DATA SHEET
Ametherm, Inc
. 3111 N. Deer Run Road #4 Carson City, NV 89701
Telephone: (800) 808-2434 (775) 884-2434 Fax: (775) 884-0670
www.ametherm.com
Part Number: NT03 15152
Electrical
Specifications:
Mechanical
Specifications:
Revision Date: March 19, 2003
Zero-Power Resistance @ 25°C
150.0
Ω
±
10%
Resistance @ 0°C/ Resistance @ 50°C
5.60
±
1%
Resistance @ 25°C/ Resistance @ 125°C
14.1
±
2%
Beta
3169
±
2%
Temp Coefficient of Resistance @ 25°C
-3.42%/°C
Operating Temperature Range
-50°C
±
150°C
Maximum Permissible Power
0.45 W
Dissipation Constant
4.0mW/°C
Thermal Time Constant
10 seconds
Material Type
“G”
Max Steady State Current up to 65°C
0.250 A
Resistance @ Max Steady State Current
15.00
Ω
Max Instantaneous Energy
3.0 J
D
3.20 mm Max
T
3.20 mm Max
Lead Diameter
0.5 mm Nom
S
3.55 mm Nom
L
38.0 mm Min
Straight Leads
Standard
L
OUTSIDE
KINKED LEADS
S
STRAIGHT
LEADS
B
INSIDE
KINKED LEADS
S
S
D
D
D
C
T
