668

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

100VDC

200VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

0.0010

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0010

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0015

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0015

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0022

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0022

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0033

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0033

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0047

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.0047

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.0068

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.0068

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.010

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.010

0.197"

(5.0mm)

0.453"

(11.5mm)

22

0.015

0.217"

(5.5mm)

0.453"

(11.5mm)

22

0.015

0.217"

(5.5mm)

0.453"

(11.5mm)

22

0.022

0.236"

(6.0mm)

0.551"

(14.0mm)

22

0.022

0.256"

(6.5mm)

0.551"

(14.0mm)

22

0.033

0.256"

(6.5mm)

0.551"

(14.0mm)

22

0.033

0.276"

(7.0mm)

0.551"

(14.0mm)

22

0.047

0.256"

(6.5mm)

0.630"

(16.0mm)

22

0.047

0.276"

(7.0mm)

0.630"

(16.0mm)

22

0.068

0.295"

(7.5mm)

0.630"

(16.0mm)

22

0.068

0.315"

(8.0mm)

0.630"

(16.0mm)

22

0.10

0.335"

(8.5mm)

0.748"

(19.0mm)

20

0.10

0.295"

(7.5mm)

0.906"

(23.0mm)

22

0.15

0.335"

(8.5mm)

0.906"

(23.0mm)

20

0.15

0.354"

(9.0mm)

0.906"

(23.0mm)

20

0.22

0.374"

(9.5mm)

1.063"

(27.0mm)

20

0.22

0.413"

(10.5mm)

1.063"

(27.0mm)

20

0.33

0.413"

(10.5mm)

1.260"

(32.0mm)

20

0.33

0.453"

(11.5mm)

1.260"

(32.0mm)

20

0.47

0.492"

(12.5mm)

1.260"

(32.0mm)

20

0.47

0.531"

(13.5mm)

1.260"

(32.0mm)

20

0.68

0.571"

(14.5mm)

1.260"

(32.0mm)

20

1.0

0.669"

(17.0mm)

1.535"

(39.0mm)

20

PAGE 1 OF 4

POLYESTER FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE

668

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

400VDC

600VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

0.0010

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0010

0.197"

(5.0mm)

0.551"

(14.0mm)

22

0.0015

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0015

0.197"

(5.0mm)

0.551"

(14.0mm)

22

0.0022

0.177"

(4.5mm)

0.453"

(11.5mm)

22

0.0022

0.197"

(5.0mm)

0.551"

(14.0mm)

22

0.0033

0.197"

(5.0mm)

0.551"

(14.0mm)

22

0.0033

0.217"

(5.5mm)

0.630"

(16.0mm)

22

0.0047

0.236"

(6.0mm)

0.551"

(14.0mm)

22

0.0047

0.256"

(6.5mm)

0.630"

(16.0mm)

22

0.0068

0.236"

(6.0mm)

0.630"

(16.0mm)

22

0.0068

0.256"

(6.5mm)

0.748"

(19.0mm)

22

0.010

0.276"

(7.0mm)

0.630"

(16.0mm)

22

0.010

0.295"

(7.5mm)

0.748"

(19.0mm)

22

0.015

0.276"

(7.0mm)

0.748"

(19.0mm)

22

0.015

0.295"

(7.5mm)

0.906"

(23.0mm)

22

0.022

0.315"

(8.0mm)

0.748"

(19.0mm)

22

0.022

0.335"

(8.5mm)

0.906"

(23.0mm)

20

0.033

0.315"

(8.0mm)

0.906"

(23.0mm)

22

0.033

0.394"

(10.0mm)

0.906"

(23.0mm)

20

0.047

0.354"

(9.0mm)

0.906"

(23.0mm)

20

0.047

0.394"

(10.0mm)

1.260"

(32.0mm)

20

0.068

0.374"

(9.5mm)

1.063"

(27.0mm)

20

0.068

0.453"

(11.5mm)

1.260"

(32.0mm)

20

0.10

0.433"

(11.0mm)

1.063"

(27.0mm)

20

0.10

0.531"

(13.5mm)

1.260"

(32.0mm)

20

0.15

0.492"

(12.5mm)

1.260"

(32.0mm)

20

0.22

0.551"

(14.0mm)

1.457"

(37.0mm)

20

PAGE 2 OF 4

POLYESTER FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE

668

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

1000VDC

CAP

(µF)

