Data Sheet

SL15 22102

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 2.00

A
J

40

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 80

J

Ω

0.90

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 1.90

Ω

°c

191.00

Body Temperature at 100% Max Current:

Dissipation Constant: 18.0

mw/°c
Sec.

45

Thermal Time Constant:

Material Type (for Beta and Curve): L

D: 16.0

max
max

6.0

T:

Lead Diameter

0.8

nom
nom

7.8

S:

L: 38.0

nom

max

5.0

Coating Lead Run Down

(straight Leads)

B: 5.00

nom
nom

3.45

C:

µf

3,473

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

868

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

File: E209153

Resistance: 220.0

Ω

±

25 %

SL15 22102

07/15/2010

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:

a

Revison:
