ABSOLUTE  MAXIMUM  RATINGS

www.adivatech.com

(888)  30-ADIVA  (23482)

O

Light  Emitting  Diodes

ADLSM  Series

Surface Mount LEDs

ELECTRICAL-OPTICAL  CHARACTERISTICS

FEATURES

INTRODUCTION

SERIES  STANDARD  SPECIFICATIONS

     WHITE

RECOMMENDED SOLDERING PATTERN

TAPING OUTLINE DIMENSIONS

The Adiva Surface Mount LED has a wide range of applications and a very small size  enabling it to be used in
a variety of advanced technological equipment such as cellular phones, PDAs, portable MP3 players and
indicator lights. The brightness makes it a perfect choice for cellphone camera flashes.

• High Luminous intensity,with a longer operation life.

• Built-in 6 chip super luminosity - White color

• Ceramic package
• Excellent Solderability and resistance to soldering

heat.

• High Reliability,100% Probing Test.

• Low thermal resistance

ADLSM0-5050-C200-L5

Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature

Parameter
Forward Voltage
Wavelength
Luminous Intensity

Shape

 5050

Part Number

ADLSM0-5050-C200-L5

Diffusion

W.C.

IR(µA)

VR=10V

MAX

100

Emitting

Material

AlGalNP

Viewing Angle

Q

(deg.)

120

Luminous

Intensity (lm)

IF=120mA

Typ

10.0

Emitting Color

White

Wavelength

(nm)

(0.31/.35)

Symbol
 Vf
coord.
lm

Conditions

IF=40mA

IF=120mA
IF=120mA

Min.

--

0.29/0.315

9.0

Typ.

3.2

10.0

Max.

--

0.33/0.385

--

Symbols

If

l

D

Top

PD

Vr
Ts

T

sol

Ratings

20

0.31/0.35

-25 ~ 80

75

5

-30 ~ 100

* 240

Unit

mA

coord.

C

mW

V
C
C

(Unit:mm)

Cathode Cathode Cathode

Anode

Anode

Anode

0.95

0.95

1.3

0.45

0.45

5.2

3.

7

6.

4

1.

35

1.

35
