Light Emitting Diodes
ADP Series
Thru-Hole LEDs
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL-OPTICAL CHARACTERISTICS
FEATURES
INTRODUCTION
SERIES STANDARD SPECIFICATIONS
RED
Unit
V
nm
mcd
1
The Adiva Thru-Hole LED has a wide range of applications and is incapsulated in water clear epoxy resin with
an 5mm diameter.
• High Luminous intensity,with a longer operation life.
• Excellent consistency on color,intensity and Forward
Current.
• Rugged and reliable design gives high
shock/vibration resistance.
• Excellent Solderability and resistance to soldering
heat.
• High Reliability,100% Probing Test.
• Low thermal resistance
ADP1-51500-S1 & S2
Items
Operation Forward Current
Reverse Current
Operating Temperature Range
Power Dissipation
Peak Pulse Forward Current
Storage Temp. Range
Soldering Temperature
Parameter
Forward Voltage
Dominant Wavelength
Luminous Intensity
Shape
5ø
Part Number
ADP1-51500-S1 & S2
Diffusion
W.C.
IR(µA)
IF RV=5V
MAX Min
100 2
Emitting
Material
GaAsP/GaP
Viewing Angle
Q
(deg.)
15 - 30
Reverse Voltage
RV
Emitting Color
Red
Wavelength
nm
620 - 635
Symbol
Vf
λ
D
Iv
Conditions
IF=20mA
IF=20mA
IF=20mA
Min.
1.9
620
500
Typ.
--
--
Max.
2.5
635
4500
Symbols
If
Ir
Top
PD
PIf
Ts
T
sol
Ratings
30
100
-25 ~ 80
100
100
-30 ~ 100
* 260
Unit
mA
uA
C
mW
mA
C
C
S1
500 - 2500
S2
2500 - 4500
Unit
mcd
Bin Ranking
Luminous Intensity
1.0 ± 0.2
0.5
5 ± 0.2
1 MAX.
1.0 MIN.
ANODE
2.54
26.4 MIN.
8.6 ± 0.3
5.9 ± 0.3
5 V
