RoHS
COMPLIANT
TRADITIONAL
Pb
MLRF0805
Ceramic Wirewound, Open Construction, MIL-PRF-83446
M83446/37 Ceramic Core
Outgassing Tested per ASTM E-595 (*)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
QPL RF INDUCTORS - SURFACE MOUNT
111114
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• DWV 200 Vrms @ Sea Level
80 Vrms @ 70,000 Feet
• Weight maximum 0.008 grams (0.000881 ounces)
* Meets a TML (Total Mass Loss) requirement of
1.0% maximum when tested in accordance with
ASTM E-595; this calculation does not include
WVR (Water Vapor Recovered)
Gold termination is code “A” finish of MIL-PRF-83446
Tin-Lead solder termination is code “B” or “F”
finish of MIL-PRF-83446
Example of ordering by Military number for
MLRF0805-047K: M83446/37-14AK
MLRF0805-047KS: M83446/37-14FK
TAPE AND REEL SPECS:
Pcs./Reel maximum:
2500
Pitch between parts:
4 mm
Tape width:
8 mm
Reel diameter:
7 in.
in. (mm)
MIL
L
Q
SRF
DCR
CURRENT
PART
DASH
L
TEST
Q
TEST
MHz
OHMS
RATING
NUMBER (
1
)
NUMBER
nH
FREQ
MIN
FREQ
MIN
MAX
mA DC MAX
MLRF0805-0022K
01^K
2.2
250
55
1800
6000
0.080
1000
MLRF0805-0027K
02^K
2.7
250
55
1800
6000
0.080
1000
MLRF0805-0033K
03^K
3.3
250
50
1500
6000
0.080
1000
MLRF0805-0047K
04^K
4.7
250
60
1500
5000
0.080
1000
MLRF0805-0056*¹
05^*¹
5.6
250
60
1500
5000
0.090
1000
MLRF0805-0068*¹
06^*¹
6.8
250
60
1500
4600
0.110
1000
MLRF0805-0082*¹
07^*¹
8.2
250
55
1500
4600
0.120
970
MLRF0805-010*¹
08^*¹
10
250
60
1500
4500
0.130
930
MLRF0805-012*²
09^*²
12
250
65
500
4000
0.150
870
MLRF0805-015*²
10^*²
15
250
50
500
2800
0.170
810
MLRF0805-018*²
11^*²
18
250
50
500
2600
0.200
750
MLRF0805-022*²
12^*²
22
250
55
500
2300
0.220
720
MLRF0805-027*²
13^*²
27
250
55
500
2300
0.250
670
MLRF0805-033*²
14^*²
33
250
60
500
2000
0.270
650
MLRF0805-039*²
15^*²
39
250
60
500
2000
0.290
625
MLRF0805-047*²
16^*²
47
250
60
500
1900
0.310
600
MLRF0805-056*²
17^*²
56
250
50
500
1600
0.340
570
MLRF0805-068*²
18^*²
68
250
50
500
1500
0.380
540
MLRF0805-082*²
19^*²
82
150
55
500
1330
0.420
520
MLRF0805-100*²
20^*²
100
150
55
500
1250
0.460
490
MLRF0805-120*²
21^*²
120
150
45
250
1100
0.510
470
MLRF0805-150*²
22^*²
150
100
45
250
920
0.700
400
MLRF0805-180*²
23^*²
180
100
45
250
920
0.800
370
MLRF0805-220*²
24^*²
220
100
45
250
820
1.2
300
MLRF0805-270*²
25^*²
270
100
40
200
730
1.2
300
MLRF0805-330*²
26^*²
330
100
40
200
750
1.8
250
MLRF0805-390*²
27^*²
390
100
40
200
700
2.0
230
MLRF0805-470*²
28^*²
470
100
40
200
600
3.0
210
MLRF0805-560*²
29^*²
560
100
40
200
500
3.5
180
MLRF0805-680*²
30^*²
680
50
40
200
450
4.0
170
MLRF0805-820*²
31^*²
820
25
15
25
250
2.5
210
MLRF0805-101*²
32^*²
1000
25
15
25
250
3.0
195
MLRF0805-181*²
33^*²
1800
7.9
15
7.9
50
4.5
150
MLRF0805-221*²
34^*²
2200
7.9
15
7.9
40
5.0
140
*
¹ Suffix “J” for 5% tolerance or “K” for 10% tolerance
*
² Suffix “G” for 2% tolerance, “J” for 5% tolerance, or “K” for 10% tolerance
(1) Add suffix letter “S” to order with tin/lead solder termination, otherwise gold termination will be provided
˄ For MIL-PRF termination finish codes refer to NOTES below
MIL-PRF-83446/37 CERAMIC CORE
0.095
(2.41)
MAX
0.070
(1.78)
MAX
H:
0.060 (1.52) MAX - Code A
0.066 (1.68) MAX - Code B & F
0.050
(1.27)
REF
RECOMMENDED FOOT PRINT
0.040
(1.016)
0.070
(1.78)
0.008
(0.20)
REF
0.070
(1.78)
0.017
(0.43)
REF
0.095
(2.41)
MAX
0.070
(1.78)
MAX
H:
0.060 (1.52) MAX - Code A
0.066 (1.68) MAX - Code B & F
0.050
(1.27)
REF
RECOMMENDED FOOT PRINT
0.040
(1.016)
0.070
(1.78)
0.008
(0.20)
REF
0.070
(1.78)
0.017
(0.43)
REF
0.095
(2.41)
MAX
0.070
(1.78)
MAX
H:
0.060 (1.52) MAX - Code A
0.066 (1.68) MAX - Code B & F
0.050
(1.27)
REF
RECOMMENDED FOOT PRINT
0.040
(1.016)
0.070
(1.78)
0.008
(0.20)
REF
0.070
(1.78)
0.017
(0.43)
REF
