Data Sheet
SL22 30005
Mechanical Specifications (mm)
Electrical Specifications
Max Steady State Current upto 65°c: 5.00
A
J
80
Max Rec. Energy Rating:
Actual Failure Instantaneous Energy: 175
J
Ω
0.39
Resistance @ 100% Max Current:
Resistance @ 50% Max Current: 0.75
Ω
°c
172.00
Body Temperature at 100% Max Current:
Dissipation Constant: 32.4
mw/°c
Sec.
94
Thermal Time Constant:
Material Type (for Beta and Curve): H
D: 22.0
max
max
6.0
T:
Lead Diameter
1.0
nom
nom
7.8
S:
L: 38.0
nom
max
5.0
Coating Lead Run Down
(straight Leads)
B: 11.50
nom
nom
3.95
C:
µf
5,200
Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:
µf
1,300
±
±
±
±
±
±
±
±
ISO9001:2008 Certified
File: E209153
Resistance: 30.0
Ω
±
20 %
SL22 30005
11/11/2008
Erin Landis
Mehdi Samii
Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com
Drawn by:
Date:
Approved By:
a
Revison:
