("R")
switching versions. Pinout is compatible with Series 6 and OAC type I/O modules.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release Current

Range

@ 5/24Vdc Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CX240D5

12-280

.06-5.0 3-15

1.0

250

UL, CSA, VDE

CX240D5R*

12-280

.06-5.0 3-15

1.0

250

UL, CSA, VDE

CXE240D5

12-280

.06-5.0 15-32

1.0

250

UL, CSA, VDE

CXE240D5R*

12-280

.06-5.0 15-32

1.0

250

UL, CSA, VDE

CX380D5

48-530

.06-5.0 4-15

1.0

250

UL, CSA, VDE

CX380D5R*

48-530

.06-5.0 4-15

1.0

250

UL, CSA, VDE

CXE380D5

48-530

.06-5.0 15-32

1.0

250

UL, CSA, VDE

CXE380D5R*

48-530

.06-5.0 15-32

1.0

250

UL, CSA, VDE

CX480D5

48-660

.06-5.0 4-15

1.0

250

UL, CSA

CX480D5R*

48-660

.06-5.0 4-15

1.0

250

UL, CSA

CXE480D5

48-660

.06-5.0 15-32

1.0

250

UL, CSA

CXE480D5R*

48-660

.06-5.0 15-32

1.0

250

UL, CSA

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current@ Release Current

Range

120/24Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

CX240A5

12-280

.06-5.0 90-140

10.0

250

UL, CSA

CX240A5R*

12-280

.06-5.0 90-140

10.0

250

UL, CSA

CXE240A5

12-280

.06-5.0 18-36

2.0

250

UL, CSA

CXE240A5R*

12-280

.06-5.0 18-36

2.0

250

UL, CSA,

* R sufﬁx denotes random turn-on. Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

Normally closed (Form B) versions available (-B sufﬁx)

MPF

4Amp

120/240 Vac
SCR AC Switch Output
Integral Heat sink

US Patent No. 5,134,094

The MPF delivers high ratings ia a single in-line package (SIP). Crydom’s patented
PowerFIN™ integral heat sink design makes for a cool compact package for PCB
mounting. With natural convection in free air, it rates 4Arms at 50˚C ambient.

Line

Load

Control Control

Must Surge

Voltage Current

Voltage

Current

Release

Current

Range

@5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

MPF240D4

12-280 .1-4

4-10

1.0

UL, CSA

MPF240D4R*

12-280 .1-4

4-10

1.0

UL, CSA

* R sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 3750 Vrms

MCX, MCXE

5Amp

120/240/380/480 Vac
AC SIP
SCR AC Switch Output
Ultra High Surge Rating

The MCX and MCXE offer the same speciﬁcations and performance as the the CX
and CXE products, the only difference is the MP style package. Add a “M” preﬁx.

UL, cUL
UL, cUL
UL, cUL
UL, cUL

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

Up to 25Amp

120/240/380/480/600 Vac
SCR AC Switch Output
Ultra High Steady State Current Rating

US Patent No. 5,134,094

Crydom’s PowerFin Series delivers the highest ratings of any single in-line
package (SIP). With Crydom’s integral heat sink design you can run 25 amps RMS
in forced air at 85˚C case temp. With natural convection in free air, it rates 10
amps RMS at 25˚C ambient. Built-in advantages include Surface Mount
Technology, low off-state leakage and SCR AC switch output.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current@

Release

Current

Range

Range**

Range

5/24Vrms

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

PF240D25

12-280 .06-25

3-15

1.0

250

UL, cUL, VDE

PF240D25R*

12-280 .06-25

3-15

1.0

250

UL, cUL, VDE

PFE240D25

12-280 .06-25

15-32

1.0

250

UL, cUL, VDE

PFE240D25R*

12-280 .06-25

15-32

1.0

250

UL, cUL, VDE

PF380D25

48-530 .06-25

4-15

1.0

250

UL, cUL, VDE

PF380D25R*

48-530 .06-25

4-15

1.0

250

UL, cUL, VDE

PFE380D25

48-530 .06-25

15-32

1.0

250

UL, cUL, VDE

PFE380D25R*

48-530 .06-25

15-32

1.0

250

UL, cUL, VDE

PF480D25

48-660 .06-25

4-15

1.0

250

UL, cUL

PF480D25R*

48-660 .06-25

4-15

1.0

250

UL, cUL

PFE480D25

48-660 .06-25

15-32

1.0

250

UL, cUL

PFE480D25R*

48-660 .06-25

15-32

1.0

250

UL, cUL

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current @ Release

Current

Range

Range**

Range

120/24Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

PF240A25

12-280 .06-25

90-140

10.0

250

UL, cUL

PF240A25R*

12-280 .06-25

90-140

10.0

250

UL, cUL

PFE240A25

12-280 .06-25

18-36

2.0

250

UL, cUL

PFE240A25R

* 12-280 .06-25

18-36

2.0

250

UL, cUL

* R sufﬁx denotes random turn-on. **Forced Air, .06-10 in convection air.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

PCB Mount Solid State Relays

PCB Mount SSRs - DC Output

DO, DMO

1-3Amp

60 Vdc
DC Mini-SIP
DC Control
Bipolar or MOSFET Output

SPST-NO DC output relays in epoxy-coated packages utilize the popular .10" grid
lead spacing. They are available with either bipolar transistor output (DO), or the
DMO063 with MOSFET output is rated at 3A/60 VDC.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1 Sec

Vdc

Adc

Vdc

Adc

DO061A

3-60

.02-1.0

3-9

1.0

5.0

DO061B

3-60

.02-1.0

1.7-9

0.8

5.0

DMO063

0-60

0-3.0

3-10

1.0

12 (@ 10msec)

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms, 4000 Vrms (DO)
Normally closed (Form B) versions available for DO series (-B sufﬁx)

CMX

3-20Amp

60/100/200 Vdc
DC SIP, MOSFET Output
Extra Low On-state Resistance

US Patent No. 5,134,094

DC output SPST-NO solid state relays use MOSFET output for high switching
capabilities in a PC-mount air-cooled package. Pinouts are compatible with
Series 6 and ODC type I/O modules.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

10 ms

Vdc

Adc

Vdc

Adc

CMX60D5

0-60

0-5

3-10

1.0

CMX60D10

0-60

0-10

3-10

1.0

100

UL, cUL

CMX60D20

0-60

0-20

3-10

1.0

200

CMX100D6

0-100

0-6

3-10

1.0

100

UL, cUL

CMX200D3

0-200

0-3

4-10

1.0

UL, cUL

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms

MPDCD3

3Amp

60 Vdc
DC Output SIP
5, 15 & 24 Volt Logic System Compatible

A SPST-NO PC-mount relay that provide greater packaging density and
compatibility with pinout of Series 6 and ODC output modules.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1 sec.

Vdc

Adc

Vdc

Adc

MPDCD3

3-60

.02-3

3-32

2.6

1.0

5.0

UL, cUL

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 4000 Vrms

PCB Mount

ASPF

3Amp

120/240 Vac
AC Mini-SIP, Integral Heat Sink
SCR AC Switch Output

US Patent No. 5,134,094

The ASPF Series delivers high ratings in a single in-line package (SIP). Crydom’s
patented PowerFIN™ integral heat sink design makes for a cool package with high
ratings. With natural convection in free air, it rates 3 Arms at 45˚C ambient.

Line

Load

Control Control

Must Surge

Voltage Current

Voltage

Current

Release

Current

Range

@5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

ASPF240D3

24-280 .1-3

4-10

1.0

UL, CSA

ASPF240D3R*

24-280 .1-3

4-10

1.0

UL, CSA

* R sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 3750 Vrms

SPF

Up to 25Amp

120/240/380/480/600 Vac
SCR AC Switch Output
Ultra High Steady State Current Rating
Works in both the vertical en horizontal
orientation.

US Patent No. 5,134,094

The SPF is identical to the PF products in speciﬁcations and performance, the
only difference is the package conﬁguration. The SPF utilizes a low proﬁle integral
heat sink that provides decreased package width for higher density applications.
To order the SPF conﬁguration simply add the “S” preﬁx to any of the above PF
model numbers. All SPF and SPFE models are UL and cUL approved.

SPA

1Amp

120/240 Vac
AC Mini-SIP, Zero Cross Turn-On
SCR AC Switch Output

US Patent No. 5,134,094

The SPA package is perfect for high density printed circuit boards. Typical
applications include: pumps, gaming, vending machines, security systems,
medical equipment and appliances.

Line

Load

Control Must

Must Surge

Voltage

Current

Operate

Release

Current

Range

Current

1-Cycle

Vrms

Arms

Apk

SPA4191

20-140

.025-1.0 10-35

1.0

SPA6191

20-280

.025-1.0 10-35

1.0

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

anel Mount

Panel Mount Solid State Relays - AC Output

5-18Amp

120/240/480 Vac
SCR AC Switch Output
Low Proﬁle - Quick Connect Terminals
24V Control Available (EZE)

The Series EZ is a SPST-NO AC output relays offer a low proﬁle package and is
the preferred choice for replacement of Electro-mechanical relays. Random Turn-
On models (R sufﬁx) are available.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@5/24Vdc Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

EZ240D5

24-280

.15-5

4-15

1.0

UL, cUL

EZ240D12

24-280

.15-12

3-15

1.0

150

UL, CSA, VDE

EZ240D18

24-280

.15-18

3-15

1.0

200

UL, CSA, VDE

EZE240D12

24-280

.15-12

15-32

1.0

150

UL, CSA, VDE

EZE240D18

24-280

.15-18

15-32

1.0

200

UL, CSA, VDE

EZ480D12

48-660

.15-12

4-15

1.0

150

UL, CSA

EZ480D18

48-660

.15-18

4-15

1.0

200

UL, CSA

EZE480D12

48-660

.15-12

15-32

1.0

150

UL, CSA

EZE480D18

48-660

.15-18

15-32

1.0

200

UL, CSA

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current @ Release

Current

Range

120/24Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

EZ240A12

24-280

.15-12

90-140

10.0

150

UL, CSA

EZ240A18

24-280

.15-18

90-140

10.0

200

UL, CSA

EZE240A12

24-280

.15-12

18-36

2.0

150

UL, CSA

EZE240A18

24-280

.15-18

18-36

2.0

200

UL, CSA

EZ480A12

48-660

.15-12

90-140

10.0

150

UL, CSA

EZ480A18

48-660

.15-18

90-140

10.0

200

UL, CSA

EZE480A12

48-660

.15-12

18-36

2.0

150

UL, CSA

EZE480A18

48-660

.15-18

18-36

2.0

200

UL, CSA

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms

NTD, NTA

5-25Amp

120/240 Vac
Zero Cross or Random Turn-On (-10)

The NT products are available with either DC control (NTD) or AC control (NTA)
with a wide output range (24-280 Vrms).

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

NTD2405

24-280

.15-5

4-15

1.0

CSA, CSAus

NTD2410

24-280

.15-10

3-32

1.0

120

UL, CSA

NTD2425

24-280

.15-25

3-32

1.0

250

UL, CSA

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current @ Release

Current

Range

120Vrms

Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

NTA2410

24-280

.15-10

90-140

120

UL, CSA

NTA2425

24-280

.15-25

90-140

250

UL, CSA

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 3750 Vrms
Random turn-on, phase controllable (-10 sufﬁx)

CSW

10-90Amp

120/240 Vac
Low Leakage
SCR AC Switch Output

The Series CSW has an SCR AC switch output featuring low off-state leakage
(1mA, snubberless), zero-voltage switching and a broadened operating range (24-
280Vrms). This wide range permits optimum performance at both 120Vac and
240Vac line voltages.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CSW2410

24-280

.15-10

3-32

1.0

120

UL, CSA, VDE

CSW2425

24-280

.15-25

3-32

1.0

250

UL, CSA, VDE

CSW2450

24-280

.15-50

3-32

1.0

625

UL, CSA, VDE

CSW2475

24-280

.25-75

3-32

1.0

1000

UL, CSA, VDE

CSW2490

24-280

.25-90

3-32

1.0

1200

UL, CSA, VDE

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms Minimum Off-State dv/dt 500V/μsec
Random turn-on, phase controllable (-10 sufﬁx)

Series 1

10-125Amp

120/240 Vac
SCR AC Switch Output
Zero Voltage or Random Turn-On

Featuring state-of-the-art Surface Mount Technology, these SPST-NO relays
deliver proven reliability in the most demanding applications. Relay output
consists of an SCR AC switch and is available in either AC or DC (coil) control.
Options include; zero-cross, random turn-on, phase controllable (add “-10”
sufﬁx); normally closed (Form B) version (add “-B” sufﬁx); 24 Vac control models
(add “E” sufﬁx). UL 508A SCCR Approved, consult Crydom for actual ratings.

D12, D24

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

D1210

24-140

.04-10

3-32

3.4

1.0

120

UL, CSA, VDE

D1225

24-140

.04-25

3-32

3.4

1.0

250

UL, CSA, VDE

D1240

24-140

.04-40

3-32

3.4

1.0

625

UL, CSA, VDE

D2410

24-280

.04-10

3-32

3.4

1.0

120

UL, CSA, VDE

D2425

24-280

.04-25

3-32

3.4

1.0

250

UL, CSA, VDE

D2450

24-280

.04-50

3-32

3.4

1.0

625

UL, CSA, VDE

D2475

24-280

.04-75

3-32

3.4

1.0

1000

UL, CSA, VDE

D2490

24-280

.04-90

3-32

3.4

1.0

1200

UL, CSA, VDE

D24110

24-280

.15-110

3-32

3.4

1.0

1500

UL, cUL

D24125

24-280

.15-125

3-32

3.4

1.0

1750

UL, cUL

A12, A24

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current@ Release

Current

Range

120Vrms

Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

A1210

24-140

.04-10

90-280

2.0

10.0

120

UL, CSA, VDE

A1225

24-140

.04-25

90-280

2.0

10.0

250

UL, CSA, VDE

A1240

24-140

.04-40

90-280

2.0

10.0

625

UL, CSA, VDE

A2410

24-280

.04-10

90-280

2.0

10.0

120

UL, CSA, VDE

A2425

24-280

.04-25

90-280

2.0

10.0

250

UL, CSA, VDE

A2450

24-280

.04-50

90-280

2.0

10.0

625

UL, CSA, VDE

A2475

24-280

.04-75

90-280

2.0

10.0

1000

UL, CSA, VDE

A2490

24-280

.04-90

90-280

2.0

10.0

1200

UL, CSA, VDE

A24110

24-280

.15-110

90-280

2.0

10.0

1500

UL, cUL

A24125

24-280

.15-125

90-280

2.0

10.0

1750

UL, cUL

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

Panel Mount Solid State Relays - AC Output

H12

25-125Amp

480/600 Vac
SCR AC Switch Output
1200 Volt Blocking

High voltage relays use IC driven circuits for switching loads up to 660 VAC. All
models come with 1200 Volts blocking standard. Types CA, CD and WD are
snubberless and feature low off-state leakage. UL 508A SCCR Approved, consult
Crydom for actual ratings.

Line

Load

Control Control

Must

Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

H12WD4825

48-660

.15-25

4-32

1.0

250

UL, VDE

H12WD4850

48-660

.15-50

4-32

1.0

625

UL, CSA, VDE

H12WD4875

48-660

.15-75

4-32

1.0

1000

VDE

H12WD4890

48-660

.15-90

4-32

1.0

1200

UL, CSA, VDE

H12WD48125

48-660

.15-125 4-32

1.0

1750

UL, cUL

H12D4825

48-530

.15-25

4-32

1.0

250

UL, cUL, VDE

H12D4850

48-530

.15-50

4-32

1.0

625

UL, CSA, VDE

H12D4875

48-530

.15-75

4-32

1.0

1000

VDE

H12D4890

48-530

.15-90

4-32

1.0

1200

UL, CSA, VDE

H12CD4825

48-660

.15-25

4-15

1.0

250

UL, CSA, VDE

H12CD4850

48-660

.15-50

4-15

1.0

625

UL, CSA, VDE

H12CD4890

48-660

.15-90

4-15

1.0

1200

UL, CSA, VDE

Line

Load

Control Control

Must

Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

H12CA4825

48-660

.15-25

90-140

10.0

250

UL, CSA, VDE

H12CA4850

48-660

.15-50

90-140

10.0

625

UL, CSA, VDE

H12CA4890

48-660

.15-90

90-140

10.0

1200

UL, CSA, VDE

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec
Random turn-on, phase controllable (-10 sufﬁx)

CWD, CWA

10-125Amp

120/240/480/600 Vac
SCR AC Switch Output
Integrated IP20 Fingerproof Cover
EMC Compliant Design

The CW series offers a SCR AC switch output featuring low off-state leakage (1mA,
snubberless), zero cross or random turn-on (-10) switching and a wide operating
range (28-280Vrms) for optimum performance at 120V ac and 240Vac line voltages.
High thermal ratings with reduced power dissipation result in reduced heat sink
requirements for optimum performance. Additional features include; integrated,
removable ﬁnger-proof cover, LED status indication and user-friendly connectors. UL 508A
SCCR Approved, consult Crydom for actual ratings.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 12Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CWD2410

24-280

.15-10

3-32

1.0

400

UL, CSA, VDE

CWD2425

24-280

.15-25

3-32

1.0

600

UL, CSA, VDE

CWD2450

24-280

.15-50

3-32

1.0

850

UL, CSA, VDE

CWD2490

24-280

.25-90

3-32

1.0

1350

UL, CSA, VDE

CWD24125

24-280

.25-125

3-32

1.0

2000

UL, CSA, VDE

CWD4810

48-660

.15-10

4-32

1.0

400

UL, CSA, VDE

CWD4825

48-660

.15-25

4-32

1.0

600

UL, CSA, VDE

CWD4850

48-660

.15-50

4-32

1.0

850

UL, CSA, VDE

CWD4890

48-660

.25-90

4-32

1.0

1350

UL, CSA, VDE

CWD48125

48-660

.25-125

4-32

1.0

2000

UL, cUL

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

CWA2410

24-280

.15-10

90-280

6.0

10.0

400

UL, CSA, VDE

CWA2425

24-280

.15-25

90-280

6.0

10.0

600

UL, CSA, VDE

CWA2450

24-280

.15-50

90-280

6.0

10.0

850

UL, CSA, VDE

CWA2490

24-280

.25-90

90-280

6.0

10.0

1350

UL, CSA, VDE

CWA24125

24-280

.25-125

90-280

6.0

10.0

2000

UL, CSA, VDE

CWA4810

48-660

.15-10

90-280

6.0

10.0

400

UL, CSA, VDE

CWA4825

48-660

.15-25

90-280

6.0

10.0

600

UL, CSA, VDE

CWA4850

48-660

.15-50

90-280

6.0

10.0

850

UL, CSA, VDE

CWA4890

48-660

.25-90

90-280

6.0

10.0

1350

UL, CSA, VDE

CWA48125

48-660

.25-125

90-280

6.0

10.0

2000

UL, cUL

Operating Temperature Range: -40˚C to 80˚C , isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec
24 Vac input versions available (E sufﬁx)

HD, HA

12-125Amp

480Vac
Zero Voltage or Random Turn-on
Ultra Low Control Current

Crydom's HD (DC control) and HA (AC control) relays incorporate the same
proven technologies as our Series 1. All models come with 1200 volts blocking as
standard and are available in either zero-cross or random turn-on and phase
controllable (-10) switching versions.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

HD4812

48-530

.04-12

3-32

2.0

1.0

140

UL, CSA, VDE

HD4825

48-530

.04-25

3-32

2.0

1.0

250

UL, CSA, VDE

HD4850

48-530

.04-50

3-32

2.0

1.0

625

UL, CSA, VDE

HD4875

48-530

.04-75

3-32

2.0

1.0

1000

UL, CSA, VDE

HD4890

48-530

.04-90

3-32

2.0

1.0

1200

UL, CSA, VDE

HD48110

48-530

.15-110

3-32

2.0

1.0

1500

UL, cUL

HD48125

48-530

.15-125

3-32

2.0

1.0

1750

UL, cUL

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

HA4812

48-530

.04-12

90-280

2.0

10.0

140

UL, CSA, VDE

HA4825

48-530

.04-25

90-280

2.0

10.0

250

UL, CSA, VDE

HA4850

48-530

.04-50

90-280

2.0

10.0

625

UL, CSA, VDE

HA4875

48-530

.04-75

90-280

2.0

10.0

1000

UL, CSA, VDE

HA4890

48-530

.04-90

90-280

2.0

10.0

1200

UL, CSA, VDE

HA48110

48-530

.15-110

90-280

2.0

10.0

1500

UL, cUL

HA48125

48-530

.15-125

90-280

2.0

10.0

1750

UL, cUL

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec
24 Vac input versions available (E sufﬁx)

SMR, SMR-6

25-90Amp

120/240/480 Vac
SCR AC Switch Output
Versatile System Monitoring SSR
LED Status Indicators, Alarm Output

The SMR system monitoring SSR’s offer a wide range of built-in fault condition
alarms to the end-user. Loss of voltage, open circuit load, relay damage and loss
of DC supply are constantly monitored. LED status indicators complete the
package for early detection of equipment problems. SMR-6 models offer the user
the capability to conﬁgure the relay with either inverting or non-inverting control
and alarm. The alarm circuit can sink or source up to 100mA.

Line

Load

Control

Alarm

Surge

Voltage

Current

Voltage

Current

Output

Current

Range

@ 12Vdc Current

1-Cycle

Vrms

Arms

Vdc

(max.)

Apk

SMR2425

60-280

.04-25

8-32

100

250

UL, CSA, VDE

SMR2450

60-280

.04-50

8-32

100

625

UL, CSA, VDE

SMR2490

60-280

.04-90

8-32

100

1200

UL, CSA, VDE

SMR2425-6

60-280

.04-25

8-32

100

250

UL, CSA, VDE

SMR2450-6

60-280

.04-50

8-32

100

625

UL, CSA, VDE

SMR2490-6

60-280

.04-90

8-32

100

120

UL, CSA, VDE

SMR4825-6

96-530

.04-25

8-32

100

250

CSA, VDE

SMR4850-6

96-530

.04-50

8-32

100

625

CSA, VDE

SMR4890-6

96-530

.04-90

8-32

100

1200

CSA, VDE

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec

anel Mount

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

anel Mount

HD60, HA60

25-125Amp

600 Vac
Zero Voltage or Random Turn-on
Ultra Low Control Current

Crydom's HD60 (DC control) and HA60 (AC control) relays incorporate the same
proven technologies as the HD/HA products with up to 660 Vac load voltage
range, preferred choice in Canada. All models come with 1200 volts blocking as
standard and are available in either zero-cross or random turn-on and phase
controllable (-10) switching versions.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

HD6025

48-660

.04-25

3-32

2.0

1.0

250

UL, CSA, VDE

HD6050

48-660

.04-50

3-32

2.0

1.0

625

UL, CSA, VDE

HD6090

48-660

.04-90

3-32

2.0

1.0

1200

UL, CSA, VDE

HD60125

48-660

.15-125

3-32

2.0

1.0

1750

UL, CSA

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

HA6025

48-660

.04-25

90-280

2.0

10.0

250

UL, CSA, VDE

HA6050

48-660

.04-50

90-280

2.0

10.0

625

UL, CSA, VDE

HA6090

48-660

.04-90

90-280

2.0

10.0

1200

UL, CSA, VDE

HA60125

48-660

.15-125

90-280

2.0

10.0

1750

UL, CSA

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec
24 Vac input versions available (E sufﬁx)

Panel Mount Solid State Relays - AC Output

CMD, CMA

25-125Amp

120/240/480/600 Vac
SCR AC Switch Output
Zero Cross or Random Turn-on

These Propack SPST-NO solid state relays offer box clamp connections for safety
and ease-of-use. The on-board LED provides visible status indication. Also
available with DIN rail mount and integral heat sink, (see CMR products on page 14).
Model choices include zero-voltage or random turn-on (phase controllable)
switching (add sufﬁx -10).

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CMD2425

24-280

.15-25

3-32

1.0

250

UL, CSA, VDE

CMD2450

24-280

.15-50

3-32

1.0

625

UL, CSA, VDE

CMD2475

24-280

.25-75

3-32

1.0

1000

UL, CSA, VDE

CMD2490

24-280

.25-90

3-32

1.0

1200

UL, CSA, VDE

CMD24110

24-280

.25-110

3-32

1.0

1500

UL, CSA

CMD24125

24-280

.25-125

3-32

1.0

1750

UL, CSA

CMD4825

48-530

.15-25

4-32

1.0

250

UL, CSA, VDE

CMD4850

48-530

.15-50

4-32

1.0

625

UL, CSA, VDE

CMD4875

48-530

.25-75

4-32

1.0

1000

UL, CSA, VDE

CMD4890

48-530

.25-90

4-32

1.0

1200

UL, CSA, VDE

CMD48110

48-530

.25-110

4-32

1.0

1500

UL, CSA

CMD48125

48-530

.25-125

4-32

1.0

1750

UL, CSA

CMD6025

48-660

.15-25

4-32

1.0

250

UL, CSA, VDE

CMD6050

48-660

.15-50

4-32

1.0

625

UL, CSA, VDE

CMD6075

48-660

.25-75

4-32

1.0

1000

UL, CSA, VDE

CMD6090

48-660

.25-90

4-32

1.0

1200

UL, CSA, VDE

CMD60110

48-660

.25-110

4-32

1.0

1500

UL, CSA

CMD60125

48-660

.25-125

4-32

1.0

1750

UL, CSA

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

CMA2425

24-280

.15-25

90-140

250

UL, CSA, VDE

CMA2450

24-280

.15-50

90-140

625

UL, CSA, VDE

CMA2475

24-280

.25-75

90-140

1000

UL, CSA, VDE

CMA2490

24-280

.25-90

90-140

1200

UL, CSA, VDE

CMA24110

24-280

.25-110

90-140

1500

UL, CSA

CMA24125

24-280

.25-125

90-140

1750

UL, CSA

CMA4825

48-530

.15-25

90-140

250

UL, CSA, VDE

CMA4850

48-530

.15-50

90-140

625

UL, CSA, VDE

CMA4875

48-530

.25-75

90-140

1000

UL, CSA, VDE

CMA4890

48-530

.25-90

90-140

1200

UL, CSA, VDE

CMA48110

48-530

.25-110

90-140

1500

UL, CSA

CMA48125

48-530

.25-125

90-140

1750

UL, CSA

CMA6025

48-660

.15-25

90-140

250

UL, CSA, VDE

CMA6050

48-660

.15-50

90-140

625

UL, CSA, VDE

CMA6075

48-660

.25-75

90-140

1000

UL, CSA, VDE

CMA6090

48-660

.25-90

90-140

1200

UL, CSA, VDE

CMA60110

48-660

.25-110

90-140

1500

UL, CSA

CMA60125

48-660

.25-125

90-140

1750

UL, CSA

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec
24 Vac input versions available (E sufﬁx)

PRG

150Amp

120/240/480 Vac
SCR AC Switch Output
High Steady-State Current
Internal Snubber

Designed for the most demanding application, the PRG SPST-NO Solid State
Relays offer an exceptionally high (150 Arms current rating). They are designed
for a wide range of applications including; high-intensity incandescent lamp
dimming, motor speed control, reversing and switching, heater or pump controls
and more.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release Current

Range

@ 5Vdc

Voltage 1-Cycle

Vrms

Arms

Vdc

Apk

PRGD24150

24-280 .15-150

3-15

1.0

1750

PRGD24150-10

24-280 .15-150

3-15

1.0

1750

PRGD48150

48-530 .15-150

4-15

1.0

1750

PRGD48150-10

48-530 .15-150

4-15

1.0

1750

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release Current

Range

@ 120Vrms Voltage 1-Cycle

Vrms

Arms

Vrms

Apk

PRGA24150

24-280 .15-150

90-140

1750

PRGA24150-10

24-280 .15-150

90-140

1750

PRGA48150

48-530 .15-150

90-140

1750

PRGA48150-10

48-530 .15-150

90-140

1750

-10 sufﬁx denotes random turn-on.

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

53TP

25-50Amp 3 PHASE

120/240/480 Vac
SCR AC Switch Output
LED Status Indicator

Three-phase solid state relays switch up to 530 Vrms directly to loads such as
motors, transformers, heating elements, etc. Available with either AC or DC input
(coil) control in zero-voltage or random turn-on switching versions (add sufﬁx -10).
For 24Vac Control (add sufﬁx E).

Line

Load*

Control Control

Must Surge*

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

D53TP25D

48-530

.05-25

3-32

1.0

250

UL, CSA, VDE

D53TP50D

48-530

.05-50

3-32

1.0

625

UL, CSA, VDE

D53DP25D

48-530

.05-25

4-32

1.0

250

UL, cUL, VDE

D53DP50D

48-530

.05-50

4-32

1.0

625

UL, cUL, VDE

Line

Load*

Control Control

Must Surge*

Voltage

Current

Voltage

Current

Release

Current

Range

@ 120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

A53TP25D

48-530

.05-25

90-280

2.2

10.0

250

UL, CSA, VDE

A53TP50D

48-530

.05-50

90-280

2.2

10.0

625

UL, CSA, VDE

A53DP25D

48-530

.05-25

90-280

10.0

250

UL, cUL, VDE

A53DP50D

48-530

.05-50

90-280

10.0

625

UL, cUL, VDE

* Current and Surge Ratings are per phase.
** DP is two controlled phases with the third connected straight through (A1 - A2).

