Sure-Seal/Sure-White EPDM Accessories

EPDM ACCESSORIES

PRESSURE-SENSITIVE CURED COVERSTRIP

Fully cured synthetic rubber product used for
splicing cured EPDM membrane in ballasted,
adhered and mechanically fastened roofi ng
systems.

Sizes Available:

3" x 100' – Product Number: 300465 – Black
3" x 100' – Product Number: 303260 – White
6" x 100' – Product Number: 302952 – Black
6" x 100' – Product Number: 317501 – White

Quantity Per Box:

4 rolls (3"), 2 rolls (6")

Cured EPDM membrane pre-cut to 20" wide
with 6" PS SecurTAPE already applied. This
product provides the most effi cient way to fl ash
curbs and short walls.

Sizes Available:

20" x 50' – Product Number: 308705 – Black
20" x 50' – Product Number: 309112 – White

Quantity Per Box:

1 roll

FULLY PRESSURE-SENSITIVE CURB
FLASHING

Also Available (Not shown)

Sizes Available:

20" x 50' – Product Number: 315839 – Black

Quantity Per Box:

1 roll

Cured EPDM membrane laminated to a
synthetic rubber adhesive makes this product
the optimal solution to overlay seam fastening
plates, stripping in seams and metal edgings or
making roof repairs.

Sizes Available:

6" x 100' – Product Number: 308701 – Black
6" x 100' – Product Number: 308910 – White
9" x 100' – Product Number: 308839 – Black
9" x 100' – Product Number: 309121 – White
12" x 50' – Product Number: 317598 – Black
12" x 50' – Product Number: 317596 – White

Quantity Per Box:

2 rolls (6"), 1 roll (9" and 12")

Uncured EPDM laminated to synthetic rubber
adhesive. Pressure-Sensitive Elastoform
Flashing can be used to fl ash corners, pipes
and other penetrations.

Sizes Available:

6" x 100' – Product Number: 310443 – Black
6" x 100' – Product Number: 310434 – White
9" x 50' – Product Number: 303162 – Black
9" x 50' – Product Number: 309950 – White
12" x 50' – Product Number: 305723 – Black
12" x 50' – Product Number: 309951 – White

Quantity Per Box:

2 rolls (6"), 1 roll (9" and 12")

PRESSURE-SENSITIVE SECURTAPE

™

PRESSURE-SENSITIVE CURB FLASHING

PRESSURE-SENSITIVE ELASTOFORM FLASHING

Reinforced Universal Securement Strip RUSS
combines reinforced EPDM with 3"-wide Pressure-
Sensitive SecurTAPE for additional membrane
securement at the perimeter and pentrations. A 9"
version with 3"-wide Pressure-Sensitive SecurTAPE
on both sides permits fi eld securement of perimeter
sheeting on mechanically fastened systems.

Sizes Available:

6" RUSS – Product Number: 300490

–

Black

6" RUSS – Product Number: 309268

–

White

Use with all EPDM Systems

9" RUSS – Product Number: 300489

Use with Mechanically Fastened EPDM Systems

Quantity Per Box:

2 rolls (6"), 1 roll (9")

Semi-cured EPDM laminated to a synthetic
rubber adhesive. It is designed for stripping in
drip edges, all types of metal edging and Carlisle
Seam Fastening Plates.

Sizes Available:

6" x 100' – Product Number: 302319 – Black
9" x 100' – Product Number: 302281 – Black
12" x 50' – Product Number: 317600 – Black

Quantity Per Box:

2 rolls (6"), 1 roll (9" and 12")

PRESSURE-SENSITIVE RUSS

PRESSURE-SENSITIVE OVERLAYMENT STRIP

Roofi ng Systems

Sure-Seal/Sure-White EPDM Accessories

Uncured EPDM laminated to a synthetic rubber
adhesive. Required to overlay T-Joint intersections
of splices in the fi eld as well as at angle changes
for wall fl ashings. An additional 12" x 12" T-Joint
Cover is required for 30-Year Warranty Systems.

Sizes Available:

6" x 6" – Product Number: 303100 – Black
12" x 12" – Product Number: 305089 – Black

Quantity Per Box:

Uncured EPDM laminated to a synthetic rubber
adhesive. The pre-cut corners greatly reduce
installation time and can be used for inside and
outside corner installations.

Sizes Available:

7" x 9" – Product Number: 300199 – Black
7" x 9" – Product Number: 310310 – White

Quantity Per Box:

PRESSURE-SENSITIVE T-JOINT COVERS

PRESSURE-SENSITIVE INSIDE/OUTSIDE CORNERS

Uncured Sure-Seal EPDM Flashing with a synthetic
rubber adhesive and a 2" support strip pre-
applied to the fl ashing. Sizes can be combined to
form larger pockets when required.

Sizes Available:

4" diameter – Product Number: 300208 – Black
6" diameter – Product Number: 300209 – Black
6" diameter – Product Number: 316243 – White
8" diameter – Product Number: 300210 – Black

Quantity Per Box:

Cured EPDM with a synthetic rubber adhesive.
PS Pipe Seals increase the speed and ease of
installation.

Sizes Available:

½" – 3" – Product Number: 300204 – Black
1" – 6" – Product Number: 309750 – Black
1" – 6" – Product Number: 316593 – White

Quantity Per Box:

PRESSURE-SENSITIVE
POURABLE SEALER POCKETS

PRESSURE-SENSITIVE PIPE SEALS

Cured EPDM with a synthetic rubber adhesive.
Pressure-Sensitive Walkway Pads are designed
to protect the Carlisle EPDM membrane in areas
exposed to repetitive foot traffi c.

Sizes Available:

30" x 30" – Product Number: 300829 – Black
30" x 30" – Product Number: 309589 – White

Quantity Per Pallet:

An extruded EPDM product used to support steel
pipe, electrical conduit, PVC pipe and copper
tubing on Carlisle’s EPDM, TPO and PVC
roofi ng systems.

Sizes Available:

Mini: ½" - 1½" – Product Number: 309403
Small: ¾" - 2" – Product Number: 309402
Large: 2½" - 5" – Product Number: 309404

Quantity Per Box:

20 (Mini and Small), 10 (Large)

PRESSURE-SENSITIVE WALKWAY PADS

PIPE SUPPORTS

EPDM ACCESSORIES

THERMOPLASTIC ACCESSORIES

Thermoplastic Accessories

Non-reinforced thermoplastic membrane used to
fi eld-fabricate pipe fl ashings and scuppers when
the use of a pre-molded accessory is not feasible.

TPO

Sizes Available:

60-mil

12" x 50' – Product Number: 300473 – White
12" x 50' – Product Number: 300479 – Gray
12" x 50' – Product Number: 300476 – Tan
24" x 50' – Product Number: 300474 – White
24" x 50' – Product Number: 300480 – Gray
24" x 50' – Product Number: 300477 – Tan

Quantity Per Box:

1 roll

PVC

Sizes Available:

All 60-mil

12" x 50' – Product Number: 323792 – White/White
12" x 50' – Product Number: 323794 – Gray/Tan
24" x 50' – Product Number: 323793 – White/White
24" x 50' – Product Number: 323795 – Gray/Tan

Quantity Per Box:

1 roll

FLASHING

Pre-slit reinforced membrane used to overlay
fasteners, plates and to overlay end laps on
FleeceBACK

and Self-Adhering Technology (SAT

™

)

membranes.

TPO

Sizes Available:

45-mil

6" x 100' – Product Number: 300485 – White
6" x 100' – Product Number: 300486 – Gray
6" x 100' – Product Number: 302811 – Tan

60-mil

9" x 50' – Product Number: 310419 – White
9" x 50' – Product Number: 310417 – Gray
9" x 50' – Product Number: 310418 – Tan

80-mil

9" x 50' – Product Number: 318404 – White

Quantity Per Box:

3 rolls (6"), 2 rolls (9")

REINFORCED & NON-REINFORCED OVERLAYMENT

Available in 10" RUSS (shown) and used in place
of narrow-width sheets to secure membrane in
the perimeter of the roof on mechanically fastened
systems. 6" RUSS is also available and is used
to secure membrane at the base of vertical walls
for additional membrane securement without
penetrating the sheet.

