Custom Fiber Optic Cables

While we do offer a complete selection of

pre-built fiber optic patch cables we often find

our clients have very specific requirements

and we are always ready to assist.

Be it Single-mode, Multi-mode, Simplex,

Duplex, LC, FC/APC or anything in-between,

we can build it!

In order to start a build we typically

need to know a few simple things

before we can begin building your

ideal cable.

• Fiber Mode (Single-mode or Multi-mode)

• Simplex, Duplex or Multi-fiber

• Connector Types

• Jacket Material (Riser, Plenum or LSZH)

• Length of the Cable

Of course cable requirements can get more

in-depth, especially when it comes to

multi-fiber assemblies. Here you can choose

from single fiber connectors, MTP/MPO’s

along with different combinations thereof.

You name it, we can build it!

We specialize in custom cable assemblies, it’s our bread

and butter, it’s what we do!

Fibertronics Standards

Fibertronics 12 Fiber, OM3, MPO cables use

Corning® ClearCurve® laser optimized

bend-insensitive fiber. This type of fiber allows

for tighter bends in your cables, so you can

route without worry. The fiber comes in the

form of 12 fiber, 3 mm micro-distribution

cable, with an aqua Plenum jacket, which is

rated for Riser and Plenum areas. The

micro-distribution format uses 12 fibers in a

loose tube jacket with protective aramid yarn,

allowing for more flexibility and a smaller

footprint than traditional ribbon cable.

We can also build these to your custom

specifications, including using a different

brand of fiber, different type of jacket, or even

customer-supplied cable. Options such as

OM4, LSZH jacket, ribbon cable, armored

cable, indoor/outdoor cable, and more are

available.

MTP / MPO Solutions

With a huge demand for more

bandwidth and more space

efficiency Multi-fiber Push-On

(MPO) connectors have an-

swered the call and provide up

to 24 or more fibers in a single

connector pushing up to and

beyond 100Gbps.

MTP® and MPO are often used interchange-

ably. MTP® is a registered trademark of US

Conec. Both MTP® and MPO are available

with standard or elite / low loss options.

At Fibertronics we terminate our cables with

both MPO and MTP® connectors, so please

be sure to specify with our sales staff if you

need genuine US Conec MTP® connectors.

www.fibertronics.com

We offer high-quality Network

Racks for housing standard 19″

rack-mount equipment-servers

as well as other devices such

as routers, UPS’ and audio /

video gear.

Our range of Network Racks allow for better

organization and management as well as

providing additional security and cable

management options while enabling better

airflow to the mounted devices.

Our racks can be used anywhere where there

is a need to house valuable telecom equip-

ment within future or existing data centers,

server rooms and network closets. They are

particularly suited to use within industrial

environments such as factory floors and

workshops.

A variety of accessories are also available.

Features & Specifications

• Standard 19” Network Rack Cabinets.

• Available heights include: 18U, 22U, 27U,

32U, 37U and 42U.

• Easy access removable side panels.

• A surface finish featuring Degrease, Acid

Pickling, Rust Prevention and Parkerizing,

Pure Water Cleaning and a Static

Electricity Powder Coating.

• Static load capacity of 1200kg (2646lbs).

Ventilation rate between 63% and 72%.

Network Racks

FIBER

TRONICS

In today’s world there is an

ever-increasing need for more

data, at even faster speeds.

The new MXC™ optical fiber connector

system, created by US Conec™ and distribut-

ed by Fibertronics, uses high-density

interconnect technology allowing for better

connections at even greater speeds!

Being able to support greater bandwidth than

traditional MT fiber optic connectors, MXC™

connectors are being rolled out wherever

high-speed data transmission is a top priority.

PRIZM MT™ Ferrule

Able to support up to 64 fibers each handling

one wavelength at 25 Gbps, the main

component of the MXC™ connector system is

the hermaphroditic PRIZM MT™ ferrule. This

allows for speeds of up 1.6 Tbit/s.

The dimensions of the MXC™ ferrule are the

same as those of a MT ferrule used in

MTP®/MPO connectors.

The key difference being that the PRIZM

MT™ ferrule tip supports 64 micro lenses

within 4 rows, each row containing 16 lenses.

MXC™ Connectors

www.fibertronics.com

Fibertronics now stocks the

US Conec™ PRIZM

LightTurn

Connector

Designed as a miniature detachable

connector the PRIZM® LightTurn® connector

provides passive alignment and novel

retention features allowing multiple

re-matings\perpendicular to the printed circuit

board.

This 12-fiber connector is made up of a

multi-fiber floating ferrule with a photonic TIR

lens enclosed in a protective housing. The

perpendicular mating capability saves vast

amounts of space on already densely packed

circuit boards.

Important Key Features

• TIR (total internal reflection) lens

• Wavelength independent optical grade

material

• Bidirectional components

• Integrated alignment pins

• Housing protects TIR lens array

• Ferrule float within the connector

• Pre-alignment latches on connector

housing

• Keyed for proper mating orientation

• Quick termination, no polishing

• Less than 1 minute light cure for epoxy

• Collimated light at optical interface

PRIZM

LightTurn

FIBER

TRONICS

01 | DESIGN

Once we receive your

custom cable order it is sent

through to our Cable Design

Department.

Here the materials needed

are listed and a diagram is

produced for use in the next

step of the process.

02 | BUILD

The required cables and

tubing are then pulled from

our extensive stock and

handed over to our skilled

Assembly Technicians.

They then begin the process

of cutting and putting

together the cables

according to the specific

requirements laid out the by

diagrams created in step 1.

Once completed the cables

are moved on to polishing to

ensure that the connectors

are in optimal condition and

testing the cables can begin.

03 | TEST

The type of testing

performed on the cables

generally depends on what

type of cables are being

built.

