Data Sheet

SL12 10005

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 5.00

A
J

60

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 120

J

Ω

0.13

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.24

Ω

°c

172.00

Body Temperature at 100% Max Current:

Dissipation Constant: 12.7

mw/°c
Sec.

47

Thermal Time Constant:

Material Type (for Beta and Curve): C

D: 12.0

.50
.50

5.1

T:

Lead Diameter

0.8

Nom
Nom

7.8

S:

L: 38.0

Nom

Nom

3.5

Coating Lead Run Down

(straight Leads)

B:

Nom

2.80

C:

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

File: E209153

Resistance: 10.0

Ω

±

20 %

SL12 10005

04/08/2011

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:
