DATA SHEET

Part Number: MS32 1R036-L



Ordering Different Lead Types:



Inside Kinked Leads

Not available

Outside Kinked Leads  Use

–B

 after Ametherm’s Part #

For example: to order an outside kinked lead use part number MS32 1R036-

B
















Resistance @ 25

°

C

1

Ω

 ± 25%

Max Steady State Current Up to 65

°

C

36.0 A

Max Recommended Energy Rating

300.0 J

Actual Failure Point of Instantaneous
Energy

540.0 J

Resistance @ 100 % of Maximum Current

0.010

Ω



Resistance @ 50% of Maximum Current

0.022

Ω



Body Temperature @ Max Current

225

 °

C

Dissipation Constant

72.0 mW/

°

C

Thermal Time Constant

285 seconds

Material Type

“B”

Recommended Capacitance @ 240/440
VAC

5200

µ

F/1500

µ

F







D

30.0 ±2.5 mm

T

7.0 ± 1.0 mm

Lead Diameter

1.3 ± 0.1 mm

S

7.8 ± 2.0 mm

L

38.0 ± 9.0 mm

Coating Run Down
Straight Leads

5.0 ± 1.0 mm

B

9.22 ± 0.85 mm

C

4.50 ± 1.0 mm











Revision Date 3/16/2004

L



OUTSIDE

KINKED LEADS

S



STRAIGHT



LEADS



B



INSIDE

KINKED LEADS

S

S

D



D

D

C



T
