LOG
655
/ R
ev 11-2016
Check
LEDTRONICS.C
OM
for la
test da
ta.
Prin
ted ma
terial ma
y be out
da
ted
.
HBL005-100W-
XHW
-101WD
(Halogen White)
HBL005-100W-
XIW
-101WD
(Warm White)
HBL005-100W-
XNW
-101WD
(Natural White)
HBL005-100W-
XPW
-101WD
(Pure White)
XHW
XIW
XNW
XPW
Input Power
100 Watts
100 Watts
100 Watts
100 Watts
Input Voltage
100-277VAC
(Tested @ 120VAC)
Total Lumens
13000 lm
13000 lm
13000 lm
13000 lm
Efficacy
130 lm/W
130 lm/W
130 lm/W
130 lm/W
Power Factor
0.9
0.9
0.9
0.9
Color Temperature
2700K
3000K
4000K
5000K
Emitted Color
Halogen White
Warm White
Natural White
Pure White
CRI
81
81
81
81
Illumination Angle
120°
120°
120°
120°
Oper. Temperature
-22°F ~+122°F / -30°C ~+50°C
Oper. Humidity
15%~90% RH
Protection Rating
IP65
(Water-Resistant to Low-Pressure Spray)
Dimmability
Continuous
(Can Dim down to ≤10% W)
Housing
Die-Cast Aluminum 1070 Alloy / Black
Lens
Clear Tempered Glass
Net Weight
6.63 lbs / 3.0 Kg
DLC Listing
P4DAZB68
P5Z6HBT9
PWDBPEY9
PT341V5E
• 5 Year LEDtronics Warranty
• High Lumen, High CRI, Low Glare / Dimmable
• Energy Savings of 70% over Counterpart HIDs
• Lumen Maintenance over 70% @ 50,000+ Hours
• Die-cast Aluminum Heatsink, SMD LED Chips
• Weather & Acid/Alkaline Resistant Tempered Glass Lens
• Meanwell HBG Constant-Current Power Driver
• IP65: Suitable for High Humidity Sites
• No UV / No IR, Impact Resistant, Extra Lightweight
• DLC & UL/cUL Listed(E481931, P/N HD-HBxx0WD)
• No Toxic Metals – RoHS Compliant
Ideal for High Bay Lighting Applications:
• Subway & Rail Platforms, Toll Booths
• Industrial Plants, Workshop Areas
• Warehouses, Depots, Conference Halls
• Indoor Tennis & Basketball Courts
• Other Color Temperatures: 3000K & 4000K
• Other Wattages & Voltages
FEATURES
APPLICATIONS
AVAILABLE OPTIONS
COMPLIANT
100 Watts
E 4 8 1 9 3 1
120° BEAM ANGLE
LED High Lumen, Low Profile High Bay Lights
100, 150 or 200 Watts – Dimmable – 120° Beam – 100~277VAC – 2700K to 5000K – UL & DLC
© 2016 LEDtronics, Inc.
23105 Kashiwa Court, Torrance, CA 90505
Phone:
(800) 579.4875 / (310) 534.1505
Fax:
(310) 534.1424
E-mail:
info@ledtronics.com
Website:
ledtronics.com
To order LEDtronics products,
contact IBS Electronics!
Visit IBS Electronics website for distribution offices worldwide!
9001:2008
ISO
CERTIFIED by DNV
Over 30 Years of LEDtronics Design,
Engineering & Manufacturing Experience
Ø9.92 typ
[Ø252mm]
Ø1.02 typ
[Ø26mm]
7.12” [180mm] typ
1.7” [42mm] typ
TOP VIEW
BOTTOM VIEW
SIDE VIEW
100 Watts, Replaces
HID up to 400W
(Some May Not Qualify for DLC)
