Data Sheet
AS32 0R536
Mechanical Specifications (mm)
Electrical Specifications
Max Steady State Current upto 65°c: 36.60
A
J
300
Max Rec. Energy Rating:
Actual Failure Instantaneous Energy: 600
J
Ω
0.01
Resistance @ 100% Max Current:
Resistance @ 50% Max Current:
Ω
°c
199.00
Body Temperature at 100% Max Current:
Dissipation Constant: 78.2
mw/°c
Sec.
Thermal Time Constant:
Material Type (for Beta and Curve): B
D: 29.0
2
.5
7.8
T:
Lead Diameter
2
17.1
S:
L: 22.0
2
2
5.0
Coating Lead Run Down
(straight Leads)
B: 4.80
.2
.2
0.90
C:
±
±
±
±
±
±
±
±
ISO9001:2008 Certified
Resistance: 0.5
Ω
±
25 %
AS32 0R536
03/15/2011
Erin Landis
Mehdi Samii
Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com
Drawn by:
Date:
Approved By:
A
Revison:
