DATA SHEET
Ametherm, Inc
. 3111 N. Deer Run Road #4 Carson City, Nv 89701
Telephone : 800-808-2434 775-884-2434 Fax: 775-884-0670
www.ametherm.com
Part Number: SL22 20008
Ordering Different Lead Types:
For example: to order an inside kinked lead use part number SL22 20008-
A
Electrical
Specifications:
Mechanical
Specifications:
CAPACITANCE VOLTAGE
(RMS)
10,000
µ
F
120
2150
µ
F
265
800
µ
F
440
420
µ
F
600
UL File Number: #E209153
Revision Date: June 12, 2002
Inside Kinked Leads
Use
-A
after Ametherm’s part #
Outside Kinked Leads
Use
-B
after Ametherm’s part #
Resistance @ 25°c
20.0
Ω
±
25%
Max Steady State Current Up to 65
°
C
7.0 A
Max Recommended Voltage
See Chart Below
Max Recommended Energy Rating (Joules)
150.0 J
Actual Failure Point of Instantaneous Energy (Joules)
275.0 J
Resistance @ 100% of Max Current
0.145
Ω
Resistance @ 50% of Max Current
0.295
Ω
Body Temperature @ 100% Current Rating
192 °C
Dissipation Constant
45.4mW/°C
Thermal Time Constant
164 seconds
Material Type
“H”
D
20.0
±
1.0 mm
T
5.0
±
0.2 mm
Lead Diameter
1.0
±
0.1 mm
S
7.8
±
2.0 mm
L
38.0
±
9.0 mm
Straight Leads
Coating Run Down
5.0
±
1.0 mm
B
9.35
±
0.85 mm
C
3.82
±
1.0 mm
L
OUTSIDE
KINKED LEADS
S
STRAIGHT
LEADS
B
INSIDE
KINKED LEADS
S
S
D
D
D
C
T
