EN 2010

POWER RESISTORS

 INDEX

2

EN 2010

Index

ATE Electronics

Products

Quality and Certifications

How to order, Cross-Reference

CS Series

SR Series

RB Series

RB/6 Series

RB/7 Series

RB/8 Series

RB106, RB256 Series

DAT Series

PR Series

3SM Series

pag.  2

pag.  3

pag.  4

pag.  5

pag.  6

pag.  7

pag.  8

pag.  9

pag.  11

pag.  12

pag.  13

pag.  14

pag.  15

pag.  16

pag.  19

     ATE

3

EN 2010

Every designer that works with electronic components knows

well integration system, reliability and custom products problems.

ATE Electronics

 solves these problems since 1970 producing

power resistors with high quality and technology.

We pay attention to all Customers enquiries giving our best

solution and warranty at low cost and fast delivery.



                                                             Sandro Felisio

                                                                     CEO

PRODUCTS

4

EN 2010

ATE Electronics

 products set:

-

CS axial wirewound resistors

 (2W to 15W), thanks to row

materials of very high quality and reliability, can replace with

better permormances resistors in ceramic glaze.

-

Aluminium housed RB series

 (10W to 250W) can supply in

small dimensions high power with low operating temperature.

-

CS and RB series

 can be supplied on request in

special

versions

 (fuse resistors, high pulse overload, non inductive...)

and with custom leads (high insulation voltage terminals, faston,

screw....)

-

3SM

 (3W) for surface mount applications wich allow the

replacament of traditional axial resistors with the same electrical

characteristics of 3CS type

-

Anti moisture devices DAT

 (100W & 150W)

-

Symmetry resistors SR

 (10W & 13W) for voltage divider and

discharge of electrolitical capacitors.

-

Fuse resistors RF

 (2W to 15W)

QUALITY

5

EN 2010

Looking for best quality, our intent is always obtain the Customer's

satisfaction with excellent products and services.

For this

ATE Electronics

 since 1994 was one of the first Italian

Companies to be certified with quality system compliant to

UNI EN ISO standards.

In feb 11th 2010 we obtained the update to

UNI EN ISO9001:2008

,

certificate nr. 9170.ATEE

All our products are made in Italy and compliant with

RoHS

,

MIL

 &

CECC

.

Our staff on all our products is able to satisfy all Your enquiries

MADE IN ITALY

ORDERS

6

EN 2010

How to order examples :

Example for

CS Series

 :

5CS     1K0      5%

Example for

PR Series

 :

PR100   1K0    10%

Tolerance

Ohmic value

Type Resistor

Tolerance

Ohmic value

Type Resistor

Example for

RB Series

 :

RB25   /1    1K0     5%

Tolerance

Ohmic value

Terminal Type (/1= Standard)

Type Resistor

Supply voltage

Device Type

Example for

DAT Series

 :

DAT100   220Vac

For

non inductive

 types You have to add the letter "

N

" after resistor type. Ex.:

CSN

 -

RBN

To order CS resistors taped on reel add the suffix "

/ 73

" after the resistor type. Ex.:

5CS/73 1K0 J

Quantity for reel: 1500x2CS,  1000x3CS, 5CS and 6CS

K

   10%

J

   5%

H

  3%

G

   2%

F

   1%

D

  0.5%



(for values above 1R0)

Tolerances:

Note: The Cross-Reference listed may not be exactly equivalent, but they are good replacements / alternatives.

We recommend to download both datasheets, ATE and direct Competitor, and make a careful comparison.

If You need more information, please contact us at [email protected]

