DATA SHEET
Ametherm, Inc
. 3111 N. Deer Run Road #4 Carson City, NV 89701
Telephone: (800) 808-2434 (775) 884-2434 Fax: (775) 884-0670
www.ametherm.com
Part Number: NT05 25311
Ordering Different Lead Types:
For example: to order an inside kinked lead use part number NT05 25311
-A
Electrical
Specifications:
Mechanical
Specifications:
Revision Date: August 12, 2002
Inside Kinked Leads
Use
-A
after Ametherm’s part #
Outside Kinked Leads
Not Available
Zero-Power Resistance @ 25°C
25.0K
Ω
±
10%
Resistance @ 0°C/ Resistance @ 50°C
10.45
±
1%
Resistance @ 25°C/ Resistance @ 125°C
38.7
±
1%
Beta
4250
±
1%
Temp Coefficient of Resistance @ 25°C
-4.78%/°C
Operating Temperature Range
-50°C/150°C
Maximum Permissible Power
0.45 W
Dissipation Constant
4.5mW/°C
Thermal Time Constant
10 seconds
D
5.0
±
0.5 mm
T
3.0 mm Max
Lead Diameter
0.5 mm Nom
S
5.0
±
0.2mm
L
38.0 mm Min
Straight Leads
Standard
L
OUTSIDE
KINKED LEADS
S
STRAIGHT
LEADS
B
INSIDE
KINKED LEADS
S
S
D
D
D
C
T
