hether you are building
miniature inductors

for space-constrained printed
circuit board applications,
transformers for arc welding
equipment, or high-efficiency
motors for precise motion
control, look to Alpha Wire

for windings
that work
better. From
the fine twists
of hearing aids

to large windings in medical
equipment, you need a proven
source with the expertise to
work with fine wire, the ability
to customize products into
application-specific solutions,
and support to give you
the best technology at the
lowest cost.

Alpha Wire’s Kerrigan-Lewis
brand of specialty wire is
designed and manufactured
to stringent standards of
quality and performance.
From expertise in fine copper
wire and insulations to an
exact understanding of your
most rigorous application
requirements, we can help you
increase efficiency, reduce size,
and achieve higher levels of
productivity.

Beyond our competitive lead
times and attractive pricing, we
also offer the lowest minimum
order levels in the industry.
Save money by ordering only
what you need.

Litz wire

Litz wire reduces AC losses
in conductors from skin
and proximity effects at
high frequencies to make
transformers and motors
more efficient. It consists of
individually insulated strands

woven or twisted in a specific
pattern so that each tends to
occupy all possible positions
in the cross section. This

equalizes
flux linkages
and
reactances
so that

current is evenly divided
among the strands. The
increased current-carrying
efficiency makes litz wire
popular in such applications as:

•

High-frequency inductors

and transformers

•

Motors

•

Relays

•

Inverters

•

Power supplies

•

Ultrasonic and sonar

equipment

•

Heat-induction equipment

•

High-twist applications,

up to 300 turns per foot

Kerrigan-Lewis litz wire is
available in a wide range of
configurations to meet specific
operating frequencies, voltages,
and current-carrying capacities.
Individual strands range from
50 to 16 AWG, with anywhere
from a few strands to thousands
in the wire. Besides traditional
round conductors, we also
offer space-saving square and

Specialty wire for

unique applications

Resistance wire

Kerrigan-Lewis resistance
wire achieves high-tolerance
resistive values with a
copper-nickel alloy. Standard
configurations are 55%
copper/45% nickel for a
resistance of 294 ohms per
circular mil-foot and 78%
copper/22% nickel for a
resistance of 180 ohms, with

others available. We offer the
wire in sizes from 40 AWG
to 25 AWG to meet specific
resistance and current-
carrying needs.

Get help from

the experts

Tap the experts at Alpha Wire
in selecting the right wire.
We understand the advantages

Variations

Features

Insulations/servings

NEMA-approved films

To 105°C, 155°C, 200°C

Single and heavy coatings

Cotton

To 105°C

Abrasion resistant

Nylon

To 130°C

Abrasion resistant

Good high-frequency properties

Celanese synthetic yarn

To 105°C

Excellent high-frequency properties

Chemically soluble

Nylon/Celanese mix

To 105°C

Excellent high-frequency properties

Chemically soluble

Teflon textile

To 200°C

Abrasion resistant

Excellent high-frequency properties

Excellent handling properties

Teflon extrusion

To 200°C

Waterproof

Abrasion resistant

Excellent high-frequency properties

Excellent handling properties

PVC

To 105°C

Strand range

50 to 16 AWG

Flexibility in meeting

application goals

Configurations

Round

Square

Rectangular

Configurable for maximum operating

and space efficiencies

rectangular cross sections
for maximum copper density.
Some popular configurations
include 60 strands of 36 AWG,
100 strands of 38 AWG, and
2100 strands of 36 AWG.

While polyurethane is the
most common insulation film,
we offer all NEMA-approved
films and a range of additional
insulations that include Teflon,®
nylon, cotton, Celanese
synthetic yarn, and a nylon/
Celanese mix.

and disadvantages of various
stranding options and
insulations, as well as their
effect on the mechanical and

electrical properties
when applied. We’ll
help you find a
standard product or
customize a wire for
your application.

bles you trust. Service you deserve.

GLOBAL HEADQUARTERS
711 Lidgerwood Avenue
Elizabeth, NJ 07207-0711 USA
Toll Free: 1-800-52 ALPHA
Tel: 1-908-925-8000
Fax: 1-908-925-5411
E-mail: info@alphawire.com

EUROPE
Alpha Wire International
Sunbury Int’l Business Centre

Brooklands Close

Windmill Road

Sunbury-on-Thames

Middlesex

United Kingdom

TW16 7DX

Tel: +44 (0) 800 288 8809
Fax: +44 (0) 800 288 8810
E-mail: europe@alphawire.com

Specifications subject to change. Consult Alpha Wire for latest specifications.

Lit. No. KL-Bro-0901

Teflon is a registered trademark of E. I. du Pont de Nemours and Company.

Supersedes: New

The cables you trust.

The service you deserve.

Every application is critical
and wire failure is not an
option when the performance
of your equipment and
reliability are paramount.
Specify Kerrigan-Lewis for
harsh environments and crucial
applications, since the integrity
of your system is only as robust
as the products you use.

Made to order

Because litz wire is highly
specialized to each application,
we custom build every order.
That way, you get the exact
wire you need. And, with Alpha
Wire, custom built also means
fast turnaround times, so you
get the best of both worlds.

Service and support,

second-to-none

Selecting the correct wire
or cable for your critical
application is essential to
overall system reliability,
performance, and safety. So we
make it easy for you to select
the right product for your
specific application. Our online
resources include a wire and
cable selection guide, technical
information, product catalogs,
and a distributor locator to
make it easy to select and
get the wire you need. Can’t
find what you’re looking for?
Design the cable to your
specification. It’s easy, just
visit

www.alphawire.com