Cross-Reference ATE Electronics

Competitors

Arcol

Ccohm

Danotherm

Ebg

Huntington

Koa

Mcb

Ohmite

Pec

Powertron

Raraohm

Rcd

Res. Online

Riedon

Royal-Ohm

Tyco / Cgs

Vishay

Vitrohm

Welwin - TT

Yageo

UK

TW

DK

USA

USA

JP

FR

USA

IN

DE

KR

USA

IN

USA-DE

TT

USA-PA

USA

PT

UK

TW

ACS
KNP

VC

-

ALSR

RW

-

80

PIA

UT

PWR

100

-

UT

KNP

ES

AC, G, RS

RX

W

-

HS
AH

HS

-

TMC

-

-

89, HS

PHA

-

RH

600

AHR

UAL

PDM

HSA

RH, SH

HS

WH

RE

HS /

-

HS /

-

-
-

-
-

-
-

-

-

-
-

-

HSX

-

RE

WH /

-

FPA100

-

-

HXP200

-
-

RCEC

TGH

-
-

TPM

-

-

KP

-

BDS100

RTOP

-

BHPR

-

FPA250

-

-

UXP300

HPK600

-

RCEC

TAP600

-
-

-

-

-
-

-

BDS250

RPS

-
-

-

S, SL

-

-

-

SM

-

-

RW

-

S/SL

-

-

-
-

-

SM

WSC

-
-

-

-
-

-

-

-
-

-

G

PYP

-

-

-

-
-

-

YP

-

-

WPYP

-

Stato

CS

RB

RB /

PR100

PR250

SMD

SR

CS Series

FEATURES

Easy replacement of vitreous enamel resistors with no cost increase

and no performance loss.

The whole assembly is coated with multi-layer silicone coating to give

maximum wire protection form -55°C to +350°C.

Performance improvement is obtained by close tolerance, very low

temperature coefficient and excellent stability in operation under severe

environmental conditions.

High level reliability due to ceramic core chemically inert and centerless

ground for uniformity, selected wire element and completely welded

construction terminal to terminal.

 WIREWOUND RESISTORS

SILICONE COATED  2 W TO 15 W

Specifications

ELECTRICAL SPECIFICATIONS

- Ohmic values

E24 Series. For out of range or not standard ohmic values,

consult ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1% (for values >R047).

- Temperature coefficient

Typical values: ±100 to ±30 ppm from R10 to Rmax

Consult factory for special applications

- Dielectric strength

500 Vdc 2CS to 6CS

700 Vdc 7CS to 12CS

- Insulation resistance

1000 MOhm minimum.

100 MOhm after moisture test

- Sovraccarico

5s at 10 times rated power

5s at 5 times rated power 2CS and 3CS

- Non inductive

Models of equivalent physical and electrical specifications are also available with

non  inductive Ayrton-Perry winding

MECHANICAL SPECIFICATIONS

- Terminal strength

10 lb. pull test.

- Solderability

Continuous, satisfactory coverage when tested in accordance to MIL-PRF-26 H.

MATERIALS

- Core

Ceramic steatite or alumina centerless ground

- Resistive element

Copper-nickel alloy or nickel-chrome alloy with specific temperature coefficient

- End caps

Stainless steel

- Coating

Special high temperature silicone

- Standard terminals

LF tinned copper or LF tinned copperweld

Point of measure:  L + 20mm

DERATING

These resistors can be used in a temperature range form -55°C to +350°C

To use these components in applications with working temp. higher  +25°C You have

to make a power reduction with linear derating from nominal power to zero at 350°C

These resistors meet or exceed the requirements of

MIL-PRF-26 H specifications.

ATE    10CS

10R J   1210

L

38±3

D

d

CS SERIES

7

EN 2010

Wirewound resistors silicone coated

2 W to 15 W

ATE

Type

MIL PRF

26H

Type

Rated

power

(W)

Resistance

range

(Ohm)

Voltage

Limit

(V)

Temperature

rise

(°C/W)

Weight

(g)

Dimensions

D

(mm)

L

(mm)

d

(mm)

2CS

3CS

5CS

6CS

7CS
10CS

12CS

RW69V

RW74U

RW67V

RW55V

RW68V

RW56V

3

4

-

6

7

10

13

15

0.01- 5K6

0.01- 10K

0.01- 24K

0.01- 27K

0.01- 47K

0.01- 68K

0.01- 82K

130

200

380

435

685

940

1100

91

74

52

45

30

24

21

1.2

1.8

3.2

3.8

7

9

10

5.2±0.5

6±0.5

8±0.5

8±0.5

9.5±0.5

9.5±0.5

9.5±0.5

12±0.8

13.5±0.8

22±1.6

25±1.6

35±1.6

46±1.6

51±1.6

0.8

0.8

0.8

0.8

0.9

0.9

0.9

0

50

100

150

200

250

300

350

0

20

40

60

80

100

T

m

ax

  (

°

C)

.

Pn (%)

2CS, 3CS

T

amb

=25

°

C

5CS, 6CS

7CS, 10CS, 12CS

SR SERIES

 8

EN 2010

Simmetry resistors

and/or capacitors discharge

7SR

10SR

SR Series

SPECIFICATIONS

 SYMMETRY RESISTORS

AND/OR CAPACITORS DISCHARGE

- Tolerance :

Standard 5%. On request up to 1%

- Ohmic values :

E24 Series

- Temperature coefficient :

From ±100 to ±30 ppm from R10 to Rmax

- Dielectric strength:

1000 Vac

- Packing:

Strip of 10 pcs or loose pcs

10SRS

, in blister

- Vibrations test :

According  IEC 60571-1

More technical data as 7CS and 10CS standard type

7SR

7SR/B

10SR

10SR/B

7CS
7CS

10CS
10CS

22.2
22.2
31.8
31.8

40
40
50
50

15
10
15
10

21
16
21
16

9.5
9.5
9.5
9.5

9
9

11
11

ATE

Type

Basic

Resistors

A (mm)

toll: ±1

B (mm)

max value

C (mm)

toll: ±1

D (mm)

toll: ±1

E (mm)

toll: ±1

Weight

(g)

ATE Type

Temperature rise at rated power

7SR and 7SR/B

Temperature rise at rated power

10SR and 10SR/B

T1
T2
T3

T4

(capacitor mounted)

∆

T = 26 °C/W

∆

T = 16 °C/W

∆

T = 15 °C/W

∆

T = 1.2 °C/W

∆

T = 21.5 °C/W

∆

T = 12.3 °C/W

∆

T = 11.5 °C/W

∆

T = 1 °C/W

ATE Type

MIL-R-26H Type

Rated power

(W)

Resistance range

(Ohm)

Voltage limit

(V)

7SR

10SR

RW55

RW68

10

13

0.1 - 47K

0.1 - 68K

685

940

A

B

E

C

0.4

D

Ø 6.3

Ø 10.6

T4

T3

T1

T2

Stainless

steel

Two

welding

spots

RB Series

FEATURES

Extruded aluminium housing provides superior heat conduction.

Housing deep finned for maximum heat dissipation at natural or

forced air convection.

Gold anodized finish for maximum resistance to environmental conditions.

Special thermosetting compound with high thermal conductivity.

Winding designed to give maximum core coverage and uniformity for

even heat dissipation.

Core centerless ground for maximum winding uniformity.

Marking at top surface for easy identification after mounting.

Complete welded construction terminal to terminal.

 FIXED POWER WIREWOUND

RESISTORS ALUMINIUM HOUSED

Specifications

ELECTRICAL SPECIFICATIONS

- Ohmic values

Serie E24. For out of range or not standard ohmic values, consult

ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1%.

- Temperature coefficient

±30 ppm  R > 20 Ohm

±50 ppm  1 Ohm < R < 20 Ohm

±100 ppm  0.1 Ohm < R < 1 Ohm

- Dielectric strength

1500 Vac for RB10

2500 Vac for RB25 and RB50

3500 Vac for RB75, RB101 and RB150

4500 Vac for RB100 and RB250

- Insulation resistance

10000 MOhm minimum

1000 MOhm after moisture test

- Overload

5s at 5 times rated power

- Non inductive

Models of equivalent physical and electrical specifications are also available with

non inductive Ayrton-Perry winding

MECHANICAL SPECIFICATIONS

- Terminal strength

10 lb. pull test; 3 Nm x RB100 and 4 Nm x RB250 max torque

- Solderability

Satisfactory when tested in accordance with method 208 of MIL-STD-202.

The use of high temperature solder is recommended when resistors work near

the maximum specified ratings

MATERIALS

- Core

Ceramic steatite or alumina centerless ground

- Resistive Element

Copper-nickel alloy or nickel-chrome alloy with specific temperature coefficient

- End caps

Stainless steel

- Encapsulant

High temperature thermosetting compound

- Housing

Aluminium with hard anodic finish

- Standard terminals

Copperweld RB10 to RB150

Stainless steel for RB100 and RB250

DERATING

ATE RB resistors have and operative temperature range from -55°C to +250°C

Derating is required for reduced chassis area and for high ambient temperature

These resistors meet or exceed the requirements of

MIL-PRF-18546 G specifications.