Operating Temperature Range: 40˚C to 80˚C, Isolation Voltage: 4000 Vrms

Panel Mount Solid State Relays

Dual Relays, Quad Relays

120/240/480 Vac

SCR AC Switch Output
Industry Standard Package
Zero Cross or Random Turn-On

Two (Dual) or four (Quad) independent AC output relays come in a single standard
panel-mount package. Utilizing an AC switch output with internal snubber, relays
provide greater protection against false triggering. Model choices include zero
cross or random turn-on (phase controllable) switching (add sufﬁx -10). For 24Vdc
Control (add sufﬁx E). UL 508A SCCR Approved, consult Crydom for actual ratings.

Duals

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

D2425D

24-280

.15-25

4-15

1.0

250

UL, CSA, VDE

D2440D

24-280

.15-40

4-15

1.0

625

UL, CSA, VDE

H12D4825D

48-530

.15-25

4-15

1.0

250

UL, cUL, VDE

H12D4840D

48-530

.15-40

4-15

1.0

625

UL, cUL, VDE

Quads

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

TD2420Q

24-280

.15-20

4-15

1.0

250

UL, CSA

TD2420Q-10

24-280

.15-20

4-15

1.0

250

UL, CSA

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms (Dual), 2500 Vrms (Quad)

PSD

10-90Amp

120/240/480 Vac
Peak Switching
Internal Snubber

Output consists of an SCR AC switch turning on at the next peak of sinusoidal AC
wave form after the input has been activated. Continuing to conduct normally until
the input is deactivated and then turning off at the next current zero cross.
Suitable for switching transformers and other highly inductive loads where
signiﬁcant inrush current may otherwise cause problems.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

PSD2410

90-280

.04-10

3-32

2.0

1.0

120

UL, cUL

PSD2425

90-280

.04-25

3-32

2.0

1.0

250

UL, cUL

PSD2450

90-280

.04-50

3-32

2.0

1.0

625

UL, cUL

PSD2490

90-280

.04-90

3-32

2.0

1.0

1200

UL, cUL

PSD4810

48-530

.04-10

4-32

1.0

140

PSD4825

48-530

.04-25

4-32

1.0

250

PSD4850

48-530

.04-50

4-32

1.0

625

PSD4890

48-530

.04-90

4-32

1.0

1200

Operating Temperature Range: -40˚C to 80˚C, Isolation Voltage: 4000 Vrms, Minimum Off-State dv/dt: 500V/μsec

DC60

3-7Amp

60 Vdc
DC Bipolar Output
AC or DC Control
Economical Panel Mount Package

The DC60 products provide bipolar transistor DC output switching with high
(4000 Vrms) isolation voltage. Only Crydom offers AC input/DC output relays in this
economical standard panel-mount package.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1 sec.

Vdc

Adc

Vdc

Adc

DC60S3

3-60

.02-3

3.5-32

2.2

1.0

UL, cUL

DC60S5

3-60

.02-5

3.5-32

2.2

1.0

UL, cUL

DC60S7

3-60

.02-7

3.5-32

2.2

1.0

UL, cUL

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1 sec.

Vdc

Adc

Vrms

Adc

DC60SA3

3-60

.02-3

90-280

UL, cUL

DC60SA5

3-60

.02-5

90-280

UL, cUL

DC60SA7

3-60

.02-7

90-280

UL, cUL

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage:4000 Vrms
Normally closed (Form B) versions available (-B sufﬁx)

Panel Mount - DC Output

anel Mount

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

SSC

25Amp

High Voltage, 0-1000 Vdc
Solid State DC Contactor

SSC solid state DC contactors feature IGBT technology for high voltage DC
switching applications.

Line

Load

Control

Must Surge

Voltage

Current

Voltage

Current

Release Current

Range

@12/24/36Vdc Voltage 10 ms

Vdc

Adc

Vdc

Adc

SSC800-25-12

0-800

.02-25

8-16

1.0

SSC800-25-24

0-800

.02-25

20-28

1.0

SSC800-25-36

0-800

.02-25

32-40

1.0

SSC1000-25-12

0-1000

.02-25

8-16

1.0

SSC1000-25-24

0-1000

.02-25

20-28

1.0

SSC1000-25-36

0-1000

.02-25

32-40

1.0

Operating Temperature Range: -30˚C to 80˚C, Isolation Voltage: 2500 Vrms

SSC 800, includes overvoltage protection

Panel Mount Solid State Relays - DC Output

D1D, D2D, D4D, D5D

7-40Amp

0-500 Vdc
MOSFET Output
Low On-State Resistance
Paralleling Capability for Higher Currents

DC output relays feature MOSFET technology for low on-state resistance,
assuring easy paralleling and switching capabilities to 40 amps at 100 Vdc.
Lower current models are also available to 500 Vdc.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

10 ms

Vdc

Adc

Vdc

Adc

D1D07

0-100

.02-7

3.5-32

1.6

1.0

D1D12

0-100

.02-12

3.5-32

1.6

1.0

D1D20

0-100

.02-20

3.5-32

1.6

1.0

D1D40

0-100

.02-40

3.5-32

1.6

1.0

106

D2D07

0-200

.02-7

3.5-32

1.6

1.0

D2D12

0-200

.02-12

3.5-32

1.6

1.0

D2D40

0-200

.02-40

3.5-32

1.6

1.0

106

D4D07

0-400

.02-7

3.5-32

1.6

1.0

D4D12

0-400

.02-12

3.5-32

1.6

1.0

D5D07

0-500

.02-7

3.5-32

1.6

1.0

D5D10

0-500

.02-10

3.5-32

1.6

1.0

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage:2500 Vrms

Heat Transfer Pads

Maximize Thermal Conductivity, 100% Grease-Free

Crydom Heat Transfer Pads offer a clean, easy-to-use and grease-free alternative
to conventional mica or grease while maximizing the thermal conductivity.
Installation is simple, pads are die cut to ﬁt perfectly with Crydom SSRs. To order heat
transfer pad attached to panel mount relays, add sufﬁx “H” to part number.

TP01

All Single Phase Panel Mount SSRs

TP03

Three Phase (53TP)

and Auxiliary Function Modules and
M50 Power Modules, non-adhesive

Protective Covers

KS100, KS300, KS100-SMR

TP01, TP03, TPEZ, TPCM

Protects Terminals for Safety
Custom Fit for Most Crydom SSRs

Made of durable, clear polycarbonate, these
removable covers provide additional protection from
electrical shock by covering the SSR terminals.

KS100

Standard Package, Single Phase SSRs

KS300

Three Phase (53TP)

KS100-SMR

SMR, SMR-6 Series and MC Series

SSR Filters

Single and Three Phase

Suppresses EMI Noise
Simple Installation

All AC Solid State Relays generate low frequency
thyristor noise which may exceed some industrial
standards (e.g. EN50061) at the lower end of the
frequency spectrum (150-250kHz). Crydom’s
patented ﬁlter design connects easily and offer up to
50% reduction in thyristor noise

1F25

SSR Filter - Single Phase

3F20

SSR Filter - Three Phase (53TP)

3F20-4

SSR Filter - Three Phase (with neutral)

anel Mount

D06D

60-100Amp

60 Vdc
DC MOSFET Output
Low On-State Resistance

The D06D products feature MOSFET technology and the proven durability of
the D1D models with up to 100 Amps output in a single industry standard package.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

10 ms

Vdc

Adc

Vdc

Adc

D06D60

0-60

.005-60

3.5-32

1.6

1.0

180

D06D80

0-60

.005-80

3.5-32

1.6

1.0

220

D06D100

0-60

.005-100 3.5-32

1.6

1.0

270

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage:2500 Vrms

TPEZ

TPCM

CMD, CMA

Crydom

Heat Sinks

Meet or Exceed Crydom’s Heat
Dissipation Requirements
Pre-Drilled and Tapped

Thermal management is a important consideration in the use of panel solid
state relays due to the contact dissipation (typically 1W per Amp). Crydom
heat sinks are engineered to match the heat dissipation requirements of Crydom
solid state relays. Pre-drilled and tapped for quick, seamless installations.

Panel Mount - Accessories

K/W

SSR

Mounting

2.1
1.5
0.7
0.4

HS-1
HS-2
HE-54
HE-90

Single Phase
Single Phase
Single Phase
(3) Single Phase or

(1) Three Phase

Panel Mount

HS8.1
HS8.3
HE13DR

2.0
3.5
0.8

Single Phase
Single Phase
(3) Single Phase or

(1) Three Phase

DIN Mount

MS1

1.4

Single Phase

DIN Mount

MS2

2.5

Single Phase

DIN Mount

MS3

1.0

(3) Single Phase or (1) Three Phase

DIN Mount

MS4

4.5

Single Phase

DIN Mount

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

DIN rail Mount Solid State Relays

CKR

10-30Amp

120/240/480/600 Vac
SCR AC Switch Output
Zero Cross or Random Turn-on
LED Status Indicator
Slim Package, Only 22mm Wide

Crydom’s proprietary thermal management
technology makes for an efﬁcient and compact
package. Safe and easy-to-use box clamp terminals
with integral heat sink complete the package. Model
choices include zero-voltage or random turn-on
(phase controllable) switching (add sufﬁx -10).
UL 508A SCCR Approved, consult Crydom for actual
ratings.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 12Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CKRD2410

