Wire & Cable
A L L P R O D U C T S R E F E R E N C E G U I D E
N O R T H A M E R I C A
Specialty
Communications
4 Tesseneer Drive
Highland Heights, Kentucky 41076
Telephone: 800.243.8020
859.572.8000
Email: info@generalcable.com
www.generalcable.com
156 Parkshore Drive
Brampton, Ontario L6T 5M1
Telephone: 800.561.0649
905.494.5300
Fax:
800.565.2529
Email: infoca@generalcable.com
GENERAL CABLE, 17 FREE, CAROL BRAND, CAROLGRENE, CAROLPRENE, CCTC, CCW, CDC, CHTC, COMBAT SERIES, COMMODORE,
CVTC, DEMAND BETTER…EXPECT MORE, DURALOX, DURASHEATH, EHTC, EMPOWR, ESP, EXZEL, FEEDERPLEX HS, FREP,
FROGHIDE, GENFREE, GENSPEED, GEPCO, HYDROBLOC, MAGSTAR, MV-RIG, NEXTGEN BRAND, NSW, NUAL, NVN, PDIC, PLUG-IT,
POWRNET, POWRPAK, POWRSERV, POLYRAD, PRESTOLITE WIRE, PROSPARK, PVIC, QUICK-PREP, SILEC BRAND, STABILOY,
SUNGEN, SUPER VU-TRON, T-2, TRANSPOWR, ULTRAFLEX, ULTROL, UNIBLEND, UNISHIELD, VERTITECK, VNTC, WIDESTRIPE HS,
WINDGEN, and X-TRACT are trademarks of General Cable Technologies Corporation.
BLOLITE is a registered trademark of Brand-Rex Limited and is used under license.
©2015. General Cable Technologies Corporation. Highland Heights, KY 41076
All rights reserved. Printed in USA
Form No. COR-0061-R0715
49158
Automotive
ProSpark
®
and MagStar
®
Coil-on-Plugs & Ignition Wire Sets; Prestolite Wire
®
Brand Primary Wire &
Battery Cable; Wire Harnesses Including: Powertrain/Engine and In-Transmission Harnesses, Fuel
Systems-Related Harnesses, High-Voltage Cable Assembly Design & Development, Interior Systems
Harnesses & Specialty Interface Connectors; Battery Cable Assemblies Including: Highly Flexible Cable
Assemblies in Copper & Aluminum, High-Voltage Power Supplies & EV/Plug-in Hybrid Charging Cables;
Automotive Approvals Including: SAE J1127; SAE J1128; ISO6722 Class A, B, C and D
Military
M24643 Communications Cable; M85045F; M85045F & M49291C; Blolite
®
Blown Optical Fiber System;
Combat
®
Series Military Tactical Fiber Cables; Copper and Fiber Assemblies
Anaconda
®
Brand Mining
Mining-Grade Cables – Types W*, G, G-GC*, G-CGC, SHD, SHD-GC, SHD-CGC, SHD-BGC, VFD-BGC,
MP-GC (*Flat and Round Construction)
Oil and Gas (Offshore & Onshore)
IEEE 1580 Type P MOR Polyrad
®
XT & XT VFD Unarmored and Armored & Sheathed; IEEE 1580
Type LSX & LSX-FS; IEEE 1580 Type E MV-RIG
®
Unarmored and Armored & Sheathed; CCW
®
UL Type
ITC-HL/PLTC, MC, MC-HL, CSA Type HL; X-Tract
®
Electrical Submersible Pump Cables; Commodore
®
Data Communications Category Cables, Coaxial Cables, Industrial Automation Cables, and Fiber Optic
Communication Cables; Application-Specific Cable Assemblies
Rail & Transit
600 V & 2000 V Polyrad
®
XT Single and Multi-Conductor; 600 V & 2000 V Polyrad
®
XT-TX NYCT Type TX
Single Conductor; 600 V Polyrad
®
ULTRA Single and Multi-Conductor; Polyrad
®
and GenFire
®
Rail LSHF
EN Cables - 50264, 50306, 50382; 600 V TRANSPOWER Head-End Power (HEP) Cables; Diesel
Locomotive Cable - 2000 V; Electronically Controlled Pneumatic (ECP) Brake Cable – Unarmored &
Armored; Copper and Fiber Optic Communications Cable; Copper & Fiber Assemblies
Nuclear
ULTROL
®
60+ Nuclear Class 1E safety-related, Non-Class 1E safety significant and non-safety related
medium- and low-voltage cables qualified for 60-year service life
Wire Harnesses & Assemblies
Simple or Complex; Copper and Fiber; Overmold; Industrial; Communications; Medical; Transit
Carol
®
Brand Electronic Cables
Hook-Up Wire; Multi-Conductor and Multi-Paired Shielded and Unshielded Communication & Control
Cable; Multi-Conductor and Multi-Paired Computer Cable; Coaxial and Twinaxial Cable; Microphone
Cable; Fire Alarm Cable; Sound & Security Cable; Plenum Cable; Special Application and Composite
Cable; CSA Approved Cable; EXZEL
®
High-Endurance PVC and LSZH Multi-Conductor and Multi-Paired
Communications Cables; 17 FREE
®
line of RG 59/U Standard and Siamese Coaxial Cable with no halogens
GenSPEED
®
Brand Copper Premise Products
Category 6A 10 Gig Unshielded and Shielded, Category 6, Category 5e and Category 3 in CMP, CMR or
CMR/CMX (Outdoor) Ratings; Industrial Ethernet Cable; Armored Single and Multiple Category Cables;
17 FREE
®
line of Cat 6A, Cat 6 and Cat 5e Riser Cables with no halogens
Gepco
®
Brand Broadcast & A/V Cables
Analog & Digital Audio Cables; Video Cables; Camera & Fiber Optic Solutions; Network, Automation
& Lighting Control Cables; Touring & Stage Lighting Cables; Specialty Cables like HydroBloc
™
Water-Resistant Cables and ABS/Shipboard; Custom Copper and Fiber Cable Assemblies;
Custom Panels; Commercial A/V Solutions
NextGen
®
Fiber Optic Products
Loose Tube Outside Plant Cables; Tight Buffer Premise Cables; Indoor/Outdoor Cables; Interconnect
Cables; Specialty and Combat
®
Series Military Tactical Cables; Blolite
®
and NextGen
®
Blown Optical
Fiber Systems; 17 FREE
®
line of Tight Buffer Distribution Type CMR Cables with no halogens
Specialty Products
Residential Composite Cable and Bundled Category Cables, Indoor/Outdoor Station Wire, Cross-Connect
and Distribution Frame; Commodore
™
Copper and Fiber Communications Cable for Offshore and Marine
Shipboard; NSW
®
Brand Telecom Mini-Sub Cables
Telecommunication Cables
Air Core Copper Cable; Filled Core Copper Cable; Buried & Aerial Wire Products; Central Office Wire
COVER