D

MAX

L

MAX

LEAD

AWG

0.0010

0.256"

(6.5mm)

0.630"

(16.0mm)

22

0.0015

0.276"

(7.0mm)

0.630"

(16.0mm)

22

0.0022

0.256"

(6.5mm)

0.748"

(19.0mm)

22

0.0033

0.276"

(7.0mm)

0.748"

(19.0mm)

22

0.0047

0.315"

(8.0mm)

0.748"

(19.0mm)

22

0.0068

0.315"

(8.0mm)

0.906"

(23.0mm)

22

0.010

0.354"

(9.0mm)

0.906"

(23.0mm)

20

0.015

0.394"

(10.0mm)

0.906"

(23.0mm)

20

0.022

0.453"

(11.5mm)

0.906"

(23.0mm)

20

0.033

0.453"

(11.5mm)

1.260"

(32.0mm)

20

0.047

0.512"

(13.0mm)

1.260"

(32.0mm)

20

0.068

0.551"

(14.0mm)

1.457"

(37.0mm)

20

PAGE 3 OF 4

POLYESTER FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE

668

301  WEST  O  STREET

•

  OGALLALA, NE  69153

Phone:  (308) 284-3611

e-mail:  sales@ascapacitor.com

Fax:  (308) 284-8324

web:  www.ascapacitor.com

PAGE 4 OF 4

GENERAL SPECIFICATIONS

PHYSICAL CHARACTERISTICS

CONSTRUCTION:

 NON-INDUCTIVE WOUND POLYESTER FILM AND FOIL.

CASE:

  TAPE WRAP CASE AND EPOXY FILL.

LEAD MATERIAL:

  AXIAL SOLDER COATED OR TINNED SOLID WIRE, AWG AS SPECIFIED IN TABLES.

DIMENSIONS:

 AS SPECIFIED IN TABLES.

ELECTRICAL CHARACTERISTICS

CAPACITANCE:

  AS SPECIFIED IN TABLES ± REQUESTED TOLERANCE WHEN MEASURED AT OR

REFERRED TO 1000 ± 20 HZ AND 25 ± 5 °C.

TOLERANCE:

 ±5%, ±10%, AND ±20% AVAILABLE.  OTHER TOLERANCES AVAILABLE UPON REQUEST.

DISSIPATION FACTOR:

  SHALL NOT BE GREATER THAN 1.0% WHEN MEASURED AT OR REFERRED TO

1000 ± 20 HZ AND 25 ± 5 °C.

INSULATION RESISTANCE:

  SHALL BE GREATER THAN 50,000 M

Ω

 WHEN MEASURED AFTER 2

MINUTES ELECTRIFICATION AT 100VDC AND 25 ± 5 °C.

DIELECTRIC STRENGTH:

  250% RATED VOLTAGE FOR 5 SECONDS THROUGH A LIMITING RESISTANCE

OF 100 OHMS/VOLT AT 25 ± 5 °C.

RATED VOLTAGE:

  100VDC, 200VDC, 400VDC, 600VDC, AND 1000VDC AVAILABLE.

TEMPERATURE:

  -40 °C TO +85 °C AT FULL RATED VOLTAGE OPERATIONAL TEMPERATURE, DERATE

LINEARLY 1.5%/°C ABOVE +85 °C TO +105 °C, +105 °C MAX STORAGE TEMPERATURE.

ADDITIONAL INFORMATION

ORDERING INFORMATION:

  ALL ASC CAPACITORS ARE ORDERED BY "FAMILY CAP-TOL-VOLT"

DESIGNATION.  (I.E.  TO ORDER A 668 0.0068µF, ±5%, 400VDC CAPACITOR, REQUEST PART NUMBER
"668 .0068-5-400")

SEE ALSO:

  "GENERAL INFORMATION - POLYESTER CAPACITORS" DOCUMENT FOR ADDITIONAL

PHYSICAL, ELECTRICAL, AND PERFORMANCE CHARACTERISTICS NOT MENTIONED IN THIS FILE.

WARNING:

  INFORMATION ON THIS FILE IS SUBJECT TO CHANGE WITHOUT NOTICE AT ASC'S

DISCRETION.

LAST MODIFIED:  08/27/01

POLYESTER FILM AND FOIL
TAPE WRAP AND EPOXY FILL CASE
