www.adivatech.com

(888)  30-ADIVA  (23482)

O

Light  Emitting  Diodes

ADLSM  Series

Surface Mount LEDs

ABSOLUTE  MAXIMUM  RATINGS

ELECTRICAL-OPTICAL  CHARACTERISTICS

FEATURES

INTRODUCTION

SERIES  STANDARD  SPECIFICATIONS

BLUE

RECOMMENDED SOLDERING PATTERN

S1

60 - 90

Bin Ranking

IV (mcd)

S2

90 - 150

The Adiva Surface Mount LED has a wide range of applications and a very small size  enabling it to be used in
a variety of advanced technological equipment such as cellular phones, PDAs, portable MP3 players and
indicator lights.

• High Luminous intensity,with a longer operation life.

• Excellent consistency on color,intensity and Forward

  Current.

• Low voltage DC operated.
• Excellent Solderability and resistance to soldering

heat.

• High Reliability,100% Probing Test.

• Low thermal resistance

ADLSM7-1608-C200-Sx

Items
Operation Forward Current
Dominant wavelength
Operating Temperature Range
Power Dissipation
Reverse Voltage
Storage Temp. Range
Soldering Temperature

Parameter
Forward Voltage
Wavelength
Luminous Intensity

Shape

 0603

Part Number

ADLSM7-1608-C200-Sx

Diffusion

W.C.

IR(µA)

VR=10V

MAX

10

Emitting

Material

InGaN

Viewing Angle

Q

(deg.)

120

Luminous

Intensity (mcd)

IF=20mA

Typ

105

Emitting Color

Blue

Wavelength

(nm)

465

Symbol
 Vf
(coord.)
mcd

Conditions

IF=20mA

If=20mA

IF=20mA

Min.

1.9

460

60

Typ.

--

465
105

Max.

2.5

470
150

Symbols

If

l

D

Top

PD

Vr
Ts

T

sol

Ratings

20

465

-25 ~ 80

75

5

-30 ~ 100

* 240

Unit

mA

mcd

C

mW

V
C
C

Cathode

Anode

(1)

(2)

(Unit:mm)

0.8

0.8

0.7
