ABSOLUTE  MAXIMUM  RATINGS

www.adivatech.com

(888)  30-ADIVA  (23482)

O

Light  Emitting  Diodes

ADLSM  Series

Surface Mount LEDs

ELECTRICAL-OPTICAL  CHARACTERISTICS

FEATURES

INTRODUCTION

SERIES  STANDARD  SPECIFICATIONS

     WHITE

RECOMMENDED SOLDERING PATTERN

Polarity

Anode

Cathode

①

②

③
④

(Unit:mm)

S1

200 - 400

S2

400 - 600

S3

800 - 1200

Bin Ranking

IV (mcd)

The Adiva Surface Mount LED has a wide range of applications and a very small size  enabling it to be used in
a variety of advanced technological equipment such as cellular phones, PDAs, portable MP3 players and
indicator lights. The brightness makes it a perfect choice for cellphone camera flashes.

• High Luminous intensity,with a longer operation life.

• Compact package

• Excellent Solderability and resistance to soldering

heat.

• High Reliability,100% Probing Test.

• Low thermal resistance

ADLSM0-3528-C200-Sx

Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature

Parameter
Forward Voltage
Wavelength
Luminous Intensity

Shape

 3528

Part Number

ADLSM0-3528-C200-Sx

Diffusion

W.C.

IR(µA)

VR=10V

MAX

100

Emitting

Material

InGaAlN

Viewing Angle

Q

(deg.)

120

Luminous

Intensity (lm)

IF=120mA

Typ

10.0

Emitting Color

White

Wavelength

(coord.)

(0.31/.35)

Symbol
 Vf
coord.
mcd

Conditions

IF=20mA
IF=20mA
IF=20mA

Min.

2.9

0.29/0.315

200

Typ.

--

700

Max.

3.5

0.33/0.385

1200

Symbols

If

l

D

Top

PD

Vr
Ts

T

sol

Ratings

20

0.31/0.35

-25 ~ 80

75

5

-30 ~ 100

* 240

Unit

mA

coord.

C

mW

V
C
C

2.

6

1.

1

1.

1

1.4

1.4

1.0
