O

Light  Emitting  Diodes

ADLSM  Series

Surface Mount LEDs

ABSOLUTE  MAXIMUM  RATINGS

ELECTRICAL-OPTICAL  CHARACTERISTICS

FEATURES

INTRODUCTION

SERIES  STANDARD  SPECIFICATIONS

WHITE

RECOMMENDED SOLDERING PATTERN

S1

150 - 200

Bin Ranking

IV (mcd)

S2

200 - 400

The Adiva Surface Mount LED has a wide range of applications and a very small size  enabling it to be used in
a variety of advanced technological equipment such as cellular phones, PDAs, portable MP3 players and
indicator lights.

• High Luminous intensity,with a longer operation life.

• Excellent consistency on color,intensity and Forward

  Current.

• Low profile 0.68mm height.
• Excellent Solderability and resistance to soldering

heat.

• High Reliability,100% Probing Test.

• Low thermal resistance

ADLSM0-2012-C200-Sx

Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature

Parameter
Forward Voltage
Wavelength
Luminous Intensity

Shape

0805

Part Number

ADLSM0-2012-C200-Sx

Diffusion

W.C.

IR(µA)

VR=10V

MAX

10

Emitting

Material

InGaAlN

Viewing Angle

Q

(deg.)

120

Luminous

Intensity (mcd)

IF=20mA

Typ

250

Emitting Color

White

Wavelength

(nm)

(0.29/0.33)

Symbol
 Vf
(coord.)
mcd

Conditions

IF=20mA

If=20mA

IF=20mA

Min.

1.9

0.29/0.315

150

Typ.

--
--
--

Max.

2.5

0.335/0.385

400

Symbols

If

l

D

Top

PD

Vr
Ts

T

sol

Ratings

20

(0.29/0.33)

-25 ~ 80

75

5

-30 ~ 100

* 240

Unit

mA

(coord.)

C

mW

V
C
C

0.8

0.8

0.7

Cathode

Anode

(1)

(2)

(Unit:mm)

1.25

2

0.28

1.22

R0.2

0.68