Sizes Available:

6" x 100' – Product Number: 303373
10" x 100' – Product Number: 305442

Quantity Per Box:

1 roll (10"), 2 rolls (6")

Reinforced PVC Yellow Warning Strip can be used
on PVC to indicated roof edges or other hazards.

Sizes Available:

12" x 150' – Product Number: 322980

Quantity Per Box:

1 roll

Non-reinforced TPO laminated to pressure-
sensitive tape used for stripping in fl at metal
fl anges such as shop-bent drip edge.

Sizes Available:

6" x 100' – Product Number: 303102 – White
6" x 100' – Product Number: 303103 – Gray
6" x 100' – Product Number: 303104 – Tan

Quantity Per Box:

2 rolls

TPO PRESSURE-SENSITIVE RUSS

PVC YELLOW WARNING STRIP

TPO PRESSURE-SENSITIVE COVERSTRIP

YELLOW PS COVERSTRIP

Non-reinforced yellow TPO coverstrip can be used
on TPO or EPDM to indicate roof edges or other
hazards.

Sizes Available:

12" x 100' – Product Number: 318250

Quantity Per Box:

1 roll

Roofi ng Systems

PVC

60-mil

6" x 100' – Product Number: 310360 – White (Non-reinforeced)
6" x 100' – Product Number: 324792 – Gray/Tan (Non-reinforeced)
8" x 80' – Product Number: 318669 – White (KEE HP Reinforced)

80-mil

8" x 65' – Product Number: 318670 – White (KEE HP Reinforced)
8" x 65' – Product Number: 324413 – Gray (KEE HP Reinforced)
8" x 65' – Product Number: 324414 – Tan (KEE HP Reinforced)
8" x 65' – Product Number: 324000 – White (Reinforced Coverstrip)
8" x 65' – Product Number: 324045 – Gray Reinforced Coverstrip)
8" x 65' – Product Number: 324046 – Tan (Reinforced Coverstrip)

Quantity Per Box:

2 rolls (60-mil), 1 roll (80-mil)

Thermoplastic Accessories

Fabricated using 60-mil reinforced Sure-Weld

and Sure-Flex

™

membrane, square tubing wraps

are designed to fl ash square metal tubing. A split
and overlap tab are incorporated into these parts
to allow the fl ashings to be opened and wrapped
around a square penetration with an obstruction.
Other sizes and colors available through special
order.

TPO

Sizes Available:

3" x 3" – Product Number: 305576 – White
3" x 3" – Product Number: 000000 – Gray
3" x 3" – Product Number: 305576 – Tan
4" x 4" – Product Number: 305577 – White
4" x 4" – Product Number: 000000 – Gray
4" x 4" – Product Number: 305577 – Tan
5" x 5" – Product Number: 305578 – White
3" x 3" – Product Number: 000000 – Gray
5" x 5" – Product Number: 305578 – White
5" x 5" – Product Number: 305578 – Tan
6" x 6" – Product Number: 305579 – White
6" x 6" – Product Number: 000000 – Gray
6" x 6" – Product Number: 305579 – Tan

Quantity Per Box:

PVC

Sizes Available:

3" x 3" – Product Number: 307742 – White
4" x 4" – Product Number: 307745 – White
6" x 6" – Product Number: 307748 – White
3" x 3" – Product Number: 307743 – Gray
4" x 4" – Product Number: 307746 – Gray
6" x 6" – Product Number: 307749 – Gray

Quantity Per Box:

Injection-molded, pre-formed fl ashings.

TPO

Sizes Available:

¾"– 8" diameter – Product Number: 316534 – White
¾"– 8" diameter – Product Number: 316536 – Tan
¾"– 8" diameter – Product Number: 316535 – Gray

Quantity Per Box:

PVC

Sizes Available:

¾"– 8" diameter – Product Number: 316537 – White
¾" – 8" diameter – Product Number: 322959 – Gray
¾" – 8" diameter – Product Number: 323823 – Tan

Quantity Per Box:

SQUARE TUBING WRAPS

MOLDED PIPE SEALS

Fabricated fl ashings made of 60-mil reinforced
Sure-Weld and Sure-Flex membrane used for
fl ashing pipes with an obstruction that prevents
the use of a molded pipe seal. Other sizes and
colors available through special order.

TPO

Sizes Available:

1" – Product Number: 303504 – White
1" – Product Number: 307654 – Gray
1" – Product Number: 307648 – Tan
2" – Product Number: 303505 – White
2" – Product Number: 307655 – Gray
2" – Product Number: 307649 – Tan
3" – Product Number: 303506 – White
3" – Product Number: 307656– Gray
3" – Product Number: 307650 – Tan
4" – Product Number: 303507 – White
4" – Product Number: 307657 – Gray
4" – Product Number: 307651 – Tan
5" – Product Number: 303508 – White
5" – Product Number: 307658 – Gray
5" – Product Number: 307652 – Tan
6" – Product Number: 303509 – White
6" – Product Number: 307659 – Gray
6" – Product Number: 307653 – Tan

Quantity Per Box:

PVC

Sizes Available:

1" – Product Number: 307724 – White
1" – Product Number: 307725 – Gray
1" – Product Number: 307726 – Tan
2" – Product Number: 307727 – White
2" – Product Number: 307728 – Gray
2" – Product Number: 307729 – Tan
3" – Product Number: 307730 – White
3" – Product Number: 307731 – Gray
3" – Product Number: 307732 – Tan
4" – Product Number: 307733 – White
4" – Product Number: 307734 – Gray
4" – Product Number: 307735 – Tan
5" – Product Number: 307736 – White
5" – Product Number: 307737 – Gray
6" – Product Number: 307739 – White
6" – Product Number: 307740 – Gray

Quantity Per Box:

SPLIT PIPE SEALS

THERMOPLASTIC ACCESSORIES

Interlocking, two-piece, injection-molded and
weldable pockets used to waterproof pipe
clusters or other oddly shaped penetrations.

TPO

Sizes Available:

6" wide x 2" high
Can be adjusted from 7½" to 11½" in length
Product Number: 316539 – White
Product Number: 316540 – Gray
Product Number: 316541 – Tan

Quantity Per Box:

5 complete pockets

PVC

Sizes Available:

6" wide x 2" high
Can be adjusted from 7½" to 11½" in length
Product Number: 316542 – White

Quantity Per Box:

5 complete pockets

MOLDED SEALANT POCKETS

Reinforced TPO membrane laminated to
TPO-coated metal. This pocket is designed to
waterproof large penetrations such as I-beams
and clusters of pipes. Other sizes are available
through special order.

Sizes Available:

Custom sizes only

Quantity Per Box:

2 complete pockets

TPO PREFABRICATED SEALANT POCKETS

Fabricated fl ashings made of 60-mil reinforced
Sure-Weld membrane designed to reduce curb
fl ashing time. Each corner has a 6"-wide base
fl ange and a 12" overall height. One curb will
require 4 corners. Other sizes and colors available
through special orders. Can also be ordered in
1- or 2-piece wraps.

TPO

Sizes available:

7" Wrap for 12" Curb –
Product Number: 305062 – White
13" Wrap for 24" Curb –
Product Number: 305063 – White
19" Wrap for 36" Curb –
Product Number: 305064 – White

Quantity Per Box:

12 pieces or 3 complete curbs

PVC

Sizes Available:

7" Wrap for 12" Curb –
Product Number: 322973 – White
Product Number: 322970 – Gray
Product Number: 322977 – Tan
13" Wrap for 24" Curb –
Product Number: 322975 – White
Product Number: 322971 – Gray
Product Number: 322978 – Tan
19" Wrap for 36" Curb –
Product Number: 322976 – White
Product Number: 322972 – Gray
Product Number: 322979 – Tan

Quantity Per Box:

12 pieces or 3 complete curbs

CURB WRAP CORNERS

Thermoplastic Accessories

Roofi ng Systems

This profile is extruded from the same
weather-resistant TPO or PVC compound as
the membrane. The Contour Rib Profile is
secured to the TPO or PVC roofing membrane
to simulate a standing seam metal roofing
system. The physical dimensional stability of
the profile is enhanced with fiberglass and
the rectangular profile provides exceptional
shadow lines for aesthetic appeal.

TPO

Sizes Available:

10’ – Product Number: 324572 – White
10’ – Product Number: 324573 – Gray
10’ – Product Number: 324574 – Tan

Quantity Per Box:

PVC

Sizes Available:

10’ – Product Number: 321909 – White
10’ – Product Number: 321911 – Gray
10’ – Product Number: 321910 – Tan

Quantity Per Box:

CONTOUR RIB

™

Pre-molded and used for fl ashing inside and
outside corners on a variety of details.

TPO

Sizes Available:

One Size

Product Number: 300020 – Gray – Outside
Product Number: 300025 – Tan – Outside
Product Number: 300016 – White – Outside
Product Number: 307406 – White – Inside
Product Number: 307407 – Tan – Inside
Product Number: 307408 – Gray – Inside

Quantity Per Bag:

PVC

Sizes Available:

One Size

Product Number: 307715 – White – Outside
Product Number: 307712 – White – Inside
Product Number: 323936 – Gray/Tan – Outside
Product Number: 323935 – Gray/Tan – Inside

Quantity Per Bag:

INSIDE/OUTSIDE CORNERS

Heat-weldable walkway rolls designed to protect
Carlisle's TPO and PVC membranes in areas
exposed to repetitive foot traffi c and other hazards.

TPO

Sizes Available:

34" x 50' – Product Number: 310508 – White
34" x 50' – Product Number: 310509 – Gray
34" x 50' – Product Number: 310510 – Tan

Packaged Individually

PVC

Sizes Available:

36" x 60' – Product Number: 307711 – Gray

Packaged Individually

WALKWAY ROLLS AND PADS

Injection-molded non-reinforced fl ashings used
to seal T-Joint splice intersections.

TPO

Sizes Available:

4½" diameter – Product Number: 307476 – White
4½" diameter – Product Number: 307478 – Gray

4½" diameter – Product Number: 307477 – Tan

Quantity Per Box:

100

PVC

Sizes Available:

4½" diameter – Product Number: 308224 – White
4½" diameter – Product Number: 309494 – Gray
4½" diameter – Product Number: 309847 – Tan

Quantity Per Box:

100

24-gauge (0.6 mm) galvanized steel sheet that
is coated with a layer of .035" non-reinforced
fl ashing. Membrane may be welded directly to the
coated metal. The sheet is cut to the appropriate
width and used to fabricate metal drip edges or
other roof perimeter edging profi les.

TPO

Sizes Available:

10 Pcs/Pallet –
4' x 10' – Product Number: 309272 – White
4' x 10' – Product Number: 309273 – Gray

4' x 10' – Product Number: 309274 – Tan

25 Pcs/Pallet –
4' x 10' – Product Number: 303181 – White
4' x 10' – Product Number: 303183 – Gray

4' x 10' – Product Number: 303182 – Tan

PVC

Sizes Available:

10 Pcs/Pallet –
4' x 10' – Product Number: 307708 – White
4' x 10' – Product Number: 307709 – Gray
4' x 10' – Product Number: 307710– Tan

T-JOINT COVERS

COATED METAL

THERMOPLASTIC ACCESSORIES

Thermoplastic Accessories

ASTENERS & PLA

TES

Applicable to steel, 22-gauge and heavier, CDX
plywood and wood plank deck types. Can be
used to secure all EPDM membranes, RUSS and
insulation. Longer fastener sizes available as
special order.

Sizes Available:

", 2"– 15" (1" Increments)

Size & Quantity Per Box:

2"– 6": 1,000; 7"– 12": 500; 13"– 15": 250
1¼":1000

HP FASTENER

Fasteners & Plates

Sure-Seal & Sure-White EPDM

Sure-Weld TPO

Sure-Flex PVC

Applicable for concrete decks. Used to secure
Sure-Seal, Sure-Weld and Sure-Flex membranes
and for insulation securement.

Sizes Available:

2"– 6" (½" Increments)
7"– 12" (1" Increments)

Size & Quantity Per Box:

2"– 8": 500; 9"– 12": 250

CD-10 FASTENER

Applicable to cementitious wood fi ber,
lightweight concrete and gypsum decks. Can
be used to secure all EPDM, Sure-Weld and
Sure-Flex membranes and insulation.

Sizes Available:

2½"– 10" (½" Increments)

Size & Quantity Per Box:

2½"– 7": 500; 7½"– 10": 250

GYPTEC PLATE

Sizes Available:

2" Metal membrane plate
3" Metal insulation plate

Quantity Per Box:

1,000

GYPTEC FASTENER & PLATE

A #14 diameter fastener used for Sure-Tough,
Sure-Weld and Sure-Flex membrane securement
into wood and concrete decks. Also applicable
to insulation securement into steel, wood and
concrete decks.

Sizes Available:

2"– 12" (1" Increments)
14"– 24" (2" Increments)

Size & Quantity Per Box:

2"– 4": 1,000; 5"– 11": 500; 12"– 24": 250

HD 14-10 FASTENER

Applicable for Sure-Seal, Sure-Flex and Sure-Weld
mechanically-fastened and fully-adhered roofi ng
systems. Used in conjunction with a specially
designed 3” Lite Deck Metal Plate for insulation
attachment to gypsum, cementitious wood fi ber
(Tectum), and lightweight concrete decks. Features
an oversize diameter (0.312" shank) and a deep
coarse thread design for high pullout resistance.

Sizes Available:

", 3"– 10", 12" (1" Increments)

Size & Quantity Per Box:

"– 4": 500; 5"– 8": 250; 9",10",12": 125

HP LIGHT DECK FASTENER

A #12 diameter fastener applicable to wood
decks and steel, 22-gauge and heavier, decks.
Used only for insulation attachment.

Sizes Available:

2"– 8" (1" Increments)
1

", 2¼", 3"– 8" (1" Increments)

Size & Quantity Per Box:

2"– 8": 1,000

INSULFAST

™

FASTENER

A #15 diameter fastener applicable to steel,
wood and CDX plywood. Can be used to secure
Sure-Seal, Sure-Weld and Sure-Flex membranes.

Sizes Available:

2"– 8" (1" Increments)
10"– 16" (2" Increments)

Size & Quantity Per Box:

2"– 4": 1,000; 5"– 12": 500; 14"– 16": 250

HP-XTRA FASTENER

Also Available (Not shown)

A #21 diameter fastener applicable to steel, wood
and CDX plywood decks.

Sizes Available:

2" – 8" (1" increments)

Size & Quantity Per Box:

500 (2" – 6"), 250 (7" – 8")

HP-X FASTENER

™

& HP-XTRA FASTENER

A pre-assembled #12 diameter InsulFast
fastener and plastic or metal insulation plate
applicable to steel and wood decks. Used to
secure insulation only. Longer fastener sizes
available through special order.

Sizes Available:

2¼", 3" – 8" (1" Increments)

Size & Quantity Per Box:

2¼" – 8": 250; 10" – 12": 200

Applications requiring a fastener larger than 8"
should use fastener HD 14-10.

ASAP INSULFAST FASTENER AND PLATE

ASTENERS & PLA

TES

Fasteners & Plates

Pre-assembled HP Fastener and Polymer seam
plate applicable to steel, wood and CDX plywood
decks. Used to secure Sure-Tough membranes.

Sizes Available:

2"– 12" (1" Increments)

Size & Quantity Per Box:

2": 500; 3": 450; 4", 5": 400; 6": 350;
7", 8": 300; 9": 250; 10"– 12": 200

POLYMER PRE-ASSEMBLED

Along with the appropriate fastener (HP-X),
used to secure Sure-Flex membranes to steel,
concrete and wood decks.

Sizes Available:

1½" x 2¾" Oval – Product Number: 319985

Quantity Per Pail:

500

OVAL BARBED PLATE

A pre-assembled HP-X Fastener and Piranha
Plate

™

applicable to steel, wood and CDX

plywood decks. Used to secure Sure-Weld and
Sure-Flex membranes.

Sizes Available:

2"–10" (1" Increments)
12"–16" (2" Increments)

Size & Quantity Per Box:

2"– 9": 250; 10"– 12": 200; 14"– 16": 150

HP-X ASAP

A specially designed fastener with a ½" drill
point used for attaching Sure-Tough, Sure-Weld
and Sure-Flex membranes to structural steel
purlins (up to

") in standing seam metal roof

retrofi t applications.

Sizes Available:

4", 5", 6", 8" & 10"

Size & Quantity Per Box:

500

RETRODRILLER FASTENER

ASTENERS & PLA

TES

Fasteners & Plates

Sure-Seal & Sure-White EPDM

Sure-Weld TPO

Sure-Flex PVC

Used in conjunction with the HP fastener.
Required for EPDM membrane and RUSS
attachment for mechanically fastened roofi ng
systems over steel decks.

Sizes Available:

2" diameter

Quantity Per Box:

1,000

HP-XTRA POLYMER SEAM PLATE

Also Available (Not shown)

Used in conjunction with the HP-XTRA fastener.
Provides greater pullout resistance than the 2" HP
Polymer Seam Plate. Used to mechanically fasten
Sure-Tough EPDM membranes over steel decks.

Sizes Available:

" diameter

Quantity Per Box:

1,000

HP POLYMER SEAM PLATE

Can be used with the HP, HD 14-10 and CD-10
fasteners to mechanically attach all EPDM,
Sure-Weld and Sure-Flex membranes and RUSS
(excluding steel decks).

Sizes Available:

2" diameter

Quantity Per Box:

1,000

SEAM FASTENING PLATE

Applicable with InsulFast, HP, and CD-10
fasteners. Used for insulation securement only
on steel, wood and concrete decks. Available in
steel or plastic.

Sizes Available:

3" diameter

Quantity Per Box:

1,000

INSULATION FASTENING PLATE

Along with the Light Deck Fastener, used in
conjunction with a specially designed 3" Lite
Deck Metal Plate for insulation attachment to
gypsum, cementitious wood fi ber (Tectum), and
lightweight concrete decks.

Sizes Available:

3" diameter

Quantity Per Box:

500

LIGHT DECK METAL PLATE

3"-round, specially coated plates used with HP-X
Fasteners and the RhinoBond induction welding
system. Available in TPO and PVC versions.

Sizes Available:

3" diameter

Quantity Per Box:

500

RHINOBOND

PLATE

Along with the appropriate fastener, used to
secure Sure-Weld and Sure-Flex membranes
to steel, concrete and wood decks.

Sizes Available:

" diameter

Quantity Per Box:

1,000

HP-XTRA PIRANHA PLATE

Also Available (Not shown)

For use with HP-XTRA Fastener to secure Sure-Weld
and Sure-Flex membranes to steel and wood decks.

Sizes Available:

" diameter

Quantity Per Box:

1,000

PIRANHA PLATE

A Galvalume

™

coated metal that is used to

mechanically fasten EPDM membranes. The
bar can be easily cut to any desired length and
installed using using HP-X Fasteners.

Sizes Available:

1" wide x 10' long

Size & Quantity Per Box:

50 pcs; 500 Linear Feet

METAL FASTENING BAR

ASTENERS & PLA

TES

Fasteners & Plates

AccuTrac Plates are a 3" Square Flat Bottom
Plate made of Galvalume

coated steel.

AccuTrac Steel Insulation Plates should be used
when fastening insulation with the AccuTrac Tool.

Sizes Available:

Quantity Per Box:

1,000

ACCUTRAC PLATE (INSULATION)

Extruded aluminum bar that is designed for
securing and sealing compression type fl ashing
terminations. The bar features a top edge for
ease of applying Carlisle’s Lap Sealant for EPDM
installations or Universal Single Ply Sealant for
TPO installations. The bar can be easily cut to
any desired length.

Sizes Available:

1" wide x 10' long

Quantity Per Box:

50 pcs; 500 Linear Feet

TERMINATION BAR (ALUMINUM)

Designed for use with Carlisle's Termination Bar
or Seam Fastening Plates to secure membrane
to concrete block, brick or structural concrete
walls. A zinc plated steel pin is used to provide
excellent corrosion resistance while the zinc alloy
body provides excellent holding power.

Sizes Available:

1¼"

Quantity Per Box:

1,000

TERM BAR NAIL-IN

Specifi cally designed for use with Carlisle's Metal
Retrofi t Roofi ng System to secure membrane and
RUSS

™

to structural steel purlins. Are compatible

with 2" HP Polymer Plates, providing superior
backout resistance in standard 16 gauge Purlins.

Sizes Available:

3¾", 4¾", 5¾", 7", 8"

Quantity Per Box:

1,000

PURLIN FASTENERS FOR METAL RETROFIT
(MEMBRANE ATTACHMENT)

A
m
b
in

Specifi cally designed for coverboard securement
under Sure-Seal, Sure-White, Sure-Flex or
Sure-Weld Roofi ng Systems. Plates are stamped
from Galvalume – coated steel for long-term
protection against corrosion.

Sizes Available:

Quantity Per Box:

1,000

SECURFAST

™

INSULATION FASTENING PLATE

ADHESIVES & SEALANTS

A high-strength, solvent-based contact
adhesive that allows quick bonding of
cured fl ashings and membranes to various
substrates. It is a synthetic rubber adhesive
formulated specifi cally for application with a
½" medium nap roller with enough versatility
in the tack time to allow large areas to be
coated and adhered at one time. 90-8-30A
EPDM Bonding Adhesive is designed for
bonding Sure-White, Sure-Seal, Sure-Tough
and Epichlorohydrin membranes to approved
substrates. 90-8-30A EPDM Bonding Adhesive
is yellow in color.

Coverage Rate:

60 square feet per gallon of

fi nished surface

A high-strength, solvent-based contact
adhesive that allows bonding of all EPDM and
Sure-Weld TPO membrane to various porous
and non-porous substrates. This product also
meets the <250 gpl VOC content requirements
of the OTC Model Rule for Single-Ply Roofi ng
Adhesives. Mixing of adhesive is required.

Coverage Rate:

60 square feet per gallon of

fi nished surface

* Not Compliant in all CA counties

90-8-30A EPDM BONDING ADHESIVE

LOW-VOC BONDING ADHESIVE*

Packaging:

5-gallon pail

Product Number:

302124

Shelf Life:

12 months

Packaging:

5-gallon pail

Product Number:

303090

Shelf Life:

12 months

A high-strength, solvent-based contact
adhesive that allows bonding of Sure-Weld
membrane to various porous and non-porous
substrates. Sure-Weld Bonding Adhesive is
yellow in color and should be stirred thoroughly
until all settled pigments are dispersed and the
adhesive is uniform in color.

Coverage Rate:

60 square feet per gallon of

fi nished surface

SURE-WELD TPO BONDING ADHESIVE

Packaging:

5-gallon pail

Product Number:

302099

Shelf Life:

12 months

Sure-Seal & Sure-White EPDM

Sure-Weld TPO

FleeceBACK

Multiple-Ply Systems

Sure-Flex PVC

Low VOC Product

Adhesives & Sealants

A high-strength, solvent-based contact
adhesive that bonds EPDM membranes to
various porous and non-porous substrates.
This product meets the <250 gpl VOC content
requirements of the OTC Model Rule for Single-
Ply Roofing Adhesives. EPDM x-23 Low-VOC
Bonding Adhesive is compatible with HP-H
and SecurShield

™

polyisocyanurate insulation,

structural and lightweight insulating concrete,
APA non-fire treated plywood, oriented
strand board, wood fiberboard, SECUROCK

DensDeck

Prime, masonry, and various

metal finishes. EPDM x-23 Low-VOC Bonding
Adhesive is easily applied with a 9" (228 mm)
medium nap roller, creating a strong adhesive
bond between the membrane and substrate.
Mixing of adhesive is required.

Coverage Rate:

60 square feet per gallon of

fi nished surface

EPDM X-23 LOW-VOC BONDING ADHESIVE

Packaging:

5-gallon pail

Product Number:

324002

Shelf Life:

12 months

A high-strength, solvent-based contact
adhesive that allows bonding of all EPDM and
Sure-Weld TPO membrane to various porous
and non-porous substrates. This product meets
the requirements for SCAQMD regulations.
Mixing of adhesive is required.

Coverage Rate:

60 square feet per gallon of

fi nished surface

LOW-VOC BONDING ADHESIVE 1168*

Packaging:

5-gallon pail

Product Number:

303090

Shelf Life:

12 months

A high-strength, solvent-based contact
adhesive that allows bonding of PVC and
KEE-enhanced PVC membrane to various
porous and non-porous substrates. It is
specially formulated using a blend of
VOC-exempt and nonexempt solvents.
This product also meets the <250 gpl VOC
content requirements of the OTC Model Rule
for Single-Ply roofi ng adhesives. Mixing of
adhesive is required.

Coverage Rate:

60 square feet per gallon of

fi nished surface

A water-based, wet lay-in, one-sided dispersion
adhesive to be used with all Sure-Flex PVC
smoothbacked and FleeceBACK membranes
in adhered systems. It is specially formulated
to be in compliance with the state of California
Clean Air Act of 1988 (updated in 1997) and
as further regulated by California’s Air Quality
Control District’s listing of VOC limitations.
This product also meets the requirements of
the OTC Model Rule for Single-Ply Roofi ng
Adhesives. HydroBond is ideal for bonding
PVC membranes to various porous and non-
porous substrates.

Coverage Rate:

Smooth-backed membrane:
Roller application – 100 square feet per gallon
of fi nished surface
Spray application – 133 square feet per gallon
of fi nished surface

FleeceBACK membrane:
Roller application – 100 square feet per gallon
over polyiso, DensDeck, DensDeck Prime/
SECUROCK

and plywood

Spray application – 100 square feet per gallon
over DensDeck and 133 square feet per gallon
over polyiso, DensDeck Prime/SECUROCK and
plywood

LOW-VOC PVC BONDING ADHESIVE

HYDROBOND

™

PVC WATER-BASED ADHESIVE

Packaging:

5-gallon pail

Product Number:

309126

Shelf Life:

12 months

Packaging:

5-gallon pail

Product Number:

322112

Shelf Life:

12 months

A semi-pressure-sensitive water-based
adhesive. This product may be used as a
two-sided contact adhesive with EPDM
and Sure-Weld TPO membranes or as a one-
sided adhesive for FleeceBACK membranes.
Aqua Base 120 is pink in color and dries
translucent/yellow.

Coverage Rate:

120 square feet per gallon of

finished surface. (May vary due to conditions
such as insulation type or wall construction.)

AQUA BASE 120 BONDING ADHESIVE

Packaging:

5-gallon pail

Product Number:

307431

Shelf Life:

12 months

A high-strength, low-odor, polymer-based
adhesive that allows fast installation of EPDM
membranes and cured fl ashings to various
substrates. This adhesive is specially designed
for installing Carlisle’s Sure-Seal and
Sure-White non-reinforced EPDM membranes.

Coverage Rate:

100 square feet per gallon of

fi nished surface

SOLVENT-FREE EPDM BONDING ADHESIVE

Packaging:

5-gallon pail

Product Number:

318127

Shelf Life:

6 months

ADHESIVES & SEALANTS

Adhesives & Sealants

ADHESIVES & SEALANTS

Designed for one-step priming of EPDM and TPO
surfaces prior to the application of pressure-
sensitive products. It is a Low-VOC product that
is ideal for use where environmental issues are
a concern.

Coverage Rate:

As high as 700 square

feet per gallon with TPO or Kleen EPDM
membrane.
Approx. 250 square feet per gallon with
dusted EPDM membrane.

A high-solids, clear polymer-based primer
used to prepare TPO membrane prior to the
application of TPO pressure-sensitive products.

Coverage Rate:

200 – 250 square feet (one

surface) per gallon.

TPO PRIMER

LOW-VOC PRIMER

Packaging:

(6) 1-gallon cans

Product Number:

310471

Shelf Life:

12 months unopened can

Packaging:

(6) 1-gallon cans

Product Number:

316522

Shelf Life:

9 months

A solvent-based product designed for priming
of Carlisle’s EPDM membrane prior to the
application of PS SecurTAPE, FAT

™

and all other

PS products.

Coverage Rate:

As high as 450 square feet

per gallon with Kleen EPDM membrane. Approx.
250 square feet per gallon with standard
membrane.

HP-250 EPDM PRIMER

Packaging:

(6) 1-gallon cans

Product Number:

302070

Shelf Life:

9 months

Adhesives & Sealants

Sure-Seal & Sure-White EPDM

Sure-Weld TPO

FleeceBACK

Multiple-Ply Systems

Sure-Flex PVC

Low VOC Product

An asphalt-modifi ed polyether, one-sided,
wet lay-in adhesive designed to adhere to
FleeceBACK AFX membranes and Carlisle’s
modifi ed base sheet.

Coverage Rate:

67 square feet per gallon

of fi nished surface for smooth surfaces.
50 square feet per gallon of fi nished
surface for uneven surfaces.

A low-rise, two-component, insulating
polyurethane adhesive. It can be used to
adhere a variety of insulations and Carlisle’s
FleeceBACK membranes, and is applied in
full spray or beads.

Coverage Rate:

See Product Data Sheet.

FAST

™

ADHESIVE

COLD APPLIED ADHESIVE

Packaging:

5-gallon pail

Product Number:

319689

Shelf Life:

9 months when stored below 90˚F

Packaging:

50-gallon drum – Part A – Product Number: 304003

50-gallon drum – Part B – Product Number: 304004

15-gallon drum – Part A – Product Number: 304001

15-gallon drum – Part B – Product Number: 304002

Bag-in-a-Box – Part A – Product Number: 317332 – Also available (not shown)

Bag-in-a-Box – Part B – Product Number: 317333 –

Also available (not shown)

Static Mixing Tip:

305573

Dual Cartridge –

Product Number: 310150

Dual Cartridge IC (Winter Grade) – Product Number: 310513

Shelf Life:

12 months (Part A and Part B)

A high-strength, solvent-based contact adhesive that
bonds EPDM membranes to various porous and non-
porous substrates. This product meets the <250 gpl\
VOC content requirements of the OTC Model Rule
for Single-Ply Roofi ng Adhesives. EPDM x-23 Low-
VOC Bonding Adhesive is compatible with HP-H and
SecurShield

™

polyisocyanurate insulation, structural

and lightweight concrete, plywood, oriented strand
board, wood fi berboard, SECUROCK

, DensDeck

Prime,

masonry, and various metal fi nishes. Mixing of adhesive
is required.

Coverage Rate:

See Product Data Sheet.

FLEXIBLE FAST ADHESIVE

Packaging:

50-gallon drums – Part A – Product Number: 310472

50-gallon drums – Part B – Product Number: 310473

15-gallon drums – Part A – Product Number: 317329

15-gallon drums – Part B – Product Number: 317331

Dual Cartridge – Product Number: 322958

Shelf Life:

12 months (Part A and Part B)

CCW-702 is a solvent-based, high-tack adhesives
specifically designed to promote maximum
adhesion of Carlisle 725TR Air and Vapor Barrier to
approved substrates. It is also used as a surface
prep to promote adhesion with FAST Adhesive.

Coverage Rate:

300-350 square feet per gallon.

This cleaner is specially formulated to clean
both new and in-service Sure-Flex membrane.

Coverage Rate:

400 square feet (one surface)

per gallon.

CCW-702 PRIMER

PVC MEMBRANE CLEANER

Packaging:

5-gallon pails

Product Number:

305363

Shelf Life:

12 months

unopened container

Packaging:

5-gallon closed-top pail

Product Number:

308352

CAV-GRIP is a multi-purpose contact adhesive/
primer recommended for enhancing the bond
of Carlisle’s 725TR Air and Vapor Barrier.
CAV-GRIP can also be used as a primer for
unexposed asphalt.

Coverage Rate:

50-55 square feet per lb,

2,000-2,500 square feet per cylinder for 725TR
or priming unexposed asphalt.

