15MG
15MGLF

*



Wirewound, Non-Magnetic, Molded

STANDARD RF INDUCTORS - THRU HOLE

RoHS

COMPLIANT

www.gowanda.com

TRADITIONAL

Pb

*Add “LF” suffix for RoHS requirement. Example: 15MG560KLF

Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.

TEST FREQ

SRF

DCR

CURRENT

   PART

L

Q

L&Q

MHz

OHMS

RATING

NUMBER

 µH

MIN

MHz

MIN

MAX

mA DC

15MG100K

0.10

50

25

550

0.025

2698

15MG120K

0.12

50

25

530

0.028

2549

15MG150K

0.15

50

25

520

0.030

2450

15MG180K

0.18

50

25

475

0.040

2133

15MG220K

0.22

50

25

450

0.055

1900

15MG270K

0.27

45

25

       375

0.070

1612

15MG330K

0.33

45

25

360

0.090

1400

15MG390K

0.39

45

25

325

0.100

1349

15MG470K

0.47

45

25

310

0.120

1225

15MG560K

0.56

50

25

280

0.135

1220

15MG680K

0.68

50

25

250

0.150

1100

15MG820K

0.82

50

25

220

0.220

900

15MG101K

1.00

50

25

200

0.290

830

15MG121K

1.20

33

7.9

180

0.420

650

15MG151K

1.50

33

7.9

160

0.500

600

15MG181K

1.80

33

7.9

150

0.650

525

15MG221K

2.20

33

7.9

135

0.950

435

15MG271K

2.70

33

7.9

120

1.200

385

15MG331K

3.30

33

7.9

110

2.000

300

15MG391K

3.90

33

7.9

100

2.300

280

15MG471K

4.70

33

7.9

90

2.600

260

1.438 ± 0.188

(36.525 ± 4.77)

22 AWG

0.375 ± 0.010

(9.525 ± 0.25)

0.156 ± 0.008

(3.962 ± 0.20)

1.0

µ

H ±10%

MG

in. (mm)

60/40 coated, copper leads

0

90

21

5

NON-MAGNETIC COIL FORM

Suffix “K” for 10% tolerance

Optional tolerance levels available; please contact factory

Custom designs are available to meet your specific requirements; please contact factory

NOTES:

• Operating Temperature Range:

-55°C to +125°C

• Current Rating is based on 35ºC temperature

rise at an ambient temperature of 90ºC

• Relative Permeabilitry: ≤0.00003 µr
• Medical Grade
• Used in imaging equipment where non

 magnetic inductors are required

• Epoxy encapsulated for environmental

 protection and superior strength to withstand all

 types of reflow soldering

• Laser marking is standard

TAPE AND REEL SPECS:



Pcs./Reel maximum:

2500



Pitch between parts:

0.200 in.

Inside tape spacing:

2.062 in.

Reel diameter

12 in.

Class:

1

1.438 ± 0.188

(36.525 ± 4.77)

22 AWG

0.375 ± 0.010

(9.525 ± 0.25)

0.156 ± 0.008

(3.962 ± 0.20)

1.0

µ

H ±10%

MG