All cables are subjected to

basic testing using a

microscope. Once inspected

and approved they are sent

on to our Interferometry

Testing Department.

Our qualified Interferometry

Testers subject the cables

and connectors to numerous

tests such as insertion loss

and return loss in order to

ensure they meet, or exceed

industry standards.

Once completed each cable

has a print-out of its test

results bundled with it and

then it is then ready to be

carefully shipped to you.

FIBERTRONICS

Fibertronics offers flexible

options for our High Fiber

Count Patch panels

Our wall mounted fiber patch panels

accommodate up to 12 modular panels and

are equipped with routing guides to limit bend

radius and enhance strain-relief control.

The 16-gauge steel with corrosion-resistant

black powder coating provides excellent

protection for the fibers inside the housing.

Wall-mount available unloaded, as well as

being capable of becoming a full-splice

enclosure with mechanical terminations.

Upon request we can also pre-install various

types of fiber optic pigtails inside patch

panels, saving you a lot of time and effort.

Additionally we also offer a series of change-

able inside panels to fit different kinds of the

Adapter interfaces which will fit both round

and ribbon fiber optic cables.

Our rack mounted fiber patch panels can be

either drawer or economic type without a draw

design.

Features & Specifications

• 19” Standard

• Light weight and robust structure

• Changeable modules inside

• Suitable for both ribbon and round cable

• Various panels to fit different adapter

interfaces

• An improved design ensures that the fiber

optic cable bend radius is not less than

40mm

www.fibertronics.com

Patch Panels

FIBER

TRONICS

If you’re looking to connect

multiple devices over long

distances without wasteful

cable use, Fibertronics’

Fan-outs are the solution.

Also known as breakout cables, the most

common is the 24” fanout attached to a

1 meter long cable assembly. 900μm tubes

can be terminated with all connector types.

They are available in all fiber modes including

9/125, 50/125, 62.5/125, single-mode and

multi-mode with duplex breakouts.

We offer a wide range of MTP

/ MPO

products including single-mode or multi-mode

MPO and MTP Fan-Out assemblies.

Available Single-mode and

Multi-mode MTP patch cables

• MTP-LC

• MTP-LC/APC

• MTP-SC

• MTP-SC/APC

• MTP-ST

• MTP-FC

• MTP-FC/APC

• MTP-MU

• MTP-MT-RJ

• MTP-E2000

• Custom Designed Cable

For customers that require more testing,

interferometry test reports can be supplied

upon request, prior to assembly.

MTP

/ MPO end-face geometry, ferrule

radius of curvature, fiber height and core dip

are among some of the test data supplied.

Fan-Out Cables

From initial concept through to

final production, we work with

our customers to help bring

their ideas to life.

We often get very specific product requests

from customers and this is when our in-house

engineering department steps in.

How it works

Combining form, fit and function is essential

in ensuring the end result meets both your

needs and expectations. We’ll take the time

to listen carefully to your ideas and product

requirements. Once we have been supplied

with some rudimentary specs or drawings we

are ready to start work.

We begin this by creating accurate 3D

Models and Renders, as well as providing

highly detailed 2D Drawings.

During this phase, we try our best to stay

within industry standards whenever possible

to ensure compatibility and future-proofing.

Once everything has been approved and we

have been given final sign-off we can begin

the manufacturing process.

www.fibertronics.com

Engineering

www.fibertronics.com

Sheet Metal Fabrication

At Fibertronics we produce our own top notch, custom,

powder coated, metal products and specialized components.

Thanks to our industrial grade metal shop we

are constantly churning out high quality,

powder coated, metal products for use within

the industry.

This allows us to ensure the highest quality

standards but it also saves on expensive

imports and the time it takes to receive them.

With both money and time saved we are then

able to pass on those savings to our valued

customers. Proudly manufactured in the USA.

Some of our products include:

• Adapter Plates

• Cassettes

• Network Racks

• Patch Panels

• Network Rack Shelves

FIBER

TRONICS

When you’re out in the field

working on your own fiber optic

projects and installations you

want to make sure you are

working with the best tools

available.

Fibertronics supplies high end tools, cleaners

and testers from industry leading and well

known international manufactures, the likes of

which include Miller, Ripley, NoeClean, IBC

and Greenlee.

Just to name a few.

Our extensive range of products

includes the following:

• Optical Time Domain Reflectometer Fiber

Optic Testers (OTDR)

• Fusion Splicers

• Fiber Optic Cleaning Swaps

• Kevlar Cutters

• Adjustable Fiber Optic Strippers

• Fiber Optic Scribes

• Polishing Pucks

• Slitters

• Field Cleaver Kits

• Die Sets

• Inspection Microscopes

• MPO Cleaners

• Visual Fault Locators

• Splice Sleeves

www.fibertronics.com

Tools & Testers

www.fibertronics.com

If you’re in the market for

Ethernet Cables, you’ve most

likely come across different

types, including the most

common ones, Cat5e and Cat6

We offer both Cat5e (Category 5 Enhanced)

and Cat6 (Category 6) cable types.

Cat5e Cables

Our Cat5e cables are great at reducing

cross-talk and confining signals to different

channels, ensuring that the signals remain

strong and that there is minimal interference.

Cat5e Ethernet Cables are capable of

handling speeds of up to 1000 Mbps (known

as Gigabit Ethernet) at 100 MHz.

Cat6 Cables

Fibertronics Cat6 cables are a step above,

capable of handling speeds of up to 10 Giga-

bits (10x faster than Cat5e) at 250 MHz.

They also continue to improve the reduction

of cross-talk by making use of an internal

separator that isolates cable pairs from each

another. They are also entirely backwards

compatible with Cat5e installations.

Network Cables are available in

these colors.

Network Copper Cables

FIBER

TRONICS