RB SERIES

9

EN 2010

Fixed power wirewound resistors

aluminium housed 10 W to 250 W

RB10
RB25
RB50
RB75

RB101
RB150
RB100
RB250

RE65
RE70
RE75

-
-
-

RE77
RE80

12
25
50
75

100
150
150
250

6

12.5

20
35
40
55
75

100

0.01-10K
0.01-18K
0.01-68K

0.1-50K
0.1-70K

0.1-100K
0.1-100K
0.1-120K

265
550

1250
1400
1900
2500
1900
2300

5.1

3

1.9
1.1

1
1

0.84
0.66

6

14
35
85

115

165
500
900

415x1
535x1

930x1.5

995x3
995x3
995x3
930x3
930x3

ATE Type

MIL-PRF-

18546 G

Type

Rated

power

(W)

Max power

no heatsink

(W)

Temp. rise

with heatsink

(W)

Resistance

range

(Ohm)

Voltage

limit

(V)

Weight

(g)

Heatsink

dimensions

(cm² x mm)

ATE Type

A

B

C

D

E

F

G

H

J

K

L

M

N

Ø

Dimensions (mm)

RB10

20.4
27.2
29.2

47
47
47

71.5

76

±0.2

35
49
71
73
89

122
139
178

±1

10
14
16
24
24
24

44.5
55.6

±0.2

11

14
16
27
27
27
46
54

±0.2

2.4
4.4
5.2
9.5

14.5
19.5

9.6
7.8

±0.5

2
2
2

3.5
3.5
3.5

5

6.3

±0.2

2
2
2
3
3
3

M5
M6

±0.2

2.2
2.2
2.2
3.2
3.2
3.2

-
-

±0.2

2.4
3.2
3.2
4.4
4.4
4.4
4.8
4.8

±0.2

-
-
-
-
-
-

69.8
98.4

±0.2

15.9
19.8
21.5

37
37
37

57.1
63.5

±0.2

5

6.5

7

11.5
11.5
11.5

20

25.5

±0.2

19
27
50
48
64
97
89

114

±0.5

14.3
18.3
39.7

29
35
58

-

76.2

±0.2

RB25
RB50
RB75

RB101
RB150
RB100
RB250

Tol.

D

C

H

K

J

F

M
E
B

N

only RB250

RB100 - RB250

F

L

G A

only RB250

N

RB75 - RB101 - RB150

J

F

E
B

G

A

∅

L

only RB150

H

C

K

D

=

=

H

C

K

D

J

F
E
B

N

G A

L

∅

RB10 - RB25 - RB50

only RB150

RB SERIES

10

EN 2010

Fixed power wirewound resistors

aluminium housed 10 W to 250 W

ATE Type

MIL-PRF

18546 G Type

Rated

power (W)

Resistance

range (Ohm)

Voltage

Limit (V)

Weight

(g)

Heatsink Dimensions

(cm² x mm)

RB25/6
RB50/6

RE70
RE75

25
50

0.1 - 18K
0.1 - 68K

550

1250

13
32

535 x 1

930 x 1.5

ATE Type

Dimensions (mm)

A

B

C

D

E

F

G

H

J

K

L

M

N

Ø

19.8

49

21.5

±0.2

14

16

±0.2

27.7

29.2

±0.2

14

16

±0.2

6.5

7

±0.2

2

2

±0.2

18.3

39.7

±0.2

24

46

±0.5

75

±1

3.2

3.2

±0.2

12.5

14.5

±1

8

10

±0.5

4

6.5

±0.5

2.2

2.2

±0.2

RB25/6

RB50/6

Tol.

