Data Sheet

SL08 7R002

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 2.00

A
J

8

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 17

J

Ω

0.22

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.58

Ω

°c

144.00

Body Temperature at 100% Max Current:

Dissipation Constant: 90.0

mw/°c
Sec.

27

Thermal Time Constant:

Material Type (for Beta and Curve): B

D:

8.0

.3
.36

2.8

T:

Lead Diameter

0.5

.1
.5

5.5

S:

L: 38.0

9

Coating Lead Run Down

(straight Leads)

B: 7.50

3.5
.5

2.50

C:

µf

560

Maximum Capacitance @ 120 VAC:

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 7.0

Ω

±

20 %

SL08 7R002

09/05/2012

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com