24-280

.15-10

4.5-32

1.0

120

UL, CSA, VDE

CKRD2420

24-280

.15-20

4.5-32

1.0

250

UL, CSA, VDE

CKRD2430

24-280

.15-30

4.5-32

1.0

625

UL, CSA, VDE

CKRD4810

48-530

.15-10

4.5-32

1.0

120

UL, CSA, VDE

CKRD4820

48-530

.15-20

4.5-32

1.0

250

UL, CSA, VDE

CKRD4830

48-530

.15-30

4.5-32

1.0

625

UL, CSA, VDE

CKRD6010

48-660

4.0-32

1.0

120

UL, CSA, VDE

CKRD6020

48-660

4.0-32

1.0

250

UL, CSA, VDE

CKRD6030

48-660

4.0-32

1.0

625

UL, CSA, VDE

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

CKRA2410

24-280

.15-10

90-280

2 10

120

UL, CSA, VDE

CKRA2420

24-280

.15-20

90-280

250

UL, CSA, VDE

CKRA2430

24-280

.15-30

90-280

625

UL, CSA, VDE

CKRA4810

48-530

.15-10

90-280

120

UL, CSA, VDE

CKRA4820

48-530

.15-20

90-280

250

UL, CSA, VDE

CKRA4830

48-530

.15-30

90-280

625

UL, CSA, VDE

CKRA6010

48-660

90-280

120

UL, CSA, VDE

CKRA6020

48-660

90-280

250

UL, CSA, VDE

CKRA6030

48-660

90-280

625

UL, CSA, VDE

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 4000 Vrms
24Vac input versions available (E sufﬁx)

HPF

20-30Amp

120/240/480 Vac
SCR AC Switch Output
Zero Cross or Random Turn-on
Low Leakage

The HPF series offers an efﬁcient and compact
package capable of switching up to 660Vac. Box
clamp terminals with integral heat sink complete the
package. Options include zero-voltage or random
turn-on (R sufﬁx) phase controllable switching.

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

HPF240D20

12-280

.15-20

4-32

1.0

250

UL, CSA

HPF240D30

12-280

.15-30

4-32

1.0

625

CSA

HPF480D20

48-660

.15-20

4.5-32

1.0

250

CSA

HPF480D30

48-660

.15-30

4.5-32

1.0

625

CSA

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 4000 Vrms

CMR

35-65Amp

120/240/480/600 Vac
SCR AC Switch Output
Zero Cross or Random Turn-on

Crydom’s Coolpak™ integral heat sink technology
creates a package that is efﬁcient with the
convenience of DIN rail mounting. These SPST-NO
solid state relays offer box clamp connections for
safety and ease-of-use. The on-board LED provides
visible status indication. Model choices include
zero-voltage or random turn-on (phase controllable)
switching (add sufﬁx -10). UL 508A SCCR Approved,
consult Crydom for actual ratings

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

Vrms

Arms

Vdc

Apk

CMRD2435

24-280

.15-35

3-32

1.0

250

UL, CSA, VDE

CMRD2445

24-280

.15-45

3-32

1.0

625

UL, CSA, VDE

CMRD2455

24-280

.25-55

3-32

1.0

1000

UL, CSA, VDE

CMRD2465

24-280

.25-65

3-32

1.0

1200

UL, CSA, VDE

CMRD4835

48-530

.15-35

4-32

1.0

250

UL, CSA, VDE

CMRD4845

48-530

.15-45

4-32

1.0

625

UL, CSA, VDE

CMRD4855

48-530

.25-55

4-32

1.0

1000

UL, CSA, VDE

CMRD4865

48-530

.25-65

4-32

1.0

1200

UL, CSA, VDE

CMRD6035

48-660

.15-35

4-32

1.0

250

UL, CSA, VDE

CMRD6045

48-660

.15-45

4-32

1.0

625

UL, CSA, VDE

CMRD6055

48-660

.25-55

4-32

1.0

1000

UL, CSA, VDE

CMRD6065

48-660

.25-65

4-32

1.0

1200

UL, CSA, VDE

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@120Vrms Voltage

1-Cycle

Vrms

Arms

Vrms

Apk

CMRA2435

24-280

.15-35

90-140

250

UL, CSA, VDE

CMRA2445

24-280

.15-45

90-140

625

UL, CSA, VDE

CMRA2455

24-280

.25-55

90-140

1000

UL, CSA, VDE

CMRA2465

24-280

.25-65

90-140

1200

UL, CSA, VDE

CMRA4835

48-530

.15-35

90-140

250

UL, CSA, VDE

CMRA4845

48-530

.15-45

90-140

625

UL, CSA, VDE

CMRA4855

48-530

.25-55

90-140

1000

UL, CSA, VDE

CMRA4865

48-530

.25-65

90-140

1200

UL, CSA, VDE

CMRA6035

48-660

.15-35

90-140

250

UL, CSA, VDE

CMRA6045

48-660

.15-45

90-140

625

UL, CSA, VDE

CMRA6055

48-660

.25-55

90-140

1000

UL, CSA, VDE

CMRA6065

48-660

.25-65

90-140

1200

UL, CSA, VDE

Operating Temperature Range: -40˚C to 80˚C Isolation Voltage: 4000 Vrms
24Vac input versions available (E sufﬁx)

MS11

LED Status Indicator (Input)
DIN rail Mount for PCB products

Line

Load

Control

Must

Surge

Must

Surge

Voltage

Current

Curre nt Release Current

Range

@ 5/24Vdc Volt age 1-Cycle

AC Output

Vrms

Arms

Vdc

Apk

MS11-CX240D5

12-280

.06 -5

3-15

1.0

250

MS11-CXE240D5

12-280

.06 -5

15-32

1.0

250

Line

Load

Control

Voltage

Curre

Curre nt

Release Current

Range

@5Vdc

Voltage

10ms

DC Output

Vdc

Adc

Vdc

Apk

MS11-CMX60D5

0-60

0-5

3-10

1.0

MS11-CMX60D10

0-60

0-10

3-10

1.0

100

MS11-CMX100D6

0-100

0-6

3-10

1.0

100

MS11-CMX200D3

0-200

0-3

3-10

1.0

Designed speciﬁcally for a variety of Crydom’s PCB mount solid state relays, the
MS11 provides a secure and convenient DIN rail mount with an input status LED.

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

DIN R

ail Mount

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

DSD, DLD

Solid State Time Delay Control Relay

10-50Amp
120/240 Vac
SCR AC Switch Output
Externally Adjustable

Line

Load

Control Control

Must Surge

Voltage

Current

Voltage

Current

Release

Current

Range

@ 5Vdc

Voltage

1-Cycle

These “on-operate” (pull-in) time-delay solid state relays are housed in a single
industry standard package. AC output is controlled by a DC input and has an externally
adjustable time delays. Choices include models with two time-delay ranges (DSD
models: 0.1 sec to 8.3 sec.; DLD models: 1.6 sec. to 133 sec.)

Vrms

Arms

Vdc

Apk

DSD2410

48-280

.04-10

3.5-15

3.4

1.0

120

DSD2425

48-280

.04-25

3.5-15

3.4

1.0

250

DSD2450

48-280

.04-50

3.5-15

3.4

1.0

625

DLD2410

48-280

.04-10

3.5-15

3.4

1.0

120

DLD2425

48-280

.04-25

3.5-15

3.4

1.0

250

DLD2450

48-280

.04-50

3.5-15

3.4

1.0

625

Timing Resistances

0 (Short) 10KΩ

100KΩ

470KΩ

1.0MΩ

DSD

0.10 sec 0.19 sec 0.94 sec 4.0 sec

8.3 sec

DLD

1.6 sec

3.1sec

15 sec

64 sec

133 sec

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

SST

Solid State Soft-Start
Control Module/Relay

10-90Amp
SCR AC Switch Output
120/240 Vac

Line

Load

Control Control

Must Surge

Crydom

Voltage

Current

Voltage

Current

Release

Current

Solid State

Range

@ 5Vdc

Voltage

1-Cycle

Relay (Incl.)

Vrms

Arms

Vdc

Apk

Part No.

SST120*

90-140

3.5-10

1.6

1.0

none

10SST120

90-140

.04-10

3.5-10

1.6

1.0

120

D2410-10

25SST120

90-140

.04-25

3.5-10

1.6

1.0

250

D2425-10

50SST120

90-140

.04-50

3.5-10

1.6

1.0

625

D2450-10

SST240*

180-280 *

3.5-10

1.6

1.0

none

10SST240

180-280 .04-10

3.5-10

1.6

1.0

120

D2410-10

25SST240

180-280 .04-25

3.5-10

1.6

1.0

250

D2425-10

50SST240

180-280 .04-50

3.5-10

1.6

1.0

625

D2450-10

75SST240

180-280 .04-75

3.5-10

1.6

1.0

1000

D2475-10

90SST240

180-280 .04-90

3.5-10

1.6

1.0

1200

D2490-10

* Control Module Only, Must be used with -10 (Series 1) DC input relay
Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

Control Relays

Solid State Control Relays

Crydom’s recognized global leadership in solid-state relays
(SSRs) is taken a step further with our extensive line of solid
state control relays. They can incorporate control circuitry,
intelligence, indication and feedback to an SSR function, further
enhancing the cost-performance beneﬁts for the end user.
Housed in familiar electrically isolated-base packages, many
commonly used power switching/control functions are
incorporated into a single relay. Crydom’s renowned advanced
thermal management techniques are utilized to ensure ease of
mounting and cooling for long life and reliable operation.
Signiﬁcant cost savings are realized from reductions in design,
volume, cooling, ﬁled maintenance, parts count, acquisition and
inventory costs.

Typical Applications

Appliances
Blow Molding Equipment
Centrifuges
Closed Loop Control
Conveyors
DC-choppers
Elevator controls
Furnaces
Gaming Equipment
Heater controls
HVAC controls
Incubators
Inverters
Lamp controls
Light Dimmers
Marine Equipment
Medical electronics
Motor controls, AC
Motor controls, Induction

Custom Designs

Crydom’s Sales and Technical Support teams will work closely
with you to deﬁne and develop customized solutions for your
unique requirements. We can help you get that competitive
edge necessary to be a leader in your industry. In-house
capabilities include ceramic substrate production, SMT
(surface mount technology) placement/insertion robotics
assembly and elevated/low temperature monitored testing. All
this interprets into fast-track design, prepare prototypes, test,
evaluate, adjust and ﬁnalize as necessary to achieve the stated
performance criteria. Upon ﬁnal customer approval we can
quickly gear up to meet your production schedules in our
ISO9001 certiﬁed manufacturing environment.

Motor controls, Universal
Motor-starter
Ovens
Polishing Equipment
Power supplies
Printing Equipment
Pump Controls
Reﬂow Soldering
Slow-start controls
Steamers
Sterilizers
Temperature Controls
Three-phase switching
Traction
Transformer Switching
Transportation
UPS systems
Welding

UL, cUL

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Models SST120 and SST240 control modules gradually apply power to the load when
energized by the control voltage. They must be used with Crydom Series 1 random
turn-on solid state relays. Consult factory for SST wiring diagrams and about use with
480 Vac loads. For a complete set (control module and solid state relay) order
10SST120, 25SST120, etc.

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

Solid State Control Relays

LPCV

Solid State Linear Proportional
Control Relay

15-110Amp
120/240 Vac
SCR AC Switch Output
Precise Proportional Load Control

L
Voltage

Current

Control

Turn-On

Input

Current

Range

Threshold

Impedance 1-Cycle

5LPCV2415

20-300

.10-15

0-5Vdc

.25Vdc

12.7K

150

5LPCV2425

20-300

.10-25

0-5Vdc

.25Vdc

12.7K

250

5LPCV2440

20-300

.10-40

0-5Vdc

.25Vdc

12.7K

625

5LPCV2475

20-300

.15-75

0-5Vdc

.25Vdc

12.7K

1000

5LPCV24110

20-300

.20-110 0-5Vdc

.25Vdc

12.7K

1500

10LPCV2415

20-300

.10-15

0-10Vdc .5Vdc

25K

150

10LPCV2425

20-300

.10-25

0-10Vdc .5Vdc

25K

250

10LPCV2440

20-300

.10-40

0-10Vdc .5Vdc

25K

625

10LPCV2475

20-300

.15-75

0-10Vdc .5Vdc

25K

1000

10LPCV24110

20-300

.20-110 0-10Vdc .5Vdc

25K

1500

20LPCV2415

20-300

.10-15

4-20mA 4.5mA

460

150

20LPCV2425

20-300

.10-25

4-20mA 4.5mA

460

250

20LPCV2440

20-300

.10-40

4-20mA 4.5mA

460

625

20LPCV2475

20-300

.15-75

4-20mA 4.5mA

460

1000

20LPCV24110

20-300

.20-110 4-20mA 4.5mA

460

1500

Operating Temperature Range: -30˚C to 80˚C, Isolation Voltage: 2500 Vrms

CPV

Solid State Phase Control
Module/Relay

10-90Amp
120/240 Vac
0-5Vdc Phase Control

Line

Load

Logic

Control Surge

Crydom

Voltage

Current

Supply

Voltage

Current

Solid State

Range

Voltage

Range

1-Cycle

Relay (Incl.)

Models CPV120 and CPV240 solid state control modules provide control of the
phased turn-on of a solid state relay, in response to the application of a 0-5 Vdc
control signal. They must be used with Crydom Series 1 random turn-on solid
state relays. Consult factory for wiring diagrams and about use with 480 Vac
loads. For acomplete set (control relay and solid state relay) order 10CPV120,
25CPV120, etc.

Vrms

Arms

Vdc

Apk

Part No.

CPV120*

90-140

3.5-10

0-5

none

10CPV120

90-140

.04-10

3.5-10

0-5

120

D1210-10

25CPV120

90-140

.04-25

3.5-10

0-5

250

D1225-10

40CPV120

90-140

.04-40

3.5-10

0-5

625

D1240-10

CPV240*

180-280 *

3.5-10

0-5

none

10CPV240

180-280 .04-10

3.5-10

0-5

120

D2410-10

25CPV240

180-280 .04-25

3.5-10

0-5

250

D2425-10

50CPV240

180-280 .04-50

3.5-10

0-5

625

D2450-10

75CPV240

180-280 .04-75

3.5-10

0-5

1000

D2475-10

90CPV240

180-280 .04-90

3.5-10

0-5

1200

D2490-10

* Control Module Only, Must be used with -10 (Series 1) DC input relay
Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 4000 Vrms

RPC

Solid State Proportional Control

15-40Amp
120/240/480 Vac
Economical Potentiometer Control

L
Voltage

Current

Off-State Potentiometer Potentiometer Current

Range

Leakage

Resistance

Wattage

1-Cycle

The RPC series provides a cost effective method of controlling power in many
different application such as heaters or incandescent lamps. A customer provided
potentiometer is all that is required for control. All RPC products are supplied with
KS100 protective cover.

Vrms

Arms

Ohms

Apk

RPC1215

90-130

.07-15

150K

150

RPC1225

90-130

.08-25

150K

250

RPC1240

90-130

.09-40

150K

625

RPC2415

200-240 .07-15

1 Meg

150

RPC2425

200-240 .08-25

1 Meg

250

RPC2440

200-240 .09-40

1 Meg

625

RPC4815

400-480 .07-15

1 Meg

150

RPC4825

400-480 .08-25

1 Meg

250

RPC4840

400-480 .09-40

1 Meg

625

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms (Load to baseplate only)
Note: Control to load is not isolated, exercise care in handling this product to avoid the risk of electric shock.

PCV

Solid State Analog Input Power
Control Relays

15-90Amp
120/240 Vac
SCR AC Switch Output

The PCV Series solid state proportional control relays are self contained power control
relays integrating a complete phase ﬁred logic control system and a solid state
relay in the same standard package.

Line

Load

Control

Surge

Voltage

Current

Off-State Voltage

Current

Range

Leakage

Range

@ 5Vdc

1-Cycle

Vrms

Arms

Vdc

Apk

7PCV2415

100-240

.15-15

2-7

150

7PCV2425

100-240

.15-25

2-7

250

10PCV2415

100-240

.15-15

2-10

150

10PCV2425

100-240

.15-25

2-10

250

10PCV2450

100-240

.15-50

2-10

625

10PCV2475

100-240

.15-75

2-10

1000

10PCV2490

100-240

.15-90

2-10

1200

Operating Temperature Range: -30˚C to 80˚C Isolation Voltage: 2500 Vrms

Control Relays

UL, CSA
UL, CSA
UL, CSA
UL, CSA
UL, CSA
UL, CSA
UL, CSA

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

The LPCV solid state linear proportional control relays control loads up to 110 amps.
Changes in the input signal linearly vary the ﬁring angle of the thyristor load control
device.
Control circuitry and power switch are in a single package.

PS-120 (120V), PS-240 (240V)

These power supplies are designed for use with the Series

LPCV control relays to provide the 20Vac required in addition to the control voltage.

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

The Crydom MCPC series of Proportional Control Relays
incorporate a complete phase-ﬁred logic system and Solid
State Relay in one small industry standard package. The MCPC
uses microprocessor control relay logic, accepts a wide range
input logic power supply, provides an output load status
indicator, and ﬁve modes of analog control input along with an
Enable/Disable control.

The MCPC does not require any calibration adjustment, is
optically isolated to 4000Vrms, includes an internal snubber
network, and is available in load ratings up to 90A and 530Vac.
The Crydom MCPC series is particularly suited to applications
such as tungsten lamp dimming, vibratory feeders, universal
motor control, and resistive heating element control.

The Crydom MCTC is a unique self-contained state of the art basic
Temperature Control Relay that combines all the necessary functions
into one easy to set up and use standard size package. The MCTC
is ideal for temperature control users that do not need multiple
built-in options, displays, and functions that they will never use.

The MCTC requires only a single, non-regulated low current DC
source, (10-32Vdc at 32mA max.), and a type J or K thermocouple,
to be able to accurately control heater and cooling compressor
loads up to 530Vac at 90A. The unit incorporates an internally
compensated thermocouple input, 5 available temperature ranges
including an inverse function refrigeration version, with adjustable
setpoint using analog low voltage or 4-20mA inputs, separate
output enable/disable control, and built in Crydom Solid State Relay
technology for load control. With integrated zerocross burst ﬁring,
and proportional derivative control to avoid set-point overshoot†,
the unit also includes 2 LED status indicators for visual reference of
operation and setpoint conditions.

MCTC

Solid State Temperature
Control Relay

25-90Amp
120/480 Vac
AC Output

MCTC2425JLA

24-280

.15-25

100 to 500

0-5

MCTC2450JLA

24-280

.15-50

100 to 500

0-5

MCTC2490JLA

24-280

.15-90

100 to 500

0-5

MCTC2425JHB

24-280

.15-25

300 to 700

0-7

MCTC2450JHB

24-280

.15-50

300 to 700

0-7

MCTC2490JHB

24-280

.15-90

300 to 700

0-7

MCTC2425JHC

24-280

.15-25

300 to 700

0-10

MCTC2450JHC

24-280

.15-50

300 to 700

0-10

MCTC2490JHC

24-280

.15-90

300 to 700

0-10

MCTC4825JLA

48-530

.15-25

100 to 500

0-5

MCTC4850JLA

48-530

.15-50

100 to 500

0-5

MCTC4890JLA

48-530

.15-90

100 to 500

0-5

MCTC4825JHB

48-530

.15-25

300 to 700

0-7

MCTC4850JHB

48-530

.15-50

300 to 700

0-7

MCTC4890JHB

48-530

.15-90

300 to 700

0-7

MCTC4825JHC

48-530

.15-25

300 to 700

0-10

MCTC4850JHC

48-530

.15-50

300 to 700

0-10

MCTC4890JHC

48-530

.15-90

300 to 700

0-10

Other ranges available

MCPC

Solid State Proportional
Control Relay

25-90Amp
120/480 Vac
AC Output

Temperature Control/SSR in One Package
Direct J or K Internally Compensated Thermocouple Input
Four Heating Ranges Available with Burst Fire Control
Setpoint is Adjustable by Voltage or 4-20mA Control
Separate Output Enable/Disable Control
SCR Based Output Load Switching
Open Thermocouple Protection Feature
One Refrigeration Range Available with Built-In 2 Minute Short-Cycle
Protection

Phase Angle Control/SSR in One Package
Low Voltage, Current or Potentiomer Control

Output Status Indicator (Load Open, No Voltage)

0-100% Control Range

Separate Output Enable/Disable Control
SCR Based Output Load Switching
Internal Snubber Network

Line Voltage

Range

Load Current

Range

Thermocouple

Type

Temp.

