Data Sheet

SL32 2R023

Mechanical Specifications (mm)

Electrical Specifications

Max Steady State Current upto 65°c: 23.00

A
J

250

Max Rec. Energy Rating:

Actual Failure Instantaneous Energy: 495

J

Ω

0.02

Resistance @ 100% Max Current:

Resistance @ 50% Max Current: 0.07

Ω

°c

198.00

Body Temperature at 100% Max Current:

Dissipation Constant: 80.0

mw/°c
Sec.

194

Thermal Time Constant:

Material Type (for Beta and Curve): G

D: 31.0

max
max

6.0

T:

Lead Diameter

1.0

nom
nom

7.8

S:

L: 38.0

nom

max

5.0

Coating Lead Run Down

(straight Leads)

B: 7.80

nom
nom

4.00

C:

µf

17,366

Maximum Capacitance @ 120 VAC:
Maximum Capacitance @ 240 VAC:

µf

4,341

±

±

±

±

±

±

±

±

ISO9001:2008 Certified

Resistance: 2.0

Ω

±

20 %

SL32 2R023

11/11/2008

Erin Landis

Mehdi Samii

Ametherm, Inc.
3111 N. Deer Run Road
Carson City, Nevada USA 89701
www.ametherm.com

Drawn by:

Date:

Approved By:

a

Revison:
