Microsemi_Connected_Home_Solutions

Microsemi is a leading provider of energy-efficient and cost-effective semiconductor system solutions for the broadband home,
delivering the right connectivity solutions for voice, data, and power. Microsemi’s ZL380 audio processors feature AcuEdge™
technology designed for world-class high-definition (HD) voice applications. Microsemi has been pioneering Power over Ethernet
since 1999 and is the only supplier of reverse power feed systems and ICs for customer equipment and distribution point units that
can be installed virtually anywhere, without the need to deploy local power.

Enabling the Connected Home

VoIP Gateway and Broadband Router

• Voice Line Circuits • PLC Line Drivers
• Wi-Fi

PA & LNA

• PoE

• Automatic Speech • Audio Event Detection
Recognition Assist

Set-top Box

• Voice Line Circuits
• PLC Line Drivers
• Automatic Speech
Recognition Assist

IP Phone

• Hands-free HD Voice
• Multi-channel
Audio Processing

Telephony

• Voice Line Circuits

Home Security

• PoE
• Automatic Speech
Recognition Assist
• Audio Event Detection
• Two Way Audio

Mobile and Hand-held

• Wi-Fi PA and LNA

PoE

• PSE and PD ICs
• Midspans

FTTdp RPF

• CPE and DPU RPF ICs
• RPF Injector

Smart Speaker

• Automatic Speech
Recognition Assist
• 360 degree Audio Pickup
• Two Way Audio
• Audio Event Detection

Designed for world-class high definition (HD) voice applications,
Microsemi’s new ZL380 series of audio processors features
Microsemi AcuEdge™ technology. This innovative technology
is a set of highly-complex and integrated algorithms that
enables extracttion of more information from the audio
environment. Microsemi AcuEdge consists of license-free,
royalty-free intelligent audio IP algorithms. With Microsemi’s
highly-integrated ZL380 series of audio processors, AcuEdge
accelerates time-to-market with a validated reference design
and easy-to-use development tools including the Microsemi
Audio Interface Box (AIB) kit, which uses the MiTuner™ GUI
software.

The Microsemi AcuEdge technology enables full duplex
operation between the connected devices to deliver seamless
high definition (HD) voice communication. In complex noise
environments such as gaming rooms and building lobbies,
Microsemi’s AcuEdge technology cancels echo, maintains
a constant ambient noise (comfort noise), and continuously
converges during double-talk situations.

Microsemi’s automatic speech recognition (ASR) assist
technology significantly improves performance for embedded
and cloud-based ASR solutions. This enables extended range
detection in noisy environments and provides exceptional barge-
in performance.

Audio Processors

t T

t L

igh

Set-

top B

Smart Ga

teway

IoT

nso

art

ker

Microsemi’s Timberwolf Audio Processing solution for Connected Home

Microsemi and the Microsemi logo are registered

trademarks of Microsemi Corporation. All other

trademarks and service marks are the property

of their respective owners.

Microsemi makes no warranty, representation, or guarantee regarding the information contained herein or the suitability of its products and services for any

particular purpose, nor does Microsemi assume any liability whatsoever arising out of the application or use of any product or circuit. The products sold

hereunder and any other products sold by Microsemi have been subject to limited testing and should not be used in conjunction with mission-critical equipment

or applications. Any performance specifications are believed to be reliable but are not verified, and Buyer must conduct and complete all performance and other

testing of the products, alone and together with, or installed in, any end-products. Buyer shall not rely on any data and performance specifications or parameters

provided by Microsemi. It is the Buyer’s responsibility to independently determine suitability of any products and to test and verify the same. The information

provided by Microsemi hereunder is provided “as is, where is” and with all faults, and the entire risk associated with such information is entirely with the Buyer.

Microsemi does not grant, explicitly or implicitly, to any party any patent rights, licenses, or any other IP rights, whether with regard to such information itself

or anything described by such information. Information provided in this document is proprietary to Microsemi, and Microsemi reserves the right to make any

changes to the information in this document or to any products and services at any time without notice.

