Data Sheet

SL15 7R004

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 4.00

A
J

55

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 120

J

Ω

0.10

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.21

Ω

°c

157.00

Body Temperature at 100% Max Current:

Dissipation Constant: 18.0

mw/°c
Sec.

54

Thermal Time Constant:

Material Type (for Beta and Curve): C

D: 15.0

Max
Max

5.0

T:

Lead Diameter

0.8

Nom
Nom

7.8

S:

L: 38.0

Nom

Max

5.0

Coating Lead Run Down

(straight Leads)

B: 7.50

Nom
Nom

2.82

C:

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 10.0

Ω

±

20 %

SL15 7R004

04/26/2012

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
