NOTES:
1. SPECIFICATIONS CAN BE MODIFIED PER
    CUSTOMER REQUIREMENTS.
2. SEE DATA SHEET FOR ELECTRICAL
    SPECIFICATIONS.
3. QUANTY PER REEL 750

(18mm x .5mm thk)

(12.7mm) TYP

SL12 SERIES

1.000"

TYP

(25.4mm)

HEAT

TAPE

Reliability Delivered On Time

AMETHERM

SL12 SERIES

ON LS100-01 LEAD

TFM      03JUN02

DRAWN BY & DATE:

DRWG NAME:

LS100-01

LEAD

DRWG NO.:

AME-10456A

N/C

REV:

SCALE:

N/A

SHEET:

1

0.151"

(3.90mm) TYP

REASON FOR REVISION

.470" DIA.+/-0.020"
(12mm +/-0.50mm)

REV

(11.68mm +/-.64mm)

+/- .025"

.460"

DATE & BY
