Data Sheet

SL15 10006

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 6.00

A
J

55

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 110

J

Ω

0.15

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.44

Ω

°c

172.00

Body Temperature at 100% Max Current:

Dissipation Constant: 15.9

mw/°c
Sec.

54

Thermal Time Constant:

Material Type (for Beta and Curve): G

D: 16.0

max
max

5.5

T:

Lead Diameter

0.8

nom
nom

7.8

S:

L: 38.0

nom

max

3.0

Coating Lead Run Down

(straight Leads)

B: 4.00

nom
nom

3.70

C:

µf

3,820

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

955

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 10.0

Ω

±

20 %

SL15 10006

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:

a

Revison:
