Data Sheet

SL10 12101

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 1.00

A
J

14

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 30

J

Ω

2.00

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 6.60

Ω

°c

137.00

Body Temperature at 100% Max Current:

Dissipation Constant: 10.0

mw/°c
Sec.

30

Thermal Time Constant:

Material Type (for Beta and Curve): M

D: 10.0

.5
.5

5.0

T:

Lead Diameter

0.5

Nom
Nom

5.1

S:

L: 38.0

Nom

.3

3.5

Coating Lead Run Down

(straight Leads)

B: 6.35

.6
.30

2.75

C:

±

±

±

±

±

±

±

±