CAV-GRIP

™

Packaging:

40-lb aerosol

cylinder

Product Number:

305432

Shelf Life:

12 months

unopened container

Carlisle’s Weathered Membrane Cleaner is used
to clean both new and in-service Sure-Seal
EPDM membrane and Sure-Weld TPO
membrane prior to the welding process.
It helps to loosen and remove dirt and
other contaminants from the surface of the
membranes and leaves a suitable surface
for application of adhesive or primer. Please
refer to the Product Data Sheets for specifi c
instructions for EPDM and TPO applications.
Membrane cleaner is clear in color.

Coverage Rate:

400 square feet (one surface)

per gallon.

WEATHERED MEMBRANE CLEANER

Packaging:

(2) 1-gallon closed-top cans,
5-gallon closed-top pail

1-gallon cans

Product Number:

304066

5-gallon pail

Product Number:

302074

* Not Compliant in all CA counties

ADHESIVES & SEALANTS

Adhesives & Sealants

CCW-702LV is a solvent-based, high-tack
adhesives specifically designed to promote
maximum adhesion of Carlisle 725TR Air and
Vapor Barrier to approved substrates. It is also
used as a surface prep to promote adhesion
with FAST Adhesive.

Coverage Rate:

300-350 square feet per

gallon.

CCW-702LV PRIMER

Packaging:

5-gallon pails

Product Number:

316148

Shelf Life:

12 months

unopened container

ADHESIVES & SEALANTS

A 100%-solids, solvent-free, one-part,
polyether sealant that provides a weathertight
seal to a variety of building substrates.
Universal Single-Ply Sealant can be used
as a termination bar sealant for Sure-Weld,
Sure-Flex and Sure-Seal white adhered and
mechanically fastened roofi ng systems. It is
also an excellent product for use in counter
fl ashing, coping and scupper details. Universal
Single-Ply Sealant has excellent adhesion to
substrates such as stone, masonry, ceramic,
marble, wood, steel, aluminum, Kynar

-coated

metal, most plastics and composites. Universal
Single-Ply Sealant is not recommended as a
glass glazing sealant.

Coverage Rate:

25' per tube or 600' per

carton using a ¼" bead.

The consistency enables it to expand and
contract with membrane movement without
loss of adhesion. Lap Sealants may be used to
seal mechanical terminations, the cut edges of
Sure-Tough EPDM membranes and for sealing
at splice intersections. Lap Sealant must be
applied and feathered on all seam edges by the
end of the working day.

Coverage Rate:

22' per tube using a

bead.

UNIVERSAL SINGLE-PLY SEALANT

SURE-SEAL AND SURE-WHITE LAP SEALANTS

Packaging:

25 Tubes/carton

Product Number:

310131

Shelf Life:

12 months

unopened container
(@ <90°F)

Packaging:

25 Tubes/carton

Product Number:

302174 – Black
302172 – White

Shelf Life:

12 months

A one-component, low-viscosity, self-wetting,
butyl-blend mastic designed to be used in
conjunction with roofi ng and waterproofi ng
systems. It is primarily used as a sealing agent
between various membranes and applicable
when membrane is being terminated using a
compression-type seal. Water Cut-Off Mastic
is an extremely tacky material and will remain
as such when used with compression type
terminations. Mastic is gray in color.

Coverage Rate:

10' per tube, using a

bead.

TPO CUT EDGE SEALANT

A free-fl owing polymeric material designed
for sealing cut edges (exposed fabric) of
Sure-Weld TPO membrane. Cut Edge Sealant
is clear in color.

Coverage Rate:

225'-275' per 16-oz. bottle

when applied with

" bead.

PVC CUT EDGE SEALANT

Also Available (Not shown)

PVC Cut Edge Sealant is recommended for
sealing cut edges (exposed fabric) of Sure-Flex
PVC Membrane. Cut Edge Sealant is clear
in color.

Packaging:

(

12) 16-oz.

Bottles/carton

Product Number:

307754

Shelf life:

12 months

Coverage Rate:

225'-275' per

bottle when applied with

" bead.

CUT EDGE SEALANT

Packaging:

(8) 16-oz.

Bottles/carton

Product Number:

303436 – Clear

Shelf Life:

12 months

WATER CUT-OFF MASTIC

Packaging:

25 Tubes/carton

Product Number:

319621

Shelf Life:

12 months

unopened container

** Certain restrictions apply, see Product Data Sheet.

Adhesives & Sealants

Sure-Seal & Sure-White EPDM

Sure-Weld TPO

FleeceBACK

Multiple-Ply Systems

Sure-Flex PVC

Low VOC Product

A single-component, moisture-curing,
elastomeric polyether sealant that is
compatible with Carlisle’s EPDM, TPO and PVC
membranes. It is designed to provide a fl exible,
durable and long-lasting seal around hard-to-
fl ash penetrations. The sealant’s consistency
allows for quick pocket fi lling without mixing.
Unused sealant is usable for up to 30 days if
pouch is resealed with original cap. Sure-Seal
one-part pourable sealer is black in color. One-
part pourable sealer is white in color.

Coverage Rate:

122 cubic inches of volume

per ½-gallon pouch.

A two-component, solvent-free, polyurethane-
based product compatible with Carlisle’s
Sure-Seal and Sure-White

™

membranes. It is

designed to provide a fl exible, durable and long-
lasting seal around hard-to-fl ash penetrations
in Sure-Seal and Sure-White Roofi ng Systems.
The product can also be used to provide a
permanent tie-in between the Sure-Seal and
Sure-White membranes and a built-up roof
surface and for attaching lightning rod
bases and ground cable clips to the
membrane surface.

Coverage Rate:

2313 cubic inches of volume

per properly mixed 1-gallon

ONE-PART POURABLE SEALER

SURE-SEAL TWO-PART POURABLE SEALER

Packaging:

(4) ½-gallon

pouches per bucket

Product Number:

307647 – Black
307603 – White

Shelf Life:

12 months

unopened container

Packaging:

Part A – (2) 1-gallon pails/ctn.
Part B – (2) 1-pint cans/ctn.

Product Number:

302084

Shelf Life:

12 months

unopened container

Designed for splicing cured-to-cured EPDM
and butyl membranes as well as non-PS
EPDM uncured fl ashing. Splicing adhesives are
high- strength, solvent-based contact cements
which allow quick bonding of fl ashing, sheeting
and cured rubber seams. They are synthetic
rubber adhesives formulated specifi cally for
application with a ½" medium nap roller and/or
a ½"-thick paint brush with enough versatility
in the tack time of the fi lm to allow large areas
to be coated and adhered at one time.

Coverage Rate:

100 square feet per gallon.

This product is for use on non-warranted
projects only.

SPLICE CEMENT

Packaging:

(6) 1-gallon

cans – Black and White

Product Number:

302342 – Black
302147 – White

Shelf Life:

12 months – Black
9 months – White

ADHESIVES & SEALANTS

Adhesives & Sealants

INSULA

TION REFERENCE

SECURSHIELD

™

HP-NB POLYISO

SECURSHIELD

A rigid roof insulation panel composed of a closed-cell polyisocyanurate
foam core bonded to high performance coated glass facers. The premium
facer provides improved fi re and moisture resistance, enhanced wind uplift
performance and improved dimensional stability. Ideal for use in fully adhered
systems and achieves a UL Class A fi re rating at 3" on combustible decks.

Sizes:

4' x 4' and 4' x 8'

Thickness:

1" to 4

⁄

Compressive Strength:

20 and 25psi

A rigid roof insulation composite panel composed of closed-cell
polyisocyanurate foam core bonded to a fi ber-reinforced facer on one side
and either

⁄

" or

⁄

" oriented strand board (OSB) on the other.

⁄

" and

⁄

plywood, as well as FSC Certifi ed OSB and plywood options are also available.

Sizes:

4' x 8'

Thickness:

1" to 4

⁄

A rigid roof insulation panel composed of a closed-cell polyisocyanurate foam
core bonded to enhanced high performance coated glass facers providing a UL
Class A fi re rating at only 1" on combustible decks.

Sizes:

4' x 4' and 4' x 8'

Thickness:

Compressive Strength:

20 and 25psi

HP-H POLYISO

A rigid roof insulation panel composed of closed-cell polyisocyanurate foam
core bonded to fi ber-reinforced facers. Approved by UL and FM for direct
application over steel decks, polyiso provides the highest R-value per inch of
any commercially available insulation product.

