Light  Emitting  Diodes

ADLSM  Series

Surface Mount LEDs

ABSOLUTE  MAXIMUM  RATINGS

ELECTRICAL-OPTICAL  CHARACTERISTICS

FEATURES

INTRODUCTION

SERIES  STANDARD  SPECIFICATIONS

WHITE

RECOMMENDED SOLDERING PATTERN

TAPING OUTLINE DIMENSIONS

The Adiva Surface Mount LED has a wide range of applications and a very small size  enabling it to be used in
a variety of advanced technological equipment such as cellular phones, PDAs, portable MP3 players and
indicator lights.

• High Luminous intensity,with a longer operation life.

• Excellent consistency on color,intensity and Forward

  Current.

• Low voltage DC operated.
• Excellent Solderability and resistance to soldering

heat.

• High Reliability,100% Probing Test.

• Low thermal resistance

ADLSM0-1608-C200-L1

Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature

Parameter
Forward Voltage
Reverse Current
Luminous Intensity

Shape

 0603

Part Number

ADLSM0-1608-C200-L1

Diffusion

W.C.

IR(µA)

VR=10V

MAX

10

Emitting

Material

InGaAlN

Viewing Angle

Q

(deg.)

120

Luminous

Intensity (mcd)

IF=20mA

Typ

28

Emitting Color

White

Wavelength

(coord.)

(0.21/1.5)

Symbol
 Vf
Ir
mcd

Conditions

IF=20mA

VR=5V

IF=20mA

Min.

2.7

--
--

Typ.

--
--

55

Max.

3.25

10

--

Symbols

If

l

D

Top

PD

Vr
Ts

T

sol

Ratings

20

(0.29/0.33)

-25 ~ 80

75

5

-30 ~ 100

* 240

Unit

mA

(coord.)

C

mW

V
C
C

Cathode

Anode

(1)

(2)

(Unit:mm)

0.8

0.8

0.7
