OUTSIDE

KINKED LEADS

S

STRAIGHT

LEADS

B

INSIDE

KINKED LEADS

S

S

D

D

D

C

T

Mechanical Specifications

D

8.0

0.5 mm

T

4.0

0.4 mm

Lead Diameter

0.5

0.1mm

S

6.4

2.0mm

L

38.0

3.0 mm

Straight Leads

Coating run down

5.0

1.0mm

B

7.5

3.50mm

C

1.50

0.2mm

Electrical Specifications

Resistance @ 25°c

16.0



 15%

Max Steady State Current Up to 65°c

2.0 A

Max recommended energy rating (Joules)

8.0 J

Actual failure point of instantaneous energy
(Joules)

20.0J

Resistance @ 100% of Max Current

0.46

Resistance @ 50% of Max Current

0.89

Body Temperature @ 100% Current rating

147°C

Dissipation Constant

9.0mW/°C

Thermal Time Constant

20seconds

Data Sheet --  SL08 16002
