Data Sheet

SL10 2R505

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 5.00

A
J

30

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 65

J

Ω

0.12

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.22

Ω

°c

165.00

Body Temperature at 100% Max Current:

Dissipation Constant: 10.0

mw/°c
Sec.

25

Thermal Time Constant:

Material Type (for Beta and Curve): A

D: 10.0

max
max

4.5

T:

Lead Diameter

0.5

nom
nom

5.0

S:

L: 38.0

nom

max

3.0

Coating Lead Run Down

(straight Leads)

B: 5.00

nom
nom

C:

µf

2,000

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

520

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

File: E209153

Resistance: 2.5

Ω

±

30 %

SL10 2R505

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
