GORE

®

 Acoustic Vents

For Industrial Applications

RELIABLE ACOUSTIC PROTECTION

FOR MICROPHONES

Apertures are essential to sound transmission, but
they can also provide an easy point of entry for
liquids and particles that can degrade acoustic
quality and device reliability.

More effective microphone protection

GORE

®

 Acoustic Vents for Industrial Applications

combine the latest technological advancements with
more than 30 years of acoustic science expertise
to provide venting solutions for varied industrial
applications with sound monitoring or voice-control
features.

Enhanced sound with advanced ingress

protection

Our newest vents,

Series 400 for Superior Fluids &

Dust Protection

, reduce insertion loss to provide

enhanced acoustic quality. At the same time, they deliver
Gore’s highest level of protection against water, other
fluids and particles that could degrade device reliability
and longevity.

Typical industrial applications:

  Security cameras

  Two-way radios (industrial use)



Outdoor intercom

  Human/machine interface devices

  Smart farming



Traffic monitoring

  Washing machines

  Interactive information displays

  Robotic devices



Power grid devices

Our vents enhance acoustic
performance while reliably
protecting against damaging
contaminants.

GORE

®

 Acoustic Vents

Rising above

acoustic challenges

GORE Membrane
ensures pressure
equalization while
allowing sound
transmission

Liquid and particles
are repelled

Series 400 for Superior Fluids & Dust Protection —

Our most advanced ingress protection enables

outstanding acoustic performance

Series 400

 eliminates the typical trade-offs between reliable waterproofing

and superior sound quality. It provides both a high level of ingress
protection and superior sound quality, offering a balanced solution for
even the harshest environments.

Liquid protection that exceeds typical IP standards

Using Gore protocols, we tested Series 400 against the IPx8 standard.
The result: No water leakage while submerged at 2 meters for 30 minutes!
Series 400’s oleophobic membrane also effectively repels oils, common
industrial fluids and cleaning solutions that can threaten devices that use
ordinary vent materials. With this level of protection, Series 400 could
mean longer-lasting devices.

Particle protection that meets today’s needs

Of course, Series 400 has been qualified to meet the IP6x dust-proof
performance standard. Additional Gore test protocols that better reflect
real-world conditions also show how well this vent performs in assembled
devices. For example, Series 400 can protect against a wide range of
particles — even those associated with poor air quality, such as smog
and dust particulates which may be only 1–10 µm in size.

Series 200 for Splash & Dust Protection —

Good environmental protection combined with

enhanced broadband acoustic transparency

Series 200

 is for industrial devices that face dust and splash hazards yet

require very good acoustic performance. Our membrane maintains sound-
wave integrity, so it delivers reliable environmental protection without
compromising sound quality.

Protects against sprays and particles

Series 200’s oleophobic non-woven membrane provides a higher level
of spray protection at a given level of acoustic performance. Its three-
dimensional tortuous path structure also traps small particles much more
efficiently than ordinary woven mesh vents. By providing a more effective
barrier to particles of varied sizes and shapes while protecting against
acoustic degradation, Series 200 can enhance microphone performance
and device reliability.

Characteristics / Performance

Series 234

Series 434

Water protection: IP rating (IEC 60529)

 1



IPx4

IPx4, IPx5, IPx6, IPx7, IPx8

 2

Comparative water spray efficiency

 3

75%

100%

Dust protection: IP rating (IEC 60529)

 1

IP5x

IP6x

Insertion loss @ 1kHz

 4

 (ID 2.0 mm)

< 2.0 dB

< 2.0 dB

Membrane type

Cellulose  /PET non-woven

ePTFE

Membrane characteristic

Oleophobic

Reference thickness

 5

0.33 mm

0.20 mm

Membrane color

Dark gray

Black

Support ring

N/A

PET

Recommended part orientation

Mount on interior

of housing

Mount on interior

of housing or on PCB

Temperature resistance

–40 °C to 75 °C

–40 °C to 100 °C

Adhesive type installation

Silicone based

EU-RoHS

 6

Meets threshold requirements

1.  IP ratings for assembled devices depend on the design of the product housing. IPx5, IPx6 feasible with adequate protection grill or cap.

2.  Test parameters IPx8: 2.0 m water @ 30 min

3.  Per Gore Water-Spray-VSZ-WI-026: based on IEC60529 - IPx4, test plate: thickness: 2.0 mm; hole: 2.54 mm, average spray efficiency

0% efficiency represents open conditions; 100% represents waterproof

4.   Tested using a typical MEMS microphone system, membrane ID 2.0 mm. Design of assembled device will affect performance.

5.   Nominal aggregate thickness of all layers. Actual thickness may vary due to the compressibility of materials.

6.  To the best of our knowledge, the parts listed above do not have any restricted substances above the maximum concentration values listed in RoHS

Directive 2011/65/EU. This information is based on our current level of knowledge and does not constitute a representation or warranty beyond those

contained in our standard terms and conditions.

P/N

ID [mm]

OD [mm]

AVP2341.53.5

1.5

3.5

AVP2342.04.0

2.0

4.0

AVP2342.55.0

2.5

5.0

AVP2343.06.0

3.0

6.0

P/N

ID [mm]

OD [mm]

AVP4341.53.5

1.5

3.5

AVP4342.04.0

2.0

4.0

AVP4342.55.0

2.5

5.0

AVP4343.06.0

3.0

6.0

Splash & Dust Protection:

Series 234

Superior Fluids & Dust Protection:

Series 434

OD

ID

b

X1

A

b

Y

X2

X1

Z

Series 234

Series 434

OD/ID = Outer/Inner diameter



= Active area

 =

Adhesive ring

A

= Non-woven material

X1

= Adhesive 1

X2

= Adhesive 2

Y

= ePTFE membrane

Z

= Support ring

b

= Reference thickness

See Product Characteristics table

Tolerance of dimensions: ± 0.20 mm

Design and Dimensions

OD

ID

b

X1

A

b

Y

X2

X1

Z

OD

ID

b

X1

A

b

Y

X2

X1

Z

Packaging:

 Supplied on sheets

Packaging:

 Supplied on sheets

P

TV

-1

36

-D

SH

-E

N

-M

A

R

21

About Gore

W. L. Gore & Associates is a global materials science company dedicated
to transforming industries and improving lives. Since 1958, Gore has solved
complex technical challenges in demanding environments — from outer
space to the world’s highest peaks to the inner workings of the human body.
With more than 10,500 Associates and a strong, team-oriented culture,
Gore generates annual revenues of $3.7 billion.

Gore develops products and technologies that address complex product
and process challenges in a variety of markets and industries, including
aerospace, automotive, pharmaceutical, mobile electronics and more.
Through close collaboration with industry leaders across the globe, Gore
enables customers to design their products and processes to be safer,
cleaner, more productive, reliable, durable and efficient across a wide range
of demanding environments.

Learn more at gore.com/protectivevents

A materials science company
dedicated to transforming industries
and improving lives

The GORE Membrane:
