MP SERIES
High Performance Molded Heat-Sink Resistors
RCD’s MP series feature power film resistor elements designed
for excellent environmental stability as well as superior high-
frequency performance (custom designs up to 1GHz avail.). All
sizes feature metal base plate for optimum heat transfer. The
resistor is electrically isolated from the metal tab, and molded into
various package styles with high-temp flame-retardant epoxy.
MP126 and MP220 in reduced wattage ratings now available
in tighter TCs and tolerances from 10
Ω
to 49.9K: MP126 (5W)
to 0.025% and 2ppm, MP220 (10W) to 0.05% and 5ppm.
TYPICAL PERFORMANCE CHARACTERISTICS
POWER FILM RESISTORS TO 140 WATT
1
Power rating without heat sink is based on unit being mounted on double-sided 2oz 1” x 1” x .063”
PCB.
2
R
θ
JC
Film (J) to Case (C)
3
Voltage determined by E=
(PR)
1/2
, not to exceed the Max.Voltage
Rating
4
Extended range available, consult factory.
Standard Temperature Coefficient
(Typ, +25°C to +125°C)
50ppm
≥
10
Ω
(2ppm avail)
100ppm 0.1 - 9.9
Ω
250ppm 0.01 - 0.99
Ω
Operating Temperature Range
-55 to +155°C
Std. Resistance Tol. (0.025%-5% avail)
±1%
≥
.05
Ω
, ±5% <.05
Ω
Dielectric Strength
1500VAC (up to 2.5KV avail)
Current Rating
30A max.
Insulation Resistance
10,000 M
Ω
min.
Load Life Stability
±1%
Overload
1.5x W, 5S, nte 1.5x Max V
Thermal Shock (Mil-Std-202 M107C)
±0.25%
Soldering Stability
±0.1%
Moisture Res (Mil-STD-202, M106)
±0.5%
RCD
Type
Max. Power
with Heat Sink
(25°C)
Max Power
1
w/o Heat Sink
(25°C)
Thermal
Resis.
2
Max.
Voltage
3,4
Resistance
Range (
Ω
)
4
MP126
20W
1.25W
<6°C/W
300V
.01 - 56K
MP126G
20W
1.25W
<6°C/W
300V
.01 - 56K
MP220
35W
2.0W
3.3°C/W
350V
.01 - 56K
MP220G
25W
2.0W
3.3°C/W
350V
.01 - 56K
MPD220
35W
2.0W
3.3°C/W
350V
.01 - 56K
MP220B
50W
2.25W
2.3°C/W
350V
.1 - 56K
MP220GB
45W
2.25W
2.3°C/W
350V
.1 - 56K
MP247
100W
3.0W
1.3°C/W
500V
.01 - 56K
MP247B
140W
3.5W
<1°C/W
500V
.1 - 56K
Industry’s widest range of TO-style power resistors!
Standard resistance range: 0.01
Ω
to 56K
Ω
Standard tolerance: ±1%, ±2%, ±5% (available to 0.025%)
Non-Inductive performance
Resistor is electrically isolated from the mounting surface
OPTIONS
Option P: Increased pulse capability
Option G: Gull-wing lead formation for surface mounting
Option B: Increased power design
Numerous design modifications are available (special
marking, custom lead wires, burn-in, etc).
POWER RATING
Power rating is based on the resistor being tightly screwed to a suitable heat
sink (with thermal compound) to limit hot spot case temperature to 155°C.
Derate W, V, A by .77%/°C above 25°C (as depicted in chart below). Mount-
ing torque not to exceed 8 in-lbs. Refer to Applic.Guide R-34 for additional
detail concerning heat-sink resistor mounting guidelines.
CASE TEMPERATURE ( °C )
% OF RA
TED W/V/A
25 50 75 100 125 150 175
100
75
50
25
0
RCD
MP220
1K 1%
RCD
MP220G
1K 1%
RCD
MPD220
1K 1%
RCD
MP126
1K 1%
RCD
MP247
10R0 1%
FA069C Sale of this product is in accordance with GF-061. Specifications subject to change without notice.
SPECIFICATIONS
78
RESISTORS
CAPACITORS
COILS
DELAY
LINES
P/N DESIGNATION:
MP220 - 1001 - F B W
Optional Temp. Coefficient
: 25=25ppm, 50=50ppm,
25=25ppm, 10=10ppm, 5=5ppm, 2=2ppm (leave blank for std)
P
ackaging
: B = Bulk, T = Taped (bulk is standard)
Tolerance Code
: J=5%, G=2%, F=1%, D=0.5%,
C=0.25%, B=0.1%, A=0.05%, X=0.025%
Resis.Code 0.025%-1%
: 3 digits &multiplier (R010=.01
Ω
,
R100=.1
Ω
, 1R00=1
Ω
, 10R0=10
Ω,
1000=100
Ω,
1001=1K, etc
)
Resis.Code 2%-10%
: 2 digits & multiplier (R01=.01
Ω,
R10=0.1
Ω,
1R0=1
Ω
, 100=10
Ω,
101=100
Ω,
102=1K, etc.)
Options:
P, G, B, etc (leave blank for std)
Termination:
W= Pb-free (std), Q= Sn/Pb (leave blank if both acceptable)
RCD Type
Term.W
is RoHS
compliant
& 260°C
compatible
RoHS
→ ←
→
MP220, MP220B
MP220G,
MP220GB
.142
[3.6]
.16 [4]
↓
↑
.030 [.76]
.40
[10.2]
→
.117[3]
.500
[12.7]
MP126G
.060 [1.5]
←
.140 [3.5]
←
→
→
.06
[1.5]
.590
[15]
→
→ ←
.177[4.5]
.10[2.5]
→ ←
.020[.5]
→ ←
←
.080 [2]
→ ←
.200 [5]
→
←
MP126
←
←
.12
[3.1]
←
.
472
[12]
.400
[10]
.10
[2.5]
→ ←
.020[.5]
→ ←
.335 [8.5]
.200
[5.08]
→ ←
←
→
.15 [3.8]
.122
[3.1]
.125
[3.2]
↓
↑
.024
[
.6]
→
.200
[5.08]
.177[4.5]
MP247, MP247B
.55
[14]
.63
[16]
.430
[10.9]
→ ←
←
.14
[3.55]
.032
[
.8]
dia.
→
←
.
800
[20.3]
.12
[3]
→ ←
→
.19
[4.8]
.20
[5.1]
MPD220
.200
[5.08]
.20
[5]
.030
[.76
]
.40
[10.2]
→ ←
→
←
.06
[1.5]
.400
[10.2]
→
→ ←
.020
[.5]
→ ←
←
.080
[2]
RCD Components Inc
, 520 E.Industrial Park Dr, Manchester, NH, USA 03109
rcdcomponents.com
Tel: 603
-
669
-
0054 Fax: 603
-
669
-
5455 Email:
sales@rcdcomponents.com
