Data Sheet

SL08 10002

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 2.00

A
J

10

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 20

J

Ω

0.30

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.50

Ω

°c

149.00

Body Temperature at 100% Max Current:

Dissipation Constant: 8.0

mw/°c
Sec.

14

Thermal Time Constant:

Material Type (for Beta and Curve): B

D:

8.0

max
max

5.0

T:

Lead Diameter

0.5

nom
nom

5.0

S:

L: 38.0

min

Coating Lead Run Down

(straight Leads)

B: 3.00

max
.5

1.77

C:

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 10.0

Ω

±

20 %

SL08 10002

04/08/2011

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com
