622

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

100VDC

100VDC

CAP

(MFD)

T

MAX

H

MAX

L

MAX

LS

± 0.059"

(± 1.5mm)

CAP

(MFD)

T

MAX

H

MAX

L

MAX

LS

± 0.059"

(± 1.5mm)

0.0010

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.027

0.177"

(4.5mm)

0.492"

(12.5mm)

0.315"

(8.0mm)

0.197"

(5.0mm)

0.0012

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.033

0.177"

(4.5mm)

0.492"

(12.5mm)

0.335"

(8.5mm)

0.197"

(5.0mm)

0.0015

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.039

0.197"

(5.0mm)

0.492"

(12.5mm)

0.354"

(9.0mm)

0.236"

(6.0mm)

0.0018

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.047

0.197"

(5.0mm)

0.492"

(12.5mm)

0.374"

(9.5mm)

0.236"

(6.0mm)

0.0022

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.056

0.217"

(5.5mm)

0.492"

(12.5mm)

0.394"

(10.0mm)

0.236"

(6.0mm)

0.0027

0.138"

(3.5mm)

0.472"

(12.0mm)

0.217"

(5.5mm)

0.138"

(3.5mm)

0.068

0.217"

(5.5mm)

0.512"

(13.0mm)

0.394"

(10.0mm)

0.236"

(6.0mm)

0.0033

0.138"

(3.5mm)

0.472"

(12.0mm)

0.236"

(6.0mm)

0.138"

(3.5mm)

0.082

0.236"

(6.0mm)

0.512"

(13.0mm)

0.413"

(10.5mm)

0.295"

(7.5mm)

0.0039

0.138"

(3.5mm)

0.472"

(12.0mm)

0.236"

(6.0mm)

0.138"

(3.5mm)

0.10

0.256"

(6.5mm)

0.512"

(13.0mm)

0.433"

(11.0mm)

0.295"

(7.5mm)

0.0047

0.138"

(3.5mm)

0.472"

(12.0mm)

0.236"

(6.0mm)

0.138"

(3.5mm)

0.12

0.276"

(7.0mm)

0.512"

(13.0mm)

0.472"

(12.0mm)

0.295"

(7.5mm)

0.0056

0.138"

(3.5mm)

0.472"

(12.0mm)

0.236"

(6.0mm)

0.138"

(3.5mm)

0.15

0.295"

(7.5mm)

0.591"

(15.0mm)

0.492"

(12.5mm)

0.295"

(7.5mm)

0.0068

0.138"

(3.5mm)

0.472"

(12.0mm)

0.236"

(6.0mm)

0.138"

(3.5mm)

0.18

0.315"

(8.0mm)

0.610"

(15.5mm)

0.512"

(13.0mm)

0.335"

(8.5mm)

0.0082

0.138"

(3.5mm)

0.472"

(12.0mm)

0.256"

(6.5mm)

0.138"

(3.5mm)

0.22

0.335"

(8.5mm)

0.630"

(16.0mm)

0.531"

(13.5mm)

0.335"

(8.5mm)

0.010

0.157"

(4.0mm)

0.472"

(12.0mm)

0.256"

(6.5mm)

0.138"

(3.5mm)

0.27

0.335"

(8.5mm)

0.689"

(17.5mm)

0.591"

(15.0mm)

0.394"

(10.0mm)

0.012

0.157"

(4.0mm)

0.472"

(12.0mm)

0.256"

(6.5mm)

0.138"

(3.5mm)

0.33

0.354"

(9.0mm)

0.748"

(19.0mm)

0.630"

(16.0mm)

0.394"

(10.0mm)

0.015

0.157"

(4.0mm)

0.492"

(12.5mm)

0.276"

(7.0mm)

0.157"

(4.0mm)

0.39

0.374"

(9.5mm)

0.768"

(19.5mm)

0.669"

(17.0mm)

0.394"

(10.0mm)

0.018

0.157"

(4.0mm)

0.492"

(12.5mm)

0.295"

(7.5mm)

0.157"

(4.0mm)

0.47

0.394"

(10.0mm)

0.787"

(20.0mm)

0.709"

(18.0mm)

0.394"

(10.0mm)

0.022

0.157"

(4.0mm)

0.492"

(12.5mm)

0.295"

(7.5mm)

0.197"

(5.0mm)

PAGE 1 OF 2

POLYESTER FILM AND FOIL
EPOXY DIPPED CASE

622

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

GENERAL SPECIFICATIONS

PHYSICAL CHARACTERISTICS

CONSTRUCTION:

INDUCTIVE WOUND POLYESTER FILM AND FOIL.

CASE:

  EPOXY DIPPED.

LEAD MATERIAL:

  SOLDER COATED OR TINNED SOLID WIRE, 22 TO 24 AWG.

DIMENSIONS:

 AS SPECIFIED IN TABLES.  OTHER LEAD LENGTHS, LEAD SPACINGS, AND CRIMP

STYLES AVAILABLE UPON REQUEST.

ELECTRICAL CHARACTERISTICS

CAPACITANCE:

  AS SPECIFIED IN TABLES ± REQUESTED TOLERANCE WHEN MEASURED AT OR

REFERRED TO 1000 ± 20 Hz AND 25 ± 5 °C.

TOLERANCE:

  ±5%, ±10%, AND ±20% AVAILABLE.  OTHER TOLERANCES AVAILABLE UPON REQUEST.

DISSIPATION FACTOR:

  SHALL NOT BE GREATER THAN 1.0% WHEN MEASURED AT OR REFERRED TO

1000 ± 20 Hz AND 25 ± 5 °C.

INSULATION RESISTANCE:

  SHALL BE GREATER THAN 50,000 M

Ω

 WHEN MEASURED AFTER 1 MINUTE

ELECTRIFICATION AT 100VDC AND 25 ± 5 °C.

DIELECTRIC STRENGTH:

  250% RATED VOLTAGE FOR 5 SECONDS THROUGH A LIMITING RESISTANCE

OF 100 OHMS/VOLT AT 25 ± 5 °C.

RATED VOLTAGE:

  100VDC.

TEMPERATURE:

  -40 °C TO +85 °C AT FULL RATED VOLTAGE.

ADDITIONAL INFORMATION

ORDERING INFORMATION:

  ALL ASC CAPACITORS ARE ORDERED BY "FAMILY CAP-TOL-VOLT"

DESIGNATION.  (I.E.  TO ORDER A 622 0.1µF, ±10%, 100VDC CAPACITOR, REQUEST PART NUMBER "622
.1-10-100")

SEE ALSO:

  "GENERAL INFORMATION - POLYESTER CAPACITORS" DOCUMENT FOR ADDITIONAL

PHYSICAL, ELECTRICAL, AND PERFORMANCE CHARACTERISTICS NOT MENTIONED IN THIS FILE.

WARNING:

  INFORMATION ON THIS FILE IS SUBJECT TO CHANGE WITHOUT NOTICE AT ASC'S

DISCRETION.

LAST MODIFIED:  08/27/01

PAGE 2 OF 2

POLYESTER FILM AND FOIL
EPOXY DIPPED CASE
