Resistors And Resistive Applications

Our metal-clad resistors are meticulously manufactured in accordance with the ISO9001 and IATF16949 systems, ensuring the highest quality standards. Furthermore,

they have received certifications such as UL, CE, IP65, and AEC-Q200, demonstrating their compliance with rigorous industry specifications. Rest assured, all our products
fully adhere to RoHS regulations, making them environmentally friendly. These versatile resistors find extensive applications in a wide range of motor control circuits.
Whether it's for braking, current limiting, charging and discharging, or other crucial functions, our resistors are engineered to excel. They are commonly employed in various
industrial robots, inverters, servo motor drives, electric vehicles, energy storage systems (ESSs), and fuel cell systems. You can rely on our resistors to deliver exceptional
performance and reliability in these demanding environments.

High Power Metal Clad Resistors

Manufacturing and export of automotive and industrial resistors, import
and sales of high-precision, high-reliability resistors and measuring

instruments.

Business Areas

MISSION

By delivering top notch services and

solutions, we facilitate joint success for
both our customers and team members,
fostering a collaborative environment of
achievement.

CORE VALUES

•

Adherence to strict industry standards.

•

Diligence.

•

Continuous development

•

Kindness and consideration.

VISION

Our aim is to become the most

competitive industrial resistor producer

worldwide.

Automotive resistors, metal clad resistors, current detection resistors

(shunts), wire wound resistors, precision resistors, thick film resistors,

heaters, etc.

Products

Aluminum Housed, Chassis Mount Resistor

Model: IRH, IRV, ULH, ULV, ARH, ARV

•

Power Rating: 60W~500W

•

Resistance(Ω): 0.1~6.8k

•

Tolerance(%): ±0.5, ±1, ±2, ±5

•

TCR(ppm/C): 260Max.

Mini Braking High Power Resistor

Model: MBH, MBV, BRH, BRV

•

Power Rating: 1.1kW~3.6kW

•

Resistance(Ω): 0.4~300

•

Tolerance(%): ±5, ±10

•

TCR(ppm/C): 260Max.

High Power Resistor Assemblies

Model: LCAH, LCAV

•

Power Rating: 1kW~4.2kW

•

Resistance(Ω): 0.6~864

•

Tolerance(%): ±5, ±10

•

TCR(ppm/C): 260Max.

Aluminum Housed, Chassis Mount Resistor

Model: RH, FRH, URH

•

Power Rating: 10W~100W

•

Resistance(Ω): 0.1~50k

•

Tolerance(%): ±1, ±2, ±5

•

TCR(ppm/C): 30, 50, 100, 200

Aluminum Housed, Chassis Mount Resistor

Model: IRV, ULV, IRM, ULM

•

Power Rating: 600W~1200W

•

Resistance(Ω): 0.1~175

•

Tolerance(%): ±1, ±2, ±5

•

TCR(ppm/C): 260Max.

Since 1989, RARA Electronics has been improving the quality, efficiency,
and availability of various resistive products. Through its extensive
network of distributors, RARA actively sells products globally, reaching
out to markets in Japan, the United States, Brazil, and Europe. We
maintain a solid relationship with more than 80 international customers
across 40 countries, providing a complete solution for industrial and
special resistors for a wide range of industrial needs

RARA Electronics L.L.C.

Resistors And Resistive Applications

We offer a comprehensive selection of AEC-Q200 automotive-grade high-power pre-charge and discharge resistors designed to meet various requirements. Our resistors
come in power ratings ranging from 20W to 500W, ensuring compatibility with a wide range of applications. Additionally, we provide different package styles and types to
accommodate diverse installation needs. Our resistors are highly customizable, allowing you to tailor them to your specific specifications. We offer options such as non-
inductive windings, HV cables, compact designs, and intrinsically safe features to cater to your unique requirements.

In response to the growing market demand for high current detection resistors in applications such as automotive and secondary battery markets, particularly within the
electric vehicle sector, we have significantly expanded our product offerings. We understand the importance of meeting diverse customer needs and have introduced a
wide range of series to cater to specific requirements. Our goal is to provide comprehensive solutions that align with the evolving demands of the current control application

market.

Pre-Charge / Discharge Resistors

(EV, HEV, PHEV)

Current Sensing Resistors

Aluminum Housed, Chassis Mount Resistor

Model: IRH, IRV, ULH, ULV

•

Power Rating: 60W~500W

•

Resistance(Ω): 0.2~3K

•

Tolerance(%): ±0.5, ±1, ±5

•

TCR(ppm/C): 260Max.

Flat Type Aluminum Housed Resistor

Model: IRN, IRF, ULN, ULF

•

Power Rating: 50W~500W

•

Resistance(Ω): 1~5.78K

•

Tolerance(%):±0.5, ±1, ±5

•

TCR(ppm/C): 260Max.

Aluminum Housed, Chassis Mount Resistor

Model: IRHC

•

Power Rating: 40W, 60W, 100W

•

Resistance(Ω): 10~1K

•

Tolerance(%): ±5, ±10

•

TCR(ppm/C): 260Max.

Aluminum Housed, Chassis Mount Resistor

Model: IRV, ULV, IRM, ULM

•

Power Rating: 600W~1200W

•

Resistance(Ω): 0.1~175

•

Tolerance(%): ±1, ±2, ±5

•

TCR(ppm/C): 260Max.

Ceramic Encased Resistor

Model: AQL

•

Power Rating: 20W~100W

•

Resistance(Ω): 10~80

•

Tolerance(%): ±1, ±5 ±10

•

TCR(ppm/C): 260Max.

Metal Alloy Low-Resistance Resistor

Model: LR, LRA, LRE

•

Power Rating : 1/16W~5W

•

Resistance(Ω) : 0.2m~300m

•

Tolerance(%) : ±0.5, ±1, ±2, ±5

•

TCR(ppm/C) : 25~175

SMD Current Sense Resistor

Model: ECS, BWR, BWN, BWB

•

Power Rating : 1W~15W

•

Resistance(Ω) : 0.2m~10m

•

Tolerance(%) : ±1, ±2, ±5

•

TCR(ppm/C) : 50~200

High Power Precision Shunt Resistor

Model: HPS, UHPS

•

Power Rating : 100W, 250W

•

Resistance(Ω) : 0.2m~100m

•

Tolerance(%) : ±0.05, ±0.1, ±1

•

TCR(ppm/C) : 3, 5, 10

Electron Beam Welding Shunt Resistor

Model: TCS

•

Power Rating : 12W~36W

•

Resistance(Ω) : 0.05m~10m

•

Tolerance(%) : ±1, ±2, ±5

•

TCR(ppm/C) : 100

High Power Precision Shunt Resistor

Model: LPS, IRH-F

•

Rated Current : 30A~500A

•

Resistance(Ω) : 0.1666m~3.333m

•

Tolerance(%) : ±0.1, ±0.5, ±1

•

TCR(ppm/C) : 15, 30

Resistors And Resistive Applications

Precision Resistors

Thin Film High Precision Chip Resistor

Model: AR

Thin film NiCr accurate resistor, Size from 0201 to 2512, Tight tolerance
0.01% , 0.1% Low TCR 1ppm-50 ppm.

•

Power Rating: 1/20W~1W

•

Resistance(Ω): 1~3M

•

Tolerance(%): ±0.01~±1%

•

TCR(ppm/C): 1~50

Precision Metal Film Leaded Resistor

Model: MFR

Excellent stability and tight tolerance, extremely low TCR, high power is
available for telecommunication and medical equipment.

•

Power Rating: 1/8W~2W

•

Resistance(Ω): 1~10M

•

Tolerance(%): ±0.05~±1

•

TCR(ppm/C): 5~100

High Precision Metal Film Leaded Resistor

Model: MFD

High precision metal film leaded resistor , very tight tolerance and extremely
low TCR for precision high level equipment and measurement etc.

•

Power Rating: 1/4W~1/2W

•

Resistance(Ω): 10~1M

•

Tolerance(%): ±0.02~±0.1

•

TCR(ppm/C): 5~25

Our High Voltage Resistor series is specifically designed to meet the most demanding requirements, particularly in terms of temperature coefficient and high stability
performance at elevated operating voltages. These resistors excel in maintaining their precise ohmic values, minimizing any changes caused by power dissipation during
warm-up. With a low temperature coefficient, they provide exceptional stability and reliability in a wide range of applications.

High Voltage Resistors

Chassis Mounting, High Voltage, Power Film Resistor

Model: HVE, HVI

HV series for very low TCR, low VCR, high voltage-functional non-
inductive divider.

•

Power Rating: 1W~20W

•

Resistance(Ω): 200~10G

•

Tolerance(%): ±1, ±5, ±10

•

TCR(ppm/C): 25, 100

High Voltage Thick Film Planar Resistor

Model: HVP

High resistance resistors for high voltage circuits and Thin SIP shape.

•

Power Rating: 0.5W~4W

•

Resistance(Ω): 1M~1G

•

Tolerance(%): ±0.5, ±1, ±5, ±10

•

TCR(ppm/C): 50, 100, 250

Our film resistor series offers a substantial increase in power rating and pulse load performance compared to standard resistors.

High Power Film Resistors

Carbon Film/Metal Film Resistor, Melf

Model: CFS, CSR, CSRA, CSRV

The MELF is cylindrical in shape and with metal electrode Leadless face
resistor. Land pattern sizes are the same as SMD chip resistors.
It is manufactured by depositing a homogeneous film of NiCr onto a high-grade.

•

Power Rating: 1/4W~2W

•

Resistance(Ω): 1~10M

•

Tolerance(%): ±0.1, ±1, ±2, ±5

•

TCR(ppm/C): 10~1000

Power Metal Film Chip Resistor

Model: SMF

Flameproof UL94V0 molded package, resistance to heat,

humidity & insulation.

•

Power Rating: 2W, 3W, 5W

•

Resistance(Ω): 10~2M

•

Tolerance(%): ±1, ±5

•

TCR(ppm/C): 100

Power Thin Film Resistor

Model: TNP

Non-inductive design suits high frequency applications
and high-speed pulse circuits.

•

Power Rating: 20W, 35W, 50W,

100W, 140W

•

Resistance(Ω): 0.02~510K

•

Tolerance(%): ±1, ±5

•

TCR(ppm/C): 50, 100, 250

Chassis Mounting Power Film Resistor

Model: TPM, TPK

Small size SOT227, light weight, high power resistor install on air-cooled

heat sink or water-cooling is necessary.

•

Power Rating: 150W~900W

•

Resistance(Ω): 0.1~1M

•

Tolerance(%): ±5

•

TCR(ppm/C): 50, 100

Chassis Mounting, High Voltage, Power Film Resistor

Model: TPU, HPR

Low profile flat type, high power resistor. Attaching large air-cooled heat
sink or water-cooling operation.

•Power Rating: 300W, 600W, 800W
1000W, 2000W

•Resistance(Ω): 0.5~1M

•Tolerance(%): ±1, ±5, ±10
•TCR(ppm/C): 50~250