Range °F

Setup Input

Range

Vrms

Arms

Vdc

MCPC2425A

180-280

.15-25

0-5

MCPC2450A

180-280

.15-50

0-5

MCPC2490A

180-280

.15-90

0-5

MCPC2425B

180-280

.15-25

0-7

MCPC2450B

180-280

.15-50

0-7

MCPC2490B

180-280

.15-90

0-7

MCPC2425C

180-280

.15-25

0-10

MCPC2450C

180-280

.15-50

0-10

MCPC2490C

180-280

.15-90

0-10

MCPC4825A

330-530

.15-25

0-5

MCPC4850A

330-530

.15-50

0-5

MCPC4890A

330-530

.15-90

0-5

MCPC4825B

330-530

.15-25

0-7

MCPC4850B

330-530

.15-50

0-7

MCPC4890B

330-530

.15-90

0-7

MCPC4825C

330-530

.15-25

0-10

MCPC4850C

330-530

.15-50

0-10

MCPC4890C

330-530

.15-90

0-10

Other ranges available

Line Voltage

Range

Load Current

Range

Analog

Input

Range

Control Relays

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

Part Number Nomenclature

Proportion Load
Voltage Input
A:

0-5Vdc

0-7Vdc

0-10Vdc

4-20mA

Internal Potenciometer

Line Voltage
12:

48-140Vrms

24:

180-280Vrms

48:

330-530Vrms

Product Type

PC:

Proportional

Controller

Rated Current
25:

25 Amps

50:

50 Amps

90:

90 Amps

SERIES

Part Number Nomenclature

Temp. Range
L:

100°F to 500°F, 38°C to 260°C

300°F to 700°F, 149°C to 371°C

VH:

500°F to 900°F, 260°C to 482°C

EH:

700°F to 1100°F, 371°C to 593°C

R :

+100°F to -100°F, +38°C to -73°C

Thermocouple
Type
J:

Type J

Type K

Setpoint Input
A:

0-5Vdc

0-7Vdc

0-10Vdc

D: 4

-30mA

Aditional Features
E:

On board

regulated 5Vdc
source included,
available only
with Setpoint
Input

(0-5Vdc)

Line Voltage
24:

180-280Vrms

48:

330-530Vrms

Product Type
TC:

Temperature

Controller

Rated Current
25:

25 Amps

50:

50 Amps

90:

90 Amps

SERIES

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

MCS

Solid State Soft-Start / Soft-Stop
Control Relay

25-90Amp
120/480 Vac
AC Output

MCBC

Solid State Burst Fire
Control Relay

25-90Amp
120/480 Vac
AC Output

The MCST, MCSP and MCSS series of controls is designed to
provide adjustable surge reducing soft-start and soft-stop control
for any load which would beneﬁt from a gradual application or
shutdown of power, and provide Crydom SSR switching within one
package.

The MCS Control Relays are available with either soft-start, or soft-stop
functions separately, or as a combined soft-start/soft-stop control.
With adjustable ramp times from 100ms to 10 seconds in two
ranges, these controls are ideal for reducing starting current
surges in motors, in preventing saturation when switching
transformers, or in reducing reverse EMF surges when de-
energizing large inductive loads. Incorporating 4000 volt isolation
from input to output, the MCS series allows real time adjustment of
the ramp rates from a remote source using analog voltage or
current control. Once the desired ramp rate is set using the analog
input, a simple digital signal applied to the ON/OFF control input will
operate the control. The MCS is also available with a built-in
potentiometer for use where remote or continuous adjustment is
not needed.

Soft-Start/Stop Control and SSR in One Package
Microcontroller Based Technology
Adjustable Ramp Rates
Low Voltage, 4-20mA, or Potentiometer Control
LED Status Indicator
SCR Based Output Load Switching
Built-In Internal Snubber

The Crydom MCBC series of Burst ﬁre Controls, incorporate a
complete burst Fire logic system and Solid State Relay in one small
industry standard package. The MCBC uses microprocessor
control relay logic, accepts a wide range input logic power supply,
provides an output load status indicator, and ﬁve modes of analog
input control along with an Enable / Disable control.

With 2 time base periods available, (10 and 20 AC cycles), the
MCBC provides a smooth proportional control that minimizes
electrical noise by utilizing zero-cross detection and switching,
ﬁring only complete AC cycles.

The MCBC does not require any calibration adjustment, is optically
isolated up to 4000 Vrms, and is available in load rating up to 90 A
and 530 Vac. In addition, specialized AC Phase Detection Circuitry
allows the MCBC to be connected to only one side of the load,
minimizing installation wiring.

The MCBC series is particularly suited to electrical heating
applications where the electrical noise generated by typical phase
angle controller can not be tolerated.

Vrms Arms Vdc Sec.

MCST2425AS

180-280

.15-25

0-5

.1-1

Soft Start

MCST2450AS

180-280

.15-50

0-5

.1-1

Soft Start

MCST2490AS

180-280

.15-90

0-5

.1-1

Soft Start

MCSP2425BM

180-280

.15-25

0-7

1-10

Soft Stop

MCSP2450BM

180-280

.15-50

0-7

1-10

Soft Stop

MCSP2490BM

180-280

.15-90

0-7

1-10

Soft Stop

MCSS2425CM

180-280

.15-25

0-10

1-10

Soft Start/Stop

MCSS2450CM

180-280

.15-50

0-10

1-10

Soft Start/Stop

MCSS2490CM

180-280

.15-90

0-10

1-10

Soft Start/Stop

MCST4825AS

300-530

.15-25

0-5

.1-1

Soft Start

MCST4850AS

300-530

.15-50

0-5

.1-1

Soft Start

MCST4890AS

300-530

.15-90

0-5

.1-1

Soft Start

MCSP4825BM

300-530

.15-25

0-7

1-10

Soft Stop

MCSP4850BM

300-530

.15-50

0-7

1-10

Soft Stop

MCSP4890BM

300-530

.15-90

0-7

1-10

Soft Stop

MCSS4825CM

300-530

.15-25

0-10

1-10

Soft Start/Stop

MCSS4850CM

300-530

.15-50

0-10

1-10

Soft Start/Stop

MCSS4890CM

300-530

.15-90

0-10

1-10

Soft Start/Stop

Other ranges available

Line Voltage

Range

Load Current

Range

Type

Analog

Input

Range

Ramp

Time

On/Off

Burst Fire Control/SSR in One Package
Low Voltage, Current, or Potentiometer Control
Output Status Indicator (Load Open, No Voltage)
0-100% Control Range
2 Time Base Periods Available
Separate Output Enable / Disable Control
SCR Based Output Load Switching
Internal Snubber Network Included

Vrms

Arms

Vdc

MCBC2425A

180-280

.15-25

0-5

MCBC2450A

180-280

.15-50

0-5

MCBC2490A

180-280

.15-90

0-5

MCBC2425B

180-280

.15-25

0-7

MCBC2450B

180-280

.15-50

0-7

MCBC2490B

180-280

.15-90

0-7

MCBC2425C

180-280

.15-25

0-10

MCBC2450C

180-280

.15-50

0-10

MCBC2490C

180-280

.15-90

0-10

MCBC4825A

330-530

.15-25

0-5

MCBC4850A

330-530

.15-50

0-5

MCBC4890A

330-530

.15-90

0-5

MCBC4825B

330-530

.15-25

0-7

MCBC4850B

330-530

.15-50

0-7

MCBC4890B

330-530

.15-90

0-7

MCBC4825C

330-530

.15-25

0-10

MCBC4850C

330-530

.15-50

0-10

MCBC4890C

330-530

.15-90

0-10

Other ranges available

Line Voltage

Range

Load Current

Range

Analog

Input

Range

Control Relays

Other Crydom products and competitive part number cross-reference available at:

www.crydom.com

Part Number Nomenclature

Ramp Time On/Off
S:

100ms - 1 sec.

1 sec. - 10 sec.

Analog Input
A:

0-5Vdc

0-7Vdc

0-10Vdc

4-20mA

Potentiometer

Line Voltage
12:

48-140Vrms

24:

180-280Vrms

48:

330-530Vrms

Product Type

ST:

Soft Start

SP:

Soft Stop

SS:

Soft Start/Stop

Rated Current
25:

25 Amps

50:

50 Amps

90:

90 Amps

SERIES

Part Number Nomenclature

Time Base Period
F:

10 AC Cycles

20 AC Cycles

Analog Control Signal
A:

0-5Vdc

0-7Vdc

0-10Vdc

4-20mA

Internal Potentiometer

Line Voltage
12:

48-140Vrms

24:

180-280Vrms

48:

330-530Vrms

Product Type

BC:

Burst Fire

Controller

Rated Current
25:

25 Amps

50:

50 Amps

90:

90 Amps

SERIES

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

Glossary of Terms

Terminology

Control Voltage Range

- the range of voltage when applied across the SSR Input terminals,

will maintain an ON condition across the Output terminals.

Control Current

- Current drain on the control source at specified SSR input voltages and

On/Off conditions.

dv/dt -

Maximum rate of rise of voltage applied across the output terminals that the SSR can

withstand without turning ON.A characteristic of thyristors used in AC SSRs.

dv/dt Off State (Static)

- Specified as a minimum dv/dt withstand capability of SSRs in the

off or blocking state.