RB/6 SERIES 11

EN 2010

Fixed power wirewound resistors

aluminium housed with large creep distance

RB25/6

RB50/6

RB/6 Series

 FIXED POWER WIREWOUND

RESISTORS ALUMINIUM HOUSED

WITH LARGE CREEP DISTANCE

ELECTRICAL SPECIFICATIONS

- Ohmic values

E24 Series. For out of range or not standard ohmic values, consult

ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1%

- Temperature coefficient

From ±100 to ±30 ppm from R10 to Rmax

- Dielectric strength

3000Vac / 4200Vac peak

- Large creep distance

RB25/6 > 6,5mm

RB50/6 > 10mm

- Insulation resistance

10000 MOhm minimum

1000 MOhm after moisture test

- Overload

5s at 5 times rated power

- Non inductive

Models of equivalent physical and electrical specifications are also available

with non inductive Ayrton-Perry winding

These resistors meet or exceed the requirements  of MIL - PRF - 18546  G

More technical data as RB25 / RB50 standard

D

C

E

F

G
H

J

A

K

∅

RB25/6 - RB50/6

H

N

M B

L

RB/7 Series

 FIXED POWER WIREWOUND

RESISTORS ALUMINIUM  HOUSED

WITH FASTON LEADS

ELECTRICAL SPECIFICATIONS

- Ohmic values

E24 Series. For out of range or not standard ohmic values, consult

ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1%

- Temperature coefficient

From ±100 to ±30 ppm from R10 to Rmax

- Dielectric strength

2500Vac / 3500Vac peak

- Insulation resistance

10000 MOhm minimum

1000 MOhm after moisture test

- Overload

5s at 5 times rated power

- Non inductive

Models of equivalent physical and electrical specifications are also available

with non inductive Ayrton-Perry winding

- Leads

6.35 mm Faston nickel plated steel, spot welding

These resistors meet or exceed the requirements of

MIL - PRF - 18546  G specifications

More technical data as RB25 / RB50 standard

ATE Type

MIL-PRF

18546 G Type

Rated

power (W)

Resistance

range (Ohm)

Voltage

limit (V)

Weight

(g)

Heatsink dimensions

(cm² x mm)

RB25/7
RB50/7

RE70
RE75

25
50

0.1 - 18K
0.1 - 68K

550

1250

13
32

535 x 1

930 x 1.5

ATE Type

Dimensions (mm)

A

B

C

D

E

F

G

H

J

K

L

M

P

19.8

69

21.5

±0.2

14

16

±0.2

27.7

29.2

±0.2

14

16

±0.2

6.5

7

±0.2

2

2

±0.2

18.3

39.7

±0.2

27

50

±0.5

91

±2

3.2

3.2

±0.2

21

20.5

±2

6.35

6.35

-

7.7

8.2

±1

RB25/7

RB50/7

Tol.

RB/7 SERIES

12

EN 2010

RB25/7

RB50/7

Fixed power wirewound resistors

aluminium housed with faston leads

G
H
J

A

B

K

RB25/7 - RB50/7

L

D

C

E

F

M

P

ATE Type

MIL-PRF

18546 G Type

Rated

power (W)

Resistance

range (Ohm)

Voltage

limit (V)

Weight

(g)

Heatsink dimensions

(cm² x mm)

RB50/8

RE75

50

0.1 - 68K

1250

52

930 x 1.5

ATE Type

Dimensions (mm)

A

B

C

D

F

G

H

J

K

L

M

N

P

Q

R

S

RB50/8

Tol.

21.5 16 29.2 16

2

39.7 50 79.5 3.2 14.5 M4

8

65 17.5 18.5 16.5

±0.2 ±0.2 ±0.2 ±0.2 ±0.2 ±0.2 ±0.5 ±2

±0.5

-

-

±0.5

±1

±0.5 ±0.5

±0.2

RB/8 SERIES 13

EN 2010

Fixed power wirewound resistors

aluminium housed with screw leads (TOP)

RB50/8

M

N

C

F

Q

G

H

J

A

B

K

RB50/8

S

P

L

R

Connection screws supplied with the resistor

RB/8 Series

 FIXED POWER WIREWOUND

RESISTORS ALUMINIUM HOUSED

WITH SCREW LEADS (TOP)

ELECTRICAL SPECIFICATIONS

- Ohmic values

E24 Series. For out of range or not standard ohmic values, consult

ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1%

- Temperature coefficient

From ±100 to ±30 ppm from R10 to Rmax

- Dielectric strength

2500Vac / 3500Vac peak

- Insulation resistance

10000 MOhm minimum

1000 MOhm after moisture test

- Overload

5s at 5 times rated power

- Non inductive

Models of equivalent physical and electrical specifications are also available

with non inductive Ayrton-Perry winding

- Leads

M4 threaded hole

-Terminal screw tightening torque

1,5Nm (static)

These resistors meet or exceed the requirements of

MIL - PRF - 18546 G specifications

More technical data as RB50 standard

RB106 Series

 FIXED POWER WIREWOUND

RESISTORS ALUMINIUM HOUSED

WITH LARGE CREEP DISTANCE

ELECTRICAL SPECIFICATIONS

- Ohmic values

E24 Series. For out of range or not standard ohmic values, consult

ATE Technical Dept.

