Data Sheet

SL10 50002

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 2.00

A
J

18

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 29

J

Ω

0.44

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 1.20

Ω

°c

140.00

Body Temperature at 100% Max Current:

Dissipation Constant: 11.2

mw/°c
Sec.

38

Thermal Time Constant:

Material Type (for Beta and Curve): H

D: 10.0

max
max

4.0

T:

Lead Diameter

0.5

nom
nom

5.0

S:

L: 38.0

nom

max

3.5

Coating Lead Run Down

(straight Leads)

B: 6.35

nom
nom

2.82

C:

µf

900

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

225

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 50.0

Ω

±

25 %

SL10 50002

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com