Form, Contact

- Contact or output configuration, as in Form A for Single Pole, Single Throw,

Normally Open (SPST-NO)

Holding Current

- The minimum load current required to maintain a thyristor in its

conducting state.

Input Current (Maximum)

- Current drain on the control source at specified SSR input

voltages and On/Off conditions.

Isolation Voltage

- The value of dielectric strength measured between the input and output,

input to base, or output to base.

LED

- Light Emitting Diode, commonly used for status indication on some models of SSRs

and as the light source in a photocoupler .

Line Voltage Range

- The range of voltages applied to the output, over which the SSR will

continuously block or switch and otherwise perform as specified.

Load Current Range

- The range of current applied to the output, over which the SSR will

continuously block or switch and otherwise perform as specified.

MOSFET

- Metal Oxide Semiconductor Field-Effect Transistor.The control electrode (gate) is

generally isolated from the source electrode by a layer of silicon oxide. A voltage applied
between the gate and the source will provide a current flow between the drain and the source.

Normally Open (NO)

- A contact or SSR output that is open when no control power is

present at the input (coil).This is a Form A device.

Normally Closed (NC)

- A contact or SSR output that is closed when no control power is

present at the input (coil).This is a Form B device.

Off-State Voltage

- The maximum transient voltage that an SSR output can withstand

without malfunction or damage.

On-State Voltage (Maximum)

- The peak voltage that appears across the SSR output

terminals at full rated load current.

Phase Control

- Turn-On of a non-zero switching SSR (each half cycle), at a phase angle

determined by the control signal source.

Photocoupler/Isolator

- A combination of light-emitting diode and light-sensitive

semiconductor used to transmit information optically while providing electrical isolation.
Commonly used isolating element for coupling the control signal to the output in an SSR.

Power Dissipation

- The maximum average power dissipation (Watts) resulting from the

effective voltage drop (power loss) in the SSR output semiconductor.

Rectifier

- Asemiconductor used to convert AC power to DC.It allows current to flow in one

direction (forward) and prevents the flow of current in the opposite directions (reverse).

SCR

- Silicon Controlled Rectifier. Unidirectional semiconductor of the thyristor family with

latching properties.

Snubber

- A resistor-capacitor combination placed across the SSR output terminals to

reduce dv/dt and transients in thyristor circuits.

Solid State Relay (SSR)

- Isolated On-Off switch composed of non-moving electrical parts

(primarily semiconductors, transformers and passive components).

Surge Current -

The maximum allowable SSR momentary current flow for a specific time

duration.Typically specified as a peak value for one line cycle for AC.

Thermal Resistance

- Expressed in degrees Celsius per watt (˚C/W).This value defines the

temperature gradient in the path between the power generated in the output SSR
semiconductor and the final dissipating medium (heat sink/air).

Thyristor -

A semiconductor bistable device comprising three or more junctions (PNPN,

etc).The generic name for a family of gate controlled switches including SCRs and triacs.

Triac

- Bidirectional semiconductor of the thyristor family. Performance is similar to that of

an inverse pair of SCRs, triggered by a single gate electrode.

Trigger

- To turn on an SCR or triac.

Turn-Off Voltage (Must Release)

- The voltage applied to the SSR input at or below which

the output must be in the Off-State (Normally-Open).

Turn-On Voltage (Must Operate)

- The voltage applied to the SSR input at or above which

the output must be in the on state (Normally-Open).

Crydom offers a broad line of digital I/O modules and mounting
boards. Designed for long, reliable service in demanding industrial
environments, these modules provide optical isolation between
logic-level control systems and external loads, such as motors,
valves, solenoids, resistive heating elements, etc.. Output modules
within the offer can switch loads up to 5 Amps at 24-280 VAC (Form
A, SPST-NO, zero-crossing output), or up to 5A/3A at 100/200 VDC
(Form A SPST-NO). Input modules provide digital feedback to the
control system when the load is energized and are available with
inputs up to 280Vac / 48 VDC, with either a 5 VDC or 24 VDC logic-
level output.

0.6" Modules

AC Inputs for 24 V, 120 V, 240 V
DC Inputs for 3.3 to 32 V, 10 to 48 V
4 kV Optical Isolation
Plugs into 0.6" Mounting boards

M Series

AC Inputs for 24 V, 120 V, 240 V
DC Inputs for 3.3 to 32 V, 10 to 48 V
4 kV Optical Isolation
Plugs into M Series Mounting boards

SM Series

AC Inputs for 24 V, 120 V, 240 V
DC Inputs for 3.3 to 32 V, 10 to 48 V
4 kV Optical Isolation
Plugs into SM Series Mounting boards

C4 Series

Built-in LED Status Indicator
Regulated Supply Voltage
4 kV Optical Isolation
Replaceable 2 AG Type Fuse (output modules)
Plugs into C4 Series Mounting boards

I/O Modules

Industry Standard Packaging
UL Recognized, CSA Certiﬁed,
CE Compliant

Quads

4 Input Circuits per module
AC Inputs for 24 V, 120 V, and 240 V
DC Inputs for 4 to 32 V, 10 to 60 V
4kV Optical Isolation
Plugs into mounting boards for quad-pack modules

O Module

Questions?

Call or e-mail

+1 (877) 502 5500

+44 (0) 1202 606030

sales@crydom.com

sales-europe@crydom.com

Americas

Europe

0.6" Modules
M Series
SM Series
C4 Series
Quads

Number of Modules

Mounting boards available

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com

Crydom is an operation of Custom
Sensors & Technologies (CST), a
business unit of Schneider Electric.

CAT/CR/SF/EN/US

AMERICAS

USA/CANADA

Crydom Inc

2320 Paseo de las Americas,
Suite 201
San Diego CA 92154

sales@crydom.com

support@crydom.com

Sales Support

Tel.: +1 (877) 502 5500

Tech Support

Tel.: +1 (877) 702 7700

tech-europe@crydom.com

Tech Support

Fax: +1 (619) 710 8540

ASIA
PACIFIC

CHINA & HONG KONG

Custom Sensors &
Technologies Asia
(Shanghai) Ltd.

2 Floor, Innovation Building,
No.1009, Yi Shan Road,
Shanghai, 200233
Tel.: +86 (21) 2401 7766
Fax: +86 (21) 6249 0701
sales-cn@crydom.com

EUROPE
MIDDLE EAST
AFRICA

Crydom SSR Ltd

Arena Business Centre
Holyrood, Close
Poole, Dorset BH17 7FJ

Tel.: +44 (0) 1202 606030
Fax: +44 (0) 1202 606035
sales-europe@crydom.com

CST Latinoamerica

SOUTHERN AND

CENTRAL AMERICAN

COUNTRIES

INDIA

SOUTH KOREA

CST Sensors India Pvt Ltd

Unit 1301 and 1302 Prestige
Meridian II
30 M.G.Road,
Bangalore - 560001
INDIA
Tel.: +91 (80) 4113 2204/05
Fax: +91 (80) 4113 2206
india@cstsensors.com

OTHER ASIAN AND

PACIFIC COUNTRIES

AUSTRIA

BELGIUM

Tel.: +32 (0) 2 460 4413
Fax: +32 (0) 2 461 2614
sales-europe@crydom.com

UNITED KINGDOM

FRANCE

sales-europe@crydom.com

GERMANY

Tel.: +49 (0) 180 3000 506
Fax: +49 (0) 180 3205 227
vertrieb@crydom.com

ITALY

Tel.: +39 (0) 2 665 99 260
Fax: +39 (0) 2 665 99 268
sales-europe@crydom.com

THE NETHERLANDS

Tel.: +31 (0) 71 582 0068
Fax: +31 (0) 71 542 1648
sales-europe@crydom.com

SPAIN

Tel.: +34 902 876 217
Fax: +34 902 876 219
sales-europe@crydom.com

SWITZERLAND

MIDDLE EAST,

AFRICA AND OTHER

EUROPEAN COUNTRIES

Tel. : +44 (0) 1202 606030
Fax: +44 (0) 1202 606035
sales-europe@crydom.com

0 810 123 963

0 810 057 605

Custom Sensors &
Technologies

3F, No. 39, Ji-Hu Road
Nei-Hu Dist.
Taipei 114, Taiwan
Tel.: +886 2 8751 6388
Fax: +886 2 2657 8725
com-eap@cstsensors.com

TAIWAN

Custom Sensors &
Technologies

3F, No. 39, Ji-Hu Road
Nei-Hu Dist.
Taipei 114, Taiwan
Tel.: +886 2 8751 6388
Fax: +886 2 2657 8725
com-tw@cstsensors.com

PORTUGAL

Tel.: +44 (0) 1202 606034
Fax: +44 (0) 1202 606035
sales-europe@crydom.com

MEXICO

Automatismo Crouzet
S.A. de C.V.

Calzada Zavaleta 2505 - C
Col Sta Cruz Buenavista
C.P. 72150 - Puebla
MEXICO
Tel. : +52 (222) 409 7000
Fax : +52 (222) 409 7810
01 800 087 6333

Custom Sensors &
Technologies

5F, Jeil Bldg.,
94-46 Youngdeungpo-dong 7-ga
Youngdeungpo-gu,
Seoul, 150-037
South Korea
Tel.: +82 2 2629 8312
com-kr@cstsensors.com

BRASIL

info@cst-latinoamerica.com

Alameda Rio Negro, 1.084-cj.A31
Centro Empresarial de Alphaville
CEP: 06454-000
Barueri - SP

Tel.:

+55 (11) 4191 9797

Fax:

+55 (11) 4191 9136

Across the Globe

Distributed by :

Specifications are subject to change without prior notice.
Crydom and the Crydom logo are registered trademarks of
Crydom Inc.

08/2008

Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