- Tolerance

Standard 5%. Available on request up to 1%

- Temperature coefficient

From ±100 to ±30 ppm from R10 to Rmax

- Dielectric strength

5000Vac / 7000Vac peak

- Large creep distance

RB106 > 22mm

RB256 > 25 mm

- Insulation resistance

10000 MOhm minimum

1000 MOhm after moisture test

- Overload

5s at 5 times rated power

- Non inductive

Models of equivalent physical and electrical specifications are also available

with non inductive Ayrton-Perry winding

These resistors meet or exceed the requirements of

MIL - PRF - 18546 G specifications

More technical data as RB100 and RB250 standard

ATE Type

MIL-PRF

18546 G Type

Rated

power (W)

Resistance

Range (Ohm)

Voltage

limit (V)

Weight

(g)

Heatsink dimensions

(cm² x mm)

RB106
RB256

RE77
RE80

150
250

0.1 - 100K
0.1 - 120K

1900
2300

500
900

930 x 3
930 x 3

ATE Type

Dimensions (mm)

A

B

C

D

E

F

G

H

J

K

P

Q

R

S

T

V

Z

57.1 46 71.5 44.5 20

5

69.8 89 139 4.8

-

-

-

-

-

25 9.6 M5 32

12

63.5 54

76 55.6 25.5 6.3 98.4 114 178 4.8 22.2 76.2 32 7.8 M6 32

16

±0.2

±0.2

±2 ±0.2 ±0.2 ±0.2 ±0.2

±0.5 ±0.5 ±0.5 ±0.5 ±0.5

±0.5

±0.5

RB106

RB256

Tol.

RB106 SERIES

14

EN 2010

RB106

RB256

Fixed power wirewound resistors

aluminium housed with large creep distance

G

Q

P

S

H

R

J

Z

ØV

K

A

T

 2 Nuts

 1 Washer

 1 Lock washer

RB106  -  RB256

D

E

F

C

B

DA

T Series

FEATURES

One of the main causes for electrical troubles on electrical and

electronic sets is due to the moisture which is formed on components

during variation of the ambient temperature.

A simple and economic way to avoid these problems, consists on

application of anti-condensation devices (Heaters) which maintain the

temperature inside the enclosure some degrees higher than the ambient

temperature in order to prevent moisture condensation.

The Heaters DAT100 and DAT150 have been developed for this

specific use.

Their main features are :

- Surface temperature limited to 70°C allows assembling without problems.

- A thermoswitch permits maximum power at very low temperatures, then

reduces the power dissipated till turn off the devices at +55°C.

- The DAT models are provided with simple clip mounting for 35mm DIN rail.

- Use of power wirewound resistors, under MIL-PRF-18546 G specs.,

increase reliability and suitable supply voltage.

 ANTI MOISTURE

DEVICES

Specifications

ELECTRICAL  SPECIFICATIONS

- Max power ratings :

DAT100 = 100W

                                  DAT150 = 150W

- Supply voltage:

Standard 220 Vac ± 20%

  On request any supply voltage from  24 Vac to 220 Vac

- Dielectric strength:

2000 Vac for any type

- Insulation resistance:

1000 MOhm minimum at 500 Vdc

P

 =

A  x  ∆T  x  K

A

 =  Console internal surface  (m²)

∆T

 =  Temperature difference  (°C)

K

 =  3.5W/m² °C  for plastic console

K

 =  5.5W/m² °C  for iron plate (closed room)

DAT150

DAT100

0

20

40

60

80

100

120

140

160

-30

-20

-10

0

10

20

30

40

50

60

70

Po

wer

 (W

)



.

Ambient Temperature  (°C)

2°C

5°C

10°C

15°C

20°C

30°C

1

2

3

4

5

6

7

8

9

10

0

100

200

300

400

500

Su

rface

  A

 (m

²)

.

Power (W)

∆

T

66

82

150

DAT SERIES 15

EN 2010

Anti moisture

devices

DAT100

DAT150

PR Series

FEATURES

Very good ratio Power / Volume.

Easy mounting and wiring with significant cost advantages.

