STANDARD RF INDUCTORS - SURFACE MOUNT
CF4H1008
Ferrite Wirewound, High Performance
RoHS
COMPLIANT
L
Q
SRF
DCR
CURRENT
PART
L
TEST Q TEST MHz
OHMS
RATING
NUMBER
µH
FREQ MHz
MIN
FREQ MHz
MIN
MAX
mA DC MAX
CF4H1008-120*
0.12
25
45
75
900
0.15
1420
CF4H1008-150*
0.15
25
45
75
800
0.18
1300
CF4H1008-180*
0.18
25
45
75
750
0.20
1230
CF4H1008-220*
0.22
25
45
75
700
0.22
1120
CF4H1008-270*
0.27
25
45
75
600
0.24
1080
CF4H1008-330*
0.33
25
45
75
520
0.25
1050
CF4H1008-390* 0.39 25
40
75
450 0.25 1050
CF4H1008-470*
0.47
25
40
75
400
0.26
1030
CF4H1008-560*
0.56
25
40
75
375
0.27
970
CF4H1008-680*
0.68
25
40
75
330
0.30
920
CF4H1008-820*
0.82
25
40
75
300
0.32
890
CF4H1008-101*
1.0
7.9
35
50
280
0.35
850
CF4H1008-121*
1.2
7.9
35
50
260
0.38
815
CF4H1008-151*
1.5
7.9
35
50
240
0.41
785
CF4H1008-181*
1.8
7.9
35
50
220
0.46
740
CF4H1008-221*
2.2
7.9
35
50
205
0.75
580
CF4H1008-271*
2.7
7.9
35
50
185
0.95
515
CF4H1008-331*
3.3
7.9
35
50
170
1.35
430
CF4H1008-391*
3.9
7.9
35
50
155
1.50
410
CF4H1008-471*
4.7
7.9
35
25
140
1.60
400
CF4H1008-561*
5.6
7.9
35
25
128
1.70
390
CF4H1008-681*
6.8
7.9
30
25
110
2.00
355
CF4H1008-821*
8.2
7.9
30
25
95
2.20
340
FERRITE CORE
*Substitute “K” for 10% tolerance, “J” for 5% tolerance, “G” for 2% tolerance
Optional tolerances of 3% or 1% may be available; please contact factory.
Custom designs are available to meet your specific requirements; please contact factory.
These RoHS components meet the ≤ 0.1% lead requirement and they are compatible with 260° soldering processes.
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• Terminations are Gold over Nickel
• Inductance and Q are measured using the
HP4342 or HP4291
• SRF is measured using the HP4291, HP8753 or
equivalent
• Suitable for reflow soldering
• Flat top cover for pick and place
• Excellent for high frequency applications
• Refer to CC4H1008 (ceramic core) series for
additional inductance values
• No internal solder connection increases
reliability
• Very tight distribution within lots
• Extremely high SRF; Exceptional Q
• High current handling capability
• Low DC resistance
• Applications include: electronic test equipment,
medical equipment, telecommunications,
disk drives, computers and modems, aviation
equipment, navigation equipment and cable TV
TAPE AND REEL SPECS:
Pcs./Reel maximum
2000
Pitch between parts:
4 mm
Tape width:
8 mm
Reel diameter:
7 in.
0.020 (0.50)
REF
0.110 (2.79)
MAX
0.020 (0.50)
REF
0.080 (2.03)
REF
0.006 (0.15)
REF
0.075 (1.91)
REF
0.120 (3.05)
MAX
0.090 (2.28)
MAX
0.020 (0.50)
REF
0.110 (2.79)
MAX
0.020 (0.50)
REF
0.080 (2.03)
REF
0.006 (0.15)
REF
0.075 (1.91)
REF
0.120 (3.05)
MAX
0.090 (2.28)
MAX
0.090 (2.28)
MAX
0.110 (2.8)
MAX
0.115 (2.92)
MAX
0.008 (0.20)
REF
RECOMMENDED FOOT PRINT
0.040
(1.016)
0.100
(2.54)
0.090
(2.28)
0.020 (0.50)
REF
0.110 (2.79)
MAX
0.020 (0.50)
REF
0.080 (2.03)
REF
0.006 (0.15)
REF
0.075 (1.91)
REF
0.120 (3.05)
MAX
0.090 (2.28)
MAX
www.gowanda.com
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 1-716-532-2234 • (f) 1-716-532-2702 • sales@gowanda.com
A n A f f i l i a t e o f G o w a n d a C o m p o n e n t s G ro u p • w w w. G o w a n d a C o m p o n e n t s G ro u p. c o m
042418
in. (mm)
continued next page
