NOTES:
1. SPECIFICATIONS CAN BE MODIFIED PER
    CUSTOMER REQUIREMENTS.
2. SEE DATA SHEET FOR ELECTRICAL
    SPECIFICATIONS.
3. QUANTY PER REEL 750

(18mm x .5mm thk)

(12.7mm) TYP

.500" +/-.005"

SL15 SERIES

1.000"

TYP

(25.4mm)

HEAT

TAPE

Reliability Delivered On Time

AMETHERM

SL15 SERIES

ON LS100-10 LEAD

TFM      03JUN02

DRAWN BY & DATE:

DRWG NAME:

LS100-10

LEAD

DRWG NO.:

REV:

SCALE:

N/A

AME-10456A

SHEET:

N/C

1

0.151"

(3.9mm) TYP

.590" DIA.+/-0.040"
(15mm +/-1.0mm)

REV

(6.85 mm +/-.64mm)

.270" +/- .025"

REASON FOR REVISION

DATE & BY
