AEM, Inc.
AEM Part
Number
Impedance
Ohm at 100 MHz
Max. DCR
Ohm
Max. Current
mA
MCP0603F300
30
0.06
1000
MCP0603F600
60
0.1
500
MCP0805F070
7
0.02
3000
MCP0805F100
10
0.02
3000
MCP0805F110
11
0.025
3000
MCP0805F150
15
0.025
3000
MCP0805F300
30
0.025
3000
MCP0805F400
40
0.03
2000
MCP0805F450
45
0.03
2000
MCP0805F800
80
0.1
1000
MCP0805F201
200
0.15
1000
MCP0805F301
300
0.15
1000
MCP0805F601
600
0.2
1000
MCP1206F190
19
0.02
3000
MCP1206F260
26
0.02
3000
MCP1206F300
30
0.02
3000
MCP1206F310
31
0.02
3000
MCP1206F500
50
0.025
3000
MCP1206F700
70
0.03
2000
MCP1206F800
80
0.03
2000
MCP1206F900
90
0.1
1000
MCP1206F121
120
0.1
1000
MCP1206F601
600
0.2
1000
MCP1206P601
600
0.1
1500
Definition of rated current: When the rated current is applied to a power bead,
its temperature rise shall not exceed 20°C.
Other values are available upon customer’s request. Please add tolerance and
packaging code to part number when ordering.
MCP Series (for high current)
