Light Emitting Diodes
ADLHP Series
High Power LEDs
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL-OPTICAL CHARACTERISTICS
FEATURES
INTRODUCTION
SERIES STANDARD SPECIFICATIONS
WHITE
1
The Adiva High-Power LED has a wide range of applications and a uniquely designed shape and is incapsu-
lated in water clear epoxy resin with an 8mm diameter.
• High Luminous intensity,with a longer operation life.
• Excellent consistency on color,intensity and Forward
Current.
• Low voltage DC operated.
• Excellent Solderability and resistance to soldering
heat.
• High Reliability,100% Probing Test.
• Low thermal resistance
ADLHP0-8C400-M1
Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature
Parameter
Forward Voltage
Reverse Current
Luminous Flux
Shape
8ø
Part Number
ADLHP0-8C200-M1
Diffusion
W.C.
IR(µA)
VR=10V
MAX Min
10 2
Emitting
Material
InGaN
Viewing Angle
Q
(deg.)
140
Luminous
Intensity (lm)
IF=200mA
Typ
30
Emitting Color
White
Wavelength
(nm) λ
n/a
Symbol
Vf
Ir
lm
Conditions
IF=250mA
VR=10V
IF=250mA
Min.
Typ.
2.1
30
Max.
10
Symbols
If
λ
D
Top
PD
VR
Ts
T
sol
Ratings
250
n/a
-25 ~ 80
0.8
5
-30 ~ 100
* 260
Unit
mA
nm
C
W
V
C
C
ADLHP
2
2
ANODE
1
CATHODE
5.8
2.79
2.54
0.7
2
?1.65
2
?9
20.9
7.7
5.3
7.7
a
5000 - 6000
b
6000 - 7000
c
7000 - 8000
Unit
K
Kelvin Rating
K
