Data Sheet

SL22 50004

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 4.00

A
J

80

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 175

J

Ω

0.44

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.90

Ω

°c

162.00

Body Temperature at 100% Max Current:

Dissipation Constant: 32.4

mw/°c
Sec.

94

Thermal Time Constant:

Material Type (for Beta and Curve): M

D: 22.0

max
max

7.0

T:

Lead Diameter

1.0

nom
nom

7.8

S:

L: 38.0

nom

max

5.0

Coating Lead Run Down

(straight Leads)

B: 9.22

nom
nom

4.33

C:

µf

5,200

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

1,300

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

File: E209153

Resistance: 50.0

Ω

±

20 %

SL22 50004

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:

a

Revison:
