Light Emitting Diodes
ADLHP Series
High Power LEDs
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL-OPTICAL CHARACTERISTICS
FEATURES
INTRODUCTION
SERIES STANDARD SPECIFICATIONS
Dominant Wavelength
RED
1
The Adiva High-Power LED has a wide range of applications and a uniquely designed shape and is incapsu-
lated in water clear epoxy resin with an 8mm diameter.
• High Luminous intensity,with a longer operation life.
• Excellent consistency on color,intensity and Forward
Current.
• Low voltage DC operated.
• Excellent Solderability and resistance to soldering
heat.
• High Reliability,100% Probing Test.
• Low thermal resistance
ADLHP2-8BC200-M1-L
Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Current
Storage Temp. Range
Soldering Temperature
Parameter
Forward Voltage
Reverse Current
Luminous Intensity
Shape
8ø
Rank
λD
a
622 - 625
b
625 - 628
b
628 - 631
Unit
nm
Part Number
ADLHP2-8BC200-M1-L
Diffusion
W.C.
IR(µA)
VR=10V
MAX
10
Emitting
Material
InGaAlP
Viewing Angle
Q
(deg.)
140
Luminous
Intensity (lm)
IF=100mA
Typ
10
Emitting Color
Red
Wavelength
(nm)
625
Symbol
Vf
Ir
lm
Test Condition
IF=100mA
VR=10V
IF=100mA
Min.
8
Typ.
2.1
10
Max.
10
12
Symbols
If
l
D
Top
PD
Irz
Ts
T
sol
Ratings
100
625
-25 ~ 80
0.2
10
-30 ~ 100
* 240
Unit
mA
nm
C
W
mA
C
C
2
ANODE
1
CATHODE
9.2
7.7
0.7
6.3
6.3
2.79
7.7
1.99
6.3
6.3
+
2