Non inductive performance for high frequency applications.

One model for power up to 150W.

Suited to UL94-V0 application.

SOT227 configuration.

THICK FILM POWER

RESISTORS PR100

Specifications

ELECTRICAL SPECIFICATIONS

- Power rating :

100W (PR102  2 x 50W)

- Max power not trimmed :

150W (heatsink at 70°C)

- Resistance range:

From 1R0 to 1MOhm, E12 series

- Tolerance:

Standard  10%, up to 1% on request

- Temperature coefficient :

±100 ppm/°C

- Max Work Voltage :

1500 Vac

- Work Temperature Range :

From -55°C to +155°C

- Dielectric  Strength :

2500 Vac

- Insulation resistance :

> 10

5

 MOhm at 500V

- Partial discharge :

< 80 pC @ 2000 Vac (on request)

- Self inductance :

40 nH

- Capacitance to heatsink :

< 30 pF

- Overload :

2 Pn x 10 s

- Thermal resistance :

0.5 °C/W

- Heatsink flatness :

0.05 mm Max

- Heatsink surface finish :

6.3μm Max

- Thermal grease :

required

- Max torque for contact :

1.2 Nm (static)

- Max torque for mounting :

1.5 Nm (static)

- Weight :

18 g (PR100 / PR101)

                24 g (PR102 / PR103)

R

2

1

R

3

4

3

1

2

1

2

1

3

4

PR100

PR101

PR102

PR103

=

=

=

=

25

12,7

4,2

15

=

=

30

±0,2

=

=

38

=

=

R4

1

4

2

3

Nut M4

12

5,5

Ø

 4,2

0,8

4

10

Connection and mounting screws supplied with the resistor

0

40

80

120

160

200

0

20

40

60

80

100

120

140

160

Po

wer

 (W

)



.

Heatsink Temperature  (°C)

PR SERIES

16

EN 2010

Thick film power resistors

PR100-101

PR102-103

Specifications

ELECTRICAL SPECIFICATIONS

-Power rating:

250W (heatsink at 100°C)

-Resistance range:

From 1R0 to 1MOhm, E12 series

-Tolerance:

Standard 10%, up to 1% on request

-Temperature coefficient:

±100 ppm/°C

-Max Work. Voltage:

5000 Vac

-Work Temp. Range:

Da -55°C a +155°C

-Dielectric Strength:

7000 Vac (12000 Vac x PR250T)

-Insulation resistance:

> 10

5

MOhm at 500V

-Creep distance:

42 mm (65 mm x PR250T)

-Air gap distance:

16 mm (29mm x PR250T)

-Partial discharge:

< 10 pC @ 5000 Vac

-Self inductance:

80 nH

-Parallel capacitance:

40 pF

-Capacitance to heatsink:

< 120 pF

-Overload :

4 Pn x  10 s

-Thermal resistance:

0.15 °C/W

-Heatsink flatness:

0.05 mm Max

-Heatsink surface finish:

6.3 µm Max

-Thermal grease:

Required

-Max torque for contacts:

2Nm (static)

-Max torque for mounting:

2Nm (static)

-Weight:

100 g (130 gx PR250T)

-Options:

- For values R039 <R< 1R0 is available Metal Foil type

PR250M

               - Cable terminals

PR250C / PR250TC

PR Series

FEATURES

Very good ratio Power / Volume

Easy mounting and wiring with significant cost advantages.

Non inductive performance for high frequency applications.

One models for power applications up to 500W.

Suited to ULV94-V0 application.

 THICK FILM POWER

RESISTORS  PR250

0

100

200

300

400

500

600

0

20

40

60

80

100

120

140

160

Po

wer

 (W

)



.

