Introducing the
NEW PAN1325A/1315A Series
Bluetooth RF Modules from
Panasonic, now providing Texas Instruments’
NEW CC2560A
controller in an
easy-to-use RF Module format with Bluetooth, FCC, IC and CE certifications.
A ROM update from Texas Instruments to the already popular CC2560 IC has
allowed Panasonic to improve its top selling PAN1325/1315 Series. The
NEW
PAN1325A/1315A Series
Modules has increased power and system efficiency
resulting from reduced initialization script size, start-up time and decreased
system memory requirements.
All of Panasonic’s Bluetooth RF Modules feature unique, tiny footprint technology
and are designed to accommodate PCBs with pad pitch of 1.3mm with as little
as two layers for easy implementation and manufacturing. With or without
an embedded antenna,
the NEW PAN1325A/1315A Series
provides easily
integrated Bluetooth connectivity into new and current designs by removing RF
design and certification barriers from the application.
As the newest addition to Panasonic’s Host Controlled Interface (HCI) Bluetooth
RF Module product line, the
PAN1325A/1315A Series
has all the features of
the existing and proven PAN1325/1315 Series but with the added benefits of the
improved efficiency.
An updated initialization script is required for modules based on the
CC2560A. Compatibility of CC2560 and CC2560A based products is a function
of Bluetoothstack firmware residing on the host processor.
Product Performance:
•
Best-in-class Bluetooth RF performance
(Tx power, Rx sensitivity, blocking)
•
Fully Qualified Bluetooth v2.1 EDR
•
Dimensions PAN1325A: 9mm x 9.5mm x 1.8mm
(width x length x height)
•
Dimensions PAN1315A: 6.5mm x 9mm x 1.7mm
(width x length x height)
•
Certifications: Bluetooth, CE, FCC
•
Operating Temperature Range: -40ºC to +85ºC
•
Supply Voltage Range: 1.7 - 4.8V
•
Profiles: SPP, HDP, A2DP
•
Based upon TI’s CC2560A
•
Integrates with TI’s ultra low-power MSP430
microprocessor
•
Very fast algorithm for both ACL and eSCO
•
Supports Extended Range Tx power with 10dBm
typical output (10dBm for PAN1315)
•
Low power scan method for page and inquiry scans
at 1/3rd normal power
PAN1325A and 1315A
Part Numbers:
Part Numbers
Description
ENW-89829A2KF
PAN1325A, CC2560A, HCI Module, Antenna
ENW-89829C2KF
PAN1315A, CC2560A, HCI Module, No Antenna
Development and Evaluation Part Numbers:
Part Numbers
Description
ENW-89825A2JF
PAN1323ETU, Development Module for PAN1315, PAN1316, PAN1317, PAN1325, PAN1326, PAN1327
EVAL_PAN1323
EVAL_PAN1323, Development Kit for PAN1315, PAN1316, PAN1317, PAN1325, PAN1326, PAN1327
New
Product
Introduction
NEW!
PAN1325A/1315A
SERIES BLUETOOTH® HIGH TEMPERATURE MODULES
Texas Instruments NEW CC2560A Bluetooth IC In An Easy-To-Use Module Format
P
i
Design and Specifications are subject to change without notice. Ask the factory for technical specifications before purchase and/or use. If there is any doubt
regarding the safety of this product, kindly inform us immediately for technical consultation.
PAN1450 Rev. A
W
IRELESS
M
ODULES
The PAN1450 provides wireless interface per the BT 1.2
specification. Interoperability and BT compliance testing have
been completed for the BT Chip ZV4301 from Zeevo, Inc. to
facilate rapid time-to-market.
The BT Chip incorporates a widely popular 32-bit ARM7TDMI
TM
CPU core with sufficient bandwidth to support a wide range of
embedded µController applications and the module provides
full ARM7 software development access.
The PAN1450 is manufactured in a 13,4 x 18,7 x 2,2 mm³
SMD package and the only external component needed is an
50 ohm antenna.
Any customizations for the software can be handled
with our recommended partners.
Overview
- Inquiry results with RSSI (1.2)
- Adaptive frequency hopping (AFH) enabled (1.2)
- High throughput (>600 kbps)
- Hold-, Park- and Sniffmode
- Up to 128 bit encryption
- Audio capability on an SCO channel
- Support for very low power modes - sleep and deep sleep
- All bluetooth data rates (up to 57,6/723,2Kbps)
User Interfaces
- Full-speed USB version 2.0 compliant
- Programmable baud rate UART (9,6 Kbps - 921,6 Kbps)
- Debug UART (DUART)
- 16 General Purpose I/O‘s (interruptible)
- PCM audio (1 channel)
- SPI and JTAG interface
Radio Features
- High sensitivity design (-86 dBm typ.)
- Integrated RF shield
- Class 2 module (0dBm typ. output power)
- One antenna port
FEATURES
OUTLINES - ENW89803J
P R O D U C T
QUAL
IFIE
D
BL
UE
TO
OTH
B01839
Bluetooth-Module PAN1450
Cut the Cable
TM
Copyright © 2013 Panasonic Corporation of North America.
All Rights Reserved. Specifications are subject to change without notice.
PAN13xx High Temp Line Extension, FY12-160-XXX
www.panasonic.com/rfmodules