Sizes:

4' x 4' and 4' x 8'

Thickness:

1" to 4

⁄

Compressive Strength:

20 and 25psi

Insulation Reference

TAPERED ACCESSORIES

SECURSHIELD HD COMPOSITE

SECURSHIELD HD AND HD PLUS

Hinged Target Sumps and Pre-Cut Hips and Valleys ship ready to install,
require no fi eld cuts and save valuable time on the roof. Multiple thicknesses
and slopes available to accommodate specifi c job conditions with no waste,
thus reducing disposal fees.

Sizes:

4' x 4' (Hip/Valley) and 8' x 8' (Sump)

Thickness:

As required by job

Compressive Strength:

As required by job

A unique composite insulation panel comprised of ½" high-density 100psi
polyiso cover board bonded during the manufacturing process to SecurShield
rigid Polyiso roof insulation. Eliminates the need for cover boards, reduces
inter-ply adhesives and saves labor on the roof. Achieves a UL Class A fi re
rating at 2" on combustible decks.

Sizes:

4' x 4' and 4' x 8'

Thickness:

2" to 4

⁄

Compressive Strength:

20 or 25psi (SecurShield)

and 100psi (Securshield HD)

A rigid roof insulation panel composed of ½" high-density, closed-cell
polyisocyanurate foam core bonded to a premium performance coated
glass facer specifi cally designed for use as a cover board. Provides 5 times
the R-value at 5 times less weight than traditional gypsum cover boards.
Enhanced performance of the HD Plus product provides a FM 1-90 wind uplift
rating with only 8 fasteners.

Sizes:

4' x 8'

Thickness:

⁄

Compressive Strength:

100psi (HD) and >100psi (HD Plus)

TAPERED POLYISO

A sloped rigid roof insulation panel composed of closed cell polyisocyanurate
foam core bonded to either high performance coated glass or fi ber-reinforced
facers. Designed to promote positive drainage and prevent ponding water with
design assistance available through Carlisle’s Tapered Design Team.

Sizes:

4' x 4' and 4' x 8'

Thickness:

⁄

" to 4

⁄

" (multiple layers utilized for increased thicknesses)

Compressive Strength:

20 and 25psi

INSULA

TION REFERENCE

Insulation Reference

INSULA

TION REFERENCE

Insulation Reference

CARLISLE SP EPS

CARLISLE HD EPS COMPOSITE

CARLISLE EPS (40/60 PSI)

Premium coated glass-faced insulation approved for mechanically-attached
or self-adhering systems without a slip sheet. Warranted long-term R-value
providing up to R30 in a single layer.

Sizes:

4' x 4' or 4' x 8'; custom sizes and taper panels available

Thickness:

⁄

" to 6"

Densities:

1.25 to 3 lb/ft

High-density polyiso cover board (

⁄

”) laminated to Carlisle engineered EPS.

5x times lighter than traditional cover boards and approved for both adhered
and mechanically attached systems, while providing enhanced protection
against severe weather and hail. Meets Title 24 requirements for continuous
insulation on combustible decks.

Sizes:

4' x 4' or 4' x 8'; custom sizes and taper panels available

Thickness:

⁄

" to 7" (including

⁄

" HD Polysio cover board)

Densities:

1 to 3 lb/ft

High compressive-strength engineered EPS. Ideal for plaza decks, garden or
vegetative roofs, IRMA and high traffi c areas that require additional strength
and water-resistance. Available in thicknesses up to 40" in a single layer.

Sizes:

4' x 4' or 4' x 8'; custom sizes and taper panels available

Thickness:

⁄

" to 40" per panel

Compressive Strength:

40 and 60 psi

CARLISLE EPS

Engineered rigid insulation consisting of high-performance, water-resistant
expanded polystyrene (EPS). Meets ASTM C578 requirements, includes
extensive UL and FM ratings and can be applied direct to the metal deck.
Warranted long-term R-value of up to 5.05/inch @40°F.

Sizes:

4' x 4' or 4' x 8'; custom sizes available

Thickness:

⁄

" to 40" per panel

Densities:

1 to 3 lb/ft

INSULA

TION REFERENCE

CARLISLE INSULLAM

CARLISLE EPS FLUTE-FILL

R-TECH

FANFOLD RECOVER

OSB, Plywood or Gypsum board laminated to Carlisle engineered EPS.
Approved for both adhered and mechanically attached systems, providing
enhanced protection against severe weather and hail. Can be utilized as a
nail base, is available vented and with a wide assortment of cover boards.

Sizes:

4' x 4' or 4' x 8'

Thickness:

1" to 6"

Laminate:

OSB

⁄

" and

⁄

"; Plywood

⁄

"; Gyp thickness varies

Custom cut, engineered EPS fl ute-fi ll insulation manufactured for virtually
any standing seam profi le. Meets ASTM C578 requirements and includes
extensive UL and FM ratings, including installations direct to metal deck.

Thickness, Shape and Size:

Custom manufactured to fi t any roof profi le

High performance water-resistant facers laminated to Carlisle engineered EPS.
Code-approved for recover applications and compatible with both light and
dark colored single-ply membranes. 5x times lighter than traditional cover
boards with a coverage rate of 200 sq. ft., saving time and labor on the roof.

Sizes:

2' x 4' (folded), 4' x 50' (unfolded)

Thickness:

⁄

CARLISLE EPS TAPER

Tapered engineered EPS insulation available in virtually any slope, with panels
up to 40" in a single layer. Can be combined with Carlisle polyiso for tapered
hybrid roof systems. Design assistance available through Carlisle’s Tapered
Design Team. Custom saddles and crickets also available.

Slope:

Virtually any slope

Thickness:

⁄

" to 40"

Densities:

1 to 3 lb/ft

Insulation Reference

EPDM REFERENCE

BALLASTED

ADHERED

MECHANICALLY

FASTENED

FLEECEBACK

AFX

COVERAGE RATE OR

AVAILABLE SIZES

PACKAGING

MEMBRANES

Sure-Seal Non-Reinforced
60- & 90-mil EPDM

4½' x 50'-50' x 200' per roll

Sure-White Non-Reinforced
60- and 90-mil White EPDM

10'-30' x 100' per roll

Sure-Tough Reinforced
60- & 75-mil EPDM

4½'-10' x 50-100' per roll

ADHESIVES & SEALANTS

Low-VOC Primer

400 sq. ft. per gallon (dusty

membrane) Up to 700 sq. ft. per

gallon (no-dust membrane)

(6) 1 gallon cans

per case

HP-250 Primer

250 sq. ft. per gallon (dusty

membrane) Up to 450 sq. ft. per

gallon (no-dust membrane)

(6) 1 gallon cans

per case

90-8-30A EPDM Bonding
Adhesive

60 sq. ft. per gallon

5 gallon pail

Solvent-Free EPDM Bonding
Adhesive

100 sq. ft. per gallon

5 gallon pail

Flexible FAST Adhesive

Aqua Base 120 Bonding
Adhesive

100-120 sq. ft. per gallon

5 gallon pail

Cold Applied Adhesive

67 sq. ft. per gallon

5 gallon pail

Low-VOC Bonding Adhesive

60 sq. ft. per gallon

5 gallon pail

Sure-Seal Black Lap Sealant

22' per tube

25 tubes per carton

Sure-White White Lap Sealant

22' per tube

25 tubes per carton

One-Part Pourable Sealer
(Black/White)

488 cubic inches per gallon

(4) ½ gallon pouches/bucket

FAST Dual Cartridge
Adhesive

600 sq. ft. (12" O.C.), 300 sq. ft. (6"

O.C.), 200 (4" O.C.)

4 sets per carton

Weathered Membrane Cleaner

400 sq. ft. per gallon

(2) 1 gallon cans or

(1) 5 gallon pail

Water Cut Off Mastic

10' per tube

25 tubes per carton

Pressure-Sensitive SecurTAPE

3" x 100', 6" x 100'

3" – 4 rolls per carton,

6" – 2 rolls per carton

EPDM SYSTEMS

(non-reinforced only)

BALLASTED

ADHERED

MECHANICALLY

FASTENED

FLEECEBACK

AFX

COVERAGE RATE OR

AVAILABLE SIZES

PACKAGING

FLASHINGS

Pressure-Sensitive
Elastoform EPDM Flashing
(Black/White)

6" x 100', 9" &

12" x 50"

6"- 2 rolls per carton

9" & 12"- 1 roll per carton

Pressure-Sensitive Cured
Coverstrip (Black/White)

6" x 100', 9" x 100'

& 12" x 50'

6" - 2 rolls per carton

9" & 12"- 1 roll per carton

Pressure-Sensitive
Overlayment Strip (Black)

6" x 100', 9" x 100' &

12" x 50'

6"- 2 rolls per carton

9" & 12"- 1 roll per carton

Pressure-Sensitive RUSS
(Black/White)

6", 9" x 100'

6"- 2 rolls per carton

9" - 1 roll per carton

Pressure-Sensitive Pipe Seals
(Black/White)

½" – 3" & 1" – 6" pipes

10 per carton

Pressure-Sensitive Pourable
Sealer Pockets (Black/White)

Black – 4", 6", 8"

White – 6" only

12 per carton

Pressure-Sensitive Inside/
Outside Corners (Black/White)

7" x 9"

20 per carton

Pressure-Sensitive Curb
Flashing (Black/White)

20" x 50',

with 6" tape

1 roll per carton

Fully Pressure-Sensitive Curb
Flashing (Black)

20" x 50'

1 roll per carton

Pressure-Sensitive T-Joint
Covers (Black)

6" & 12"

20 per carton

Pipe Supports

Mini:

" – 1

Small: ¾" – 2"

Large: 2

" – 5"

Mini & small 20 per

carton; large 10 per carton

BALLASTED

ADHERED

MECHANICALLY

FASTENED

FLEECEBACK

AFX

COVERAGE RATE OR

AVAILABLE SIZES

PACKAGING

ACCESSORIES

Pressure-Sensitive Molded
Walkway Pads (Black/White)

30" x 30"

50/pallet

Interlocking Rubber Pavers
(Black/TerraCotta)

24" x 24"

Single paver

HP Protective Mat

15' x 300'

Per roll

EPDM Expansion Joint-Edge

25 ft.

25 LF per carton

EPDM Expansion Joint-Field

25 ft.

25 LF per carton

EPDM REFERENCE

EPDM SYSTEMS

TPO/PVC REFERENCE

MECHANICALLY

FASTENED

ADHERED

FLEECEBACK

AFX

COVERAGE RATE

OR AVAILABLE SIZES

PACKAGING

TPO MEMBRANES

Sure-Weld 45-, 60- & 80-mil

4' to 12' x 100' roll

TPO ADHESIVES AND SEALANTS

Sure-Weld Bonding Adhesive

60 sq. ft. per gallon

5 gallon pail

Aqua Base 120 Bonding Adhesive

100-120 sq. ft. per gallon

5 gallon pail

FAST Adhesive

See PDS

Multiple

Low-VOC Bonding Adhesive

60 sq. ft. per gallon

5 gallon pail

Flexible FAST Adhesive

See PDS

Multiple

Weathered Membrane Cleaner

400 sq. ft. per gallon

1 gallon or 5 gallon pail

Cold Applied Adhesive

50-67 sq. ft. per gallon

5 gallon pail

White One-Part Sealant

122 cubic inches per .5 gallon (4) 0.5 gallon pouches/bucket

TPO Primer (Standard and Low-VOC)

200 to 250 sq. ft. per gallon

(6) 1 gallon cans/carton

TPO Clear Cut Edge Sealant

225 linear ft. per bottle

6 bottles per carton

Universal Single-Ply Sealant

25 ft. per tube (½" bead)

24 tubes, 10.1 fl . oz. each

TPO FLASHINGS

TPO Molded Pipe Seals (White/Gray/Tan)

¾" to 8"

8 per carton

TPO PS Coverstrip 6" x 100' (White/Gray/Tan)

6" x 100'

2 rolls per carton

TPO Non-Reinforced Flashing (White/Gray/Tan)

12" x 50' & 24" x 50'

1 per carton

TPO Split Pipe Seals (White)

1" to 6"

8 per box

TPO Square Tubing Wraps (White)

3", 4", 5", 6"

8 per box

TPO Inside Corners (White/Gray/Tan)

12 per bag

TPO Outside Corners (White/Gray/Tan)

12 per bag

TPO Curb Wrap Corners (White)

7", 13", 19”

12 per box

TPO Molded Sealant Pockets (White/Gray/Tan)

7.5" to 11" x 6" oval

5 per carton

TPO Sealant Pocket Extensions (White)

14" overall length; 10"

installed length

10 per carton

TPO PS RUSS

6" x 100'

2 rolls

TPO PS RUSS

10" x 100'

1 roll

TPO T-Joint Covers (White/Gray/Tan)

4.5" diameter

100 per box

ACCESSORIES

TPO Walkway Rolls (White/Gray/Tan)

34" x 50' roll

Per roll

TPO Coated Metal 4' x 10' (White/Gray/Tan)

4' x 10'

10 or 25 per skid

SURE-WELD TPO SYSTEMS

TPO/PVC REFERENCE

MECHANICALLY

FASTENED

ADHERED

FLEECEBACK

AFX

COVERAGE RATE

OR AVAILABLE SIZES

PACKAGING

TPO OR PVC FASTENERS

Insulfast Insulation Fasteners

" to 8"

1000 per package

3" Steel Insulation Plate

3" diameter

1000 per package

HP Fasteners (Insulation)

1 ¼" to 15"

500-1000 per package

HP-X Fasteners (Membrane)

2" to 22"

500-1000 per package

HP-X ASAP Fasteners (Membrane)

2" to 16"

150 to 250 per package

Piranha Plates

1000 per package

HP-XTRA Fasteners (Steel Deck Only)

2" to 12"

250-500 per bucket

TPO RhinoBond Plates

3" diameter

500 per package

PVC RhinoBond Plates

3" diameter

500 per package

MECHANICALLY

FASTENED

ADHERED

FLEECEBACK

COVERAGE RATE

OR AVAILABLE SIZES

PACKAGING

PVC MEMBRANES

Sure-Flex 50, 60 & 80 mil

See PDS

Sure-Flex PVC KEE 50, 60 & 80-mil

See PDS

PVC FLASHINGS

PVC Curb Wrap Corners (White/Gray/Tan)

7", 13", 19”

12 per box

PVC/KEE Coverstrip (White)

8" x 65', 8" x 80'

60-mil – 2 rolls per carton

80-mil – 1 roll per carton

PVC Flashing (White/Gray and White/Tan)

12", 24" x 50'

1 per carton

PVC T-Joint Covers (White/Gray/Tan)

4.5" diameter

100 per box

PVC Inside Corners (White/Gray/Tan)

12 per bag

PVC Outside Corners (White/Gray/Tan)

12 per bag

PVC Molded Sealant Pockets (White)

7 ½" x 6"

5 per carton

PVC Molded Pipe Seals (White/Gray)

¾" to 8" diameter pipe

8 per box

PVC Split Pipe Seals (White/Gray/Tan)

1" to 6" diameter pipe

8 per box

PVC Square Tubing Wraps (White/Gray/Tan)

3", 4", 6"

8 per box

PVC ADHESIVES AND SEALANTS

Low-VOC PVC Bonding Adhesive

60 sq. ft. per gallon

5 gallon pail

HydroBond PVC Water-Based Adhesive

100 and 135 sq. ft. per gallon

5 gallon pail

FAST Adhesive

See PDS

Flexible FAST Adhesive

See PDS

White One-Part Sealant

122 cubic inches per .5 gallon

(4) 0.5 gallon pouches/bucket

PVC Cut-Edge Sealant

225' to 275' (

" bead)

(12) 16 oz. bottles/carton

PVC Membrane Cleaner

400 sq. ft. per gallon

5 gallon pail

PVC COATED METAL & WALKWAY

White PVC Coated Metal

4' x 10' sheet

10 sheet/pallet

PVC Walkway Rolls (Gray)

36" x 60' (91.4 cm x 18.3 m)

Per roll

*Available in 60- and 80-mil only

SURE-WELD TPO SYSTEMS

SURE-FLEX PVC SYSTEMS