Heatsink Temperature  (°C)

PR SERIES

17

EN 2010

Thick film power resistors PR250

PR250T

34

=

=

72

=

=

R 5,75

4,3

36

=

=

57

±0,2

=

=

59

=

=

M4 x 8

14

19

25

4

PR250

14

19

40

4

PR250T

Connection and mounting screws

supplied with the resistor

PR SERIES

18

EN 2010

Thick film power resistors

PR254

PR254T

Specifications

ELECTRICAL SPECIFICATIONS

-Power rating:

250W (heatsink at 100°C)

-Resistance range:

From 1R0 to 1MOhm, E12 series

-Tolerance:

Standard 10%, up to 1% on request

-Temperature coefficient:

±100 ppm/°C

-Max Work. Voltage:

5000 Vac

-Work Temp. Range:

From -55°C to +155°C

-Dielectric Strength:

7000 Vac (12000 Vac x PR254T)

-Insulation resistance:

> 10

5

MOhm at 500V

-Creep distance:

42 mm (65 mm x PR254T)

-Air gap distance:

16 mm (29mm x PR254T)

-Partial discharge:

< 10 pC @ 5000 Vac

-Self inductance:

80 nH

-Parallel capacitance:

40 pF

-Capacitance to heatsink:

< 120 pF

-Overload :

4 Pn x 10 s

-Thermal resistance:

0.15 °C/W

-Heatsink flatness:

0.05 mm Max

-Heatsink surface finish:

6.3 μm Max

-Thermal grease:

Required

-Max torque for contacts:

2Nm (static)

-Max torque for mounting:

2Nm (static)

-Weight:

125 g (155 g x PR254T)

-Opzioni:

Cable terminals

PR254C / PR254TC

R

4

1

R

3

2

PR252

R

4

1

R

3

2

PR254

R

Pn=2x110W@100°C

Pn=3x70W@100°C

3

1

4

2

PR251

R

4

1

R

3

2

PR253

Pn=2x110W@100°C

Pn=250W@100°C

PR Series

FEATURES

Very good ratio Power / Volume

Easy mounting and wiring with significant cost advantages.

Non inductive performance for high frequency applications.

One models for power applications up to 500W.

Suited to ULV94-V0 application.

 THICK FILM POWER

RESISTORS  PR254

34

=

=

72

=

=

R 5,75

4,3

36

=

=

57

±0,2

=

=

59

=

=

M4 x 8

14

19

25

14

19

40

4

4

PR254

PR254T

1 2

4 3

Connection and mounting screws supplied with the resistor

0

100

200

300

400

500

600

0

20

40

60

80

100

120

140

160

P

ower

 (

W

)





.

Heatsink Temperature (°C)

PR251

PR252, PR253

⇒

each resistor

PR254

⇒

each resistor

Specifiche

TECHNICAL SPECIFICATIONS

- Power rating :

3 W at 70°C, mounted on FR4 board 1.6 mm

- Resistance range :

from R10 to 10K. E12 series, other on request

- Tolerance :

Standard 5%, up to 1% on request

- TCR :

Typical values ±100 to ±30 ppm from R10 to 10K

- Maximum continuous working voltage :

200 Vac

- Thermal resistance :

50 °C/W

- Derating :

Linear from 70°C to 220°C

- Dielectric Strength :

1000 Vac

- Insulation resistance :

1000 MOhm minimum

- Overload :

5s at 5 times power rating

- Non inductive :

Ayrton-Perry winding, max. 4K7

- Weight :

2.5 g

- Climatic category :

55/220/56

- Packaging :

Reel 330 mm, blister 32 mm, pitch 12 mm,700 pcs

3SM SERIES 19

EN 2010

Surface mount power

wirewound resistors

3SM Series

FEATURES

Easy replacement of axial power wirewound resistors without

performance loss.

Performance improvement is obtained by close tolerance, very low

temperature coefficient and stability in operation under severe

environmental conditions.

High level reliability due to ceramic core chemically inert and centerless

ground, selected wire element and completely welded construction terminal

to terminal.

The whole assembly is silicon coated and thermoplastic UL94-V0

moulded to give maximum wire protection from -55°C to +220°C.

 SURFACE MOUNT POWER

WIREWOUND RESISTORS

4

7,5

±0,2

0,2

±0,1

4

4

15

4,6

Recommended pad size

20

±0,3

7

±0,2

7,5

±0,2

11,5

±0,2

=

1,5

= 1,5

2,2

2,2

Dimensions  (mm)

Via U.Scaletta 13 10094 Giaveno (TO) ITALY

Tel.: +39 011.93.78.575  Fax.: +39 011.93.78.463

www.ate-electronics.com  [email protected]

EN 2010

The information contained herein does not form part of a contract and are subject to change without notice. It is responsibility of the Customer to ensure that the component

selected from our set is suitable for the intended application. If in doubt please contact ATE Electronics s.r.l.