Microsemi Corporation (Nasdaq: MSCC) offers a comprehensive portfolio of semiconductor and system solutions for aerospace

& defense, communications, data center and industrial markets. Products include high-performance and radiation-hardened

analog mixed-signal integrated circuits, FPGAs, SoCs and ASICs; power management products; timing and synchronization

devices and precise time solutions, setting the world’s standard for time; voice processing devices; RF solutions; discrete

components; enterprise storage and communication solutions, security technologies and scalable anti-tamper products;

Ethernet solutions; Power-over-Ethernet ICs and midspans; as well as custom design capabilities and services. Microsemi is

headquartered in Aliso Viejo, California and has approximately 4,800 employees globally. Learn more at www.microsemi.com.

Microsemi Corporate Headquarters

One Enterprise, Aliso Viejo, CA 92656 USA
Within the USA: +1 (800) 713-4113
Outside the USA: +1 (949) 380-6100
Fax: +1 (949) 215-4996
Email: sales.support@microsemi.com
www.microsemi.com

MSCC-0232-BR-01000-1.00-1117

Voice Line Circuits

The miSLIC™ series provides the most
economical solution for adding two
channels of voice to broadband
applications, such as residential gateways,
DSL integrated access devices (IAD), cable
embedded multimedia terminal adapters
(eMTAs), and fiber to the premise (FTTX) applications. The miSLIC
series supports ringing and system power management, enabling
energy efficient control of two telephone lines and meeting the
European Code of Conduct specifications. The miSLIC device
together with the patented shared buck boost automatic battery
switching (BBABS) power supply design are Microsemi’s most
economical RBOM for two channels of voice.

The VE950 series offers high-performance,
voice-over-broadband SLIC devices with
universal differential ringing and codec
interfaces optimized for short loop, power-
sensitive applications. The VE950 products
are designed to interface to residential
gateway SoCs with integrated analog codecs.

Power over Ethernet (PoE)

Microsemi has been pioneering Power over Ethernet since 1999,
with the invention of Power over LAN™. Microsemi has the broadest
Power over Ethernet product line covering PoE IC’s that send power
(PSE), receive power (PD), and complete systems that inject Power
over Ethernet in an intelligent way (Midspans). Microsemi’s products
support IEEE802.3af-2003, IEEE802.3at-2009 in both 30 W and 60 W
versions, Energy Efficient Power over Ethernet, and the 95 W Power
over HDBaseT™ (PoH) standard. Microsemi’s PoE PSE product line

includes IC’s and modules that can be used to build PoE switches and
routers (Endspans) from 1 to 96 ports in a single power management
system. Microsemi provides the most energy efficient and cost
effective solutions to build PD’s consuming up to 95 W over a single
Category 5/5E/6/6A/7 cable. PD applications achieve best-in-class
power and thermal performance using Microsemi’s fully integrated
smallest footprint dual pack Idea Diode Bridge IC’s. Microsemi’s
midspans can be used in indoor and outdoor deployments, with
advanced network management and energy efficient PoE models.

Reverse Power Feed (RPF)

Reverse power feed (RPF) technology allows service providers to
deploy xDSL DSLAMs virtually anywhere, without the need to deploy
local power. Microsemi is the only supplier of RPF systems and IC’s for
customer premises equipment (CPE) and the distribution point units
(DPU). Microsemi’s RPF solution allows low cost, safe, and reliable
power injection and extraction over xDSL including VDSL2, G.hn, and
G.fast. It is compatible with DSL bonding and vectoring, and covers
1-line DPU’s reverse power fed by 1 CPE as well as multi-line DPU’s
featuring Microsemi’s FairPower™ for equal power sharing of all RPF
CPE’s.

Wireless LAN RF ICs

Microsemi’s WLAN (Wi-Fi) RF IC’s portfolio for broadband gateways
includes front-end modules (FEMs), power amplifiers (PAs), and
linear amplifiers (LNAs) required to implement an RF front-end.
Combinations include one or more power amplifiers with both input/
output impedance matching, a switch, and one or more low noise
amplifiers. Microsemi’s WLAN RF IC’s can be found in multiple
IEEE802.11a/b/g/n/ac reference designs by the leading WLAN
baseband SoC suppliers.

Line Drivers

Microsemi has been a supplier of line drivers for xDSL technologies
since 2001. Starting with ADSL, Microsemi now supports every xDSL
standard inlcuding G.fast, ADSL2+, and VDSL2 with extremly energy
efficient and long range capable products. Microsemi’s new power
line communications line drivers support the G.hn and HomePlug AV2
standards with bandwidths of up to 110 Mhz, for Classes AB and GH.

Figure 2: Industry-Leading Power over Ethernet (PoE) Solutions
